E5CC/E5EC

Solutions Guide for FAQs

Using Basic Functions

Basic Setup Procedure

START

Connect sensor and operating terminal.

Turn ON power.

1. Setting the sensor type

2. Using ON/OFF control 3. Using PID control

Setting the set point

4. Setting temperature alarms 5. Setting heater

burnout alarms

Operation

CONTENTS

1. Setting the Sensor Type

2. Using ON/OFF Control

3. Using PID Control

4. Setting Temperature Alarms

5. Setting Heater Burnout Alarms

Introduction

This Solutions Guide is based on customer questions that were received at OMRON's

Customer Support Center. It provides practical operating procedures for setting and

changing the most common items: setting the sensor type, ON/OFF control, PID control,

setting temperature alarms, and setting heater burnout alarms.

Keep this Guide in a convenient location onsite to help you make settings and changes.

If you are having trouble with Temperature Controller settings, this is the guidebook for

you.

OMRON, 2012

form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior writte

permission of OMRON.

No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON

is constantly striving to improve its high-quality products, the information contained in this manual is subject to change

without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no

responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the

information contained in this publication.

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Setting the Sensor Type

1-1

Setting the Sensor Type

Select and set the sensor type (i.e., the Input Ty pe parameter) to the set value that corresponds to

the type of sensor used in the application and the required temperature range.

The parameter is set to 5 (K thermocouple at −200 to 1,300 °C) by default.

Thermocouples

Resistance

Thermometers E5CC/E5EC

R. etc.

JPt

E5CC/E5EC

Input type Sensor type Input temperature setting

range in °C

Input temperature setting

range in °F

E5CC/E5EC set

value

−200 to 850 °C−300 to 1500 °F0

−199.9 to 500.0 °C−199.9 to 900.0 °F1

Pt100

0.0 to 100.0 °C0.0 to 210.0 °F2

−199.9 to 500.0 °C−199.9 to 900.0 °F3

Resistance

thermometer JPt100

0.0 to 100.0 °C0.0 to 210.0 °F4

−200 to 1300 °C−300 to 2300 °F5 (default)

−20.0 to 500.0 °C0.0 to 900.0 °F6

−100 to 850 °C−100 to 1500 °F7

J −20.0 to 400.0 °C0.0 to 750.0 °F8

−200 to 400 °C−300 to 700 °F9

T −199.9 to 400.0 °C−199.9 to 700.0 °F10

E −200 to 600 °C−300 to 1100 °F11

L −100 to 850 °C−100 to 1500 °F12

−200 to 400 °C−300 to 700 °F13

U −199.9 to 400.0 °C−199.9 to 700.0 °F14

N −200 to 1300 °C−300 to 2300 °F15

R 0 to 1700 °C0 to 3000 °F16

S 0 to 1700 °C0 to 3000 °F17

B 100 to 1800 °C300 to 3200 °F18

W 0 to 2300 °C0 to 3200 °F19

Thermocouple

PLII 0 to 1300 °C0 to 2300 °F20

* When using the ES1B Infrared Temperature Sensor and an analog input, refer to the E5CC/E5EC Digital Temperature

Controllers User's Manual (Cat. No. H174).

←If the setting of the Input Type parameter does not agree with the connected sensor,

s.err (S.ERR: Input Error) will flash on the display as shown at the left when the power

supply is turned ON.

Use the procedure on page 1-2 to set the Input Type parameter correctly.

Any value can be set for any model.

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Setting the Sensor Type

1-2

Setting the Sensor Type

You set this parameter in the Initial Setting Level.

The parameter is set to 5 (K thermocouple at −200 to 1,300 °C) by default.

1 Setting the Sensor Type

Change the set value with the

(Up and Down) Keys.

Operating Display

←in-t (IN-T): Indicates the Input Type parameter.

←Default setting is 5 (5): K thermocouple a

−200 to 1,300 °C.

Initial Setting Level

←in-t(IN-T) will be di splayed to show

that the Initial Setting Level has been

entered.

Press the Ke y for at least 3 seconds.

← Flashes 3 times.

Set the parameter with the Key s.

←If a sensor is not connected or if the setting of the

Input Type parameter does not agree w ith the

connected sensor, s.err (S.ERR: Input Error) will

flash on the display when the power supply is

turned ON.

If the sensor is not connected, connect it now.

←Input Type: 0 (Pt100 resistance thermometer at

−200 to 850 °C) (example)

Set the number that you selected for the

Input Type parameter on page 1-1.

Turn ON the power supply.

Initial Setting Level

Press the ( Level) Key for at

least 3 seconds.

(When finished, press the (Level) Key for at least 1 second to return

to the operation display.)

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Using ON/OFF Control

2-1

Using ON/OFF Control

The procedure to use ON/OFF control is given step by step in this section.

The default setting is for reverse operation.

For heating control, select reverse operation. For cooling control, select direct operation.

With ON/OFF control, you can adjust the reset width (called the hysteresis) for heating or cooling

operation. The default setting is 1.0°C.

Heating (Reverse) Operation Cooling (Direct) Operation

When the output turns OFF at the set point, the

temperature will decrease. You can set the

temperature width that determines when the

output will turn ON again.

When the output turns OFF at the set point, the

temperature will increase. You can set the

temperature width that determines when the

output will turn ON again.

1Select direct or reverse operation.

Set point

OFF

Te m p e rat ur e

Output turns OFF if the

temperature is greater than

the set point.

Output turns ON if the

temperature is lower than the

set point.

Heating

Reverse Operation (Default)

OFF

Cooling

Set point

Temperature

Output turns ON if the

temperature is greater than

the set point.

Output turns OFF if the

temperature is lower than the

set point.

Direct Operation (Default)

2Adjust the hysteresis.

Set point

OFF Temperature

This width can be set as the

hysteresis.

Heating

OFF

Set point

Temperature

This width can be set as the

hysteresis.

Cooling

Step 1 Determining the Control Method

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Using ON/OFF Control

2-2

Using ON/OFF Control

You set this parameter in the Initial Setting Level. The parameter is set to ON/OFF control by default.

You set this parameter in the Initial Setting Level. The parameter is set to reverse operation by

default.

Step 2 Setting ON/OFF Control Parameters

1 Setting ON/OFF Control

Press the

(Level) Key for

at least 3

seconds.

Press the ( Mode) Key

several times to display

cntl(CNTL).

Operating Display

←cntl(CNTL): Indicates the Control Method

parameter.

←Default setting is onof (ONOF): ON/OFF

control.

Initial Setting Level

←in-t (IN-T) will be displayed to

show that the Initial Setting Level

has been entered.

Press the K ey for at least 3 seconds.

Initial Setting Level

←Flashes 3 times.

Change the parameter with the Key .

If pid (PID control) is displayed, press

the ( Down) Key to change to onof

(ONOF) (ON/OFF control).

Turn ON the power supply.

(When finished, press the (Level) Key for at least 1 second to return

to the operation display.)

2Setting Direct or Reverse Operation

Press the ( Mode) Key

several times to display

orev (OREV).

←orev (OREV): Indicates the

Direct/Reverse Operation parameter.

←Default setting is or-r (OR-R):

Reverse operation.

Initial Setting Level

Change the parameter with the Ke y.

Change the set value with the

(Up and Down) Keys.

or-r (OR-R): Reverse operation (default)

or-d (OR-D): Direct operation

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Using ON/OFF Control

2-3

Using ON/OFF Control

You set this parameter in the Adjustment Level. The parameter is set to 1.0°C by default.

3 Setting the Hysteresis

Turn ON the power supply.

Press the

(Level) Key for less

than 1 second.

Operating Display

Change the parameter with the Key .

←l.adj (L.ADJ) will be displayed

to show that the Adjustment

Level has been entered.

The four numeric digits that

identify the product code are

displayed.

←hys(HYS): Indicates the Hysteresis parameter.

←Default setting is 1.0 (1.0°C).

Press the (Mode) Key

several times to display

hys (HYS).

Change the set value with the

(Up and Down) Keys.

Set the parameter with the Keys.

Adjustment Level

(When finished, press the (Level) Key to return to the

operation display.)

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Using ON/OFF Control

2-4

Using ON/OFF Control

MEMO

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Using PID Control

3-1

Using PID Control

The procedure to use PID control is given step by step in this section.

The default setting is for reverse operation.

For heating control, select reverse operation. For cooling control, select direct operation.

You can automatically or manually set the PID constants that are used for PID control.

Adjusting the PID Constants

The suitable values of the PID constants that are used for temperature control depend on the

characteristics of the controlled object.

There are three ways that you can use to set the PID constants. These are described

below.

⇒Use autotuning (AT).

⇒Set the PID constants

manually.

⇒Use self-tuning (ST).

1 Select direct or reverse operation.

Step 1 Determining the Control Method

Set point

100%

0% Temperature

Manipulated variable

Heating

Reverse Operation (Default)

The manipulated variable

increases if the temperature is

lower than the set point.

The manipulated variable

decreases if the temperature

is higher than the set point.

Set point

100%

0% Temperature

Manipulated variable

Cooling

Direct Operation

The manipulated variable

increases if the temperature is

higher than the set point.

The manipulated variable

decreases if the temperature is

lower than the set point.

2 Adjust the PID constants.

If you ca n allow the temperature to vary while tuning the PID

constants and you need to calculate the optimum PID constants:

If you know the PID constants in advance:

If you cannot allow the temperature to vary and you need to

automatically estimate the PID constants when the set point is

changed:

With self-tuning, calculation of the PID constants is affected by

changes in the temperature, such as when a heater is turned

ON and OFF. The PID c onstants will be automatically

calculated and set. If there is an external source that causes

temperature changes (such as a heater turning OFF), u se

autotuning or set the PID constants manually.

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Using PID Control

3-2

Using PID Control

You set this parameter in the Initial Setting Level. The parameter is set to ON/OFF control by default.

Step 2 Setting PID Control Parameters

1 Setting PID Control

Press the

(Level) Key for at

least 3 seconds.

Press the ( Mode) Key

several times to display cntl

(CNTL).

Change the set value with

the (Up and Down)

Keys.

←cntl (CNTL): Indicates the Control Method parameter.

←Default setting is onof (ONOF): ON/OFF control

Initial Setting Level

←in-t (IN-T) will be displayed to

show that the Initial Setting Level

has been entered.

Press the K ey for at least 3 seconds.

←Flashes 3 times.

Change the parameter with the Key .

If onof (ON/OFF control) is displayed, press

the ( Up) Key to change to pid (PID) (PID

control).

off (OFF):

on (ON):

Self-tuning disabled. Use this setting to perform

autotuning or to set the PID constants manually.

Self-tuning enabled. Use this setting to perform

self-tuning

←st (ST): Indicates the Self-tuning parameter.

←Default setting is on (ON): Enabled.

You cannot set the following parameters while self-tuning (ST)

is enabled.

• Adjustment Level: MV Upper Limit, MV Lower Limit, SP

Ramp Set Value, and SP Ramp Fall Value

• Advanced Function Setting Level: SP Ramp Time Unit

* To set these parameters, first set the st (ST) (self-tuning)

parameter in the Initial Setting Level to off (OFF) to

disable self-tuning.

Initial Setting Level

Turn ON the power supply.

* cp (CP): Default setting of control period is 20 seconds for a

relay output (R) and 2 seconds for a voltage pulse output (Q).

(Refer to on page 3-1.)

2. Ad

usting PID Constants

Simplicity on the Worksite Solutions Guide for FAQs: E5CC/E5EC

Other manuals for E5CC

This manual suits for next models

Table of contents

Popular Temperature Controllers manuals by other brands

Swegon

Swegon LUNAd MB Instructions for use

Lucky Reptile

Lucky Reptile Thermo Control II Operation instructions

SENSORMETRIX

SENSORMETRIX Argon 100 manual

Fuji Electric

Fuji Electric PXE4 instruction manual

Yuyao gongyi

Yuyao gongyi XMT-808 series Operation manual

Selec

Selec TC544C user guide

P.W. KEY

P.W. KEY rt-208gt operating manual

Future Design

Future Design FDC-9200 user manual

BH Thermal

BH Thermal BriskONE owner's manual

West Control Solutions

West Control Solutions KS 45 Operation Notes

MCS

MCS RITC-15B Operator's manual

SMC Networks

SMC Networks Thermo-con INR-244-639 Operation manual

eltherm

eltherm Ex-TC It Series operating instructions

industrie technik

industrie technik CA1 instructions

KRAL

KRAL EET 32 operating instructions

dixell

dixell XR420C Installing and operating instructions

Opt Lasers

Opt Lasers TEC-8A-24V-PID-HC operating manual

Vaillant

Vaillant VR 92/3 Operating and installation instructions
