Omron Large Cuff Operating instructions

Thank you for purchasing the Omron®Large Cuff for large arms. This cuff

is designed to meet the needs of individuals with an arm circumference

size of 13’’ to 17’’. The Omron Large Cuff is intended for use with Omron

digital blood pressure monitors sold with the D-ring style cuff.

To connect the large cuff to your Omron automatic or manual digital

blood pressure monitor:

(1) Simply remove the existing arm cuff by disconnecting the air plug

from the monitor. To disconnect arm cuff, grasp the air plug and pull.

Do not pull on air tube.

(2) Connect the air plug from the large cuff into the air jack on the monitor.

CAUTION: Do not block the end of the air release valve. This device is

necessary to maintain a proper deation rate. Blocking the

air release valve could result in erroneous readings.

If you have an automatic inating unit and you notice it takes

more than 25 seconds to inate the cuff, use the optional AC

adapter or replace the batteries. Weak batteries will extend

the ination time and possibly cause arm discomfort.

DO NOT BLOCK THIS PART

HOW TO USE

1. Put your left arm through

the cuff loop. The bottom

of the cuff should be about

1/2” above your elbow.

2. Adjust the position of the cuff

so the tubing is positioned

along the middle of the inside

of your arm.

3. Secure the cuff so that it ts

snugly and stays in place.

You should be able to t one

nger between the cuff and

your arm.

Arm circumference Range: approximately 13’’ to 17’’ (32cm to 42cm)

Cuff Dimensions: 24 1/2’’ x 6 3/4’’

Distributed by:

OMRON HEALTHCARE, INC.

1200 Lakeside Drive

Bannockburn, Illinois 60015

www.omronhealthcare.com

Made in China

0685673-4E

HOW TO CORRECTLY APPLY THE ARM CUFF

CUFF SPECIFICATION

Bottom Edge

1/2 inch

Cu Tab Cu Tube
