Olympus Infinity SuperZoom 3000 DLX User manual

INSTRUCTIONS

Before using your SuperZoom3000DLX, read

this manual carefully to ensure correct use.

We recommend that you take test shots to get

accustomed toyour SuperZoom3000DLX

before taking important photographs.

Thank you for purchasing the Olympus SuperZoom3000DLX.

MAIN

FEATURES

Built-in 38mm ~ 110mm 3X zoom lens.

Weatherproof

Remote control (optional)

VersatilefunctionsincludingAF-Pmodetoensurethat

approaching subjects are in focus.

Quarts date ortime imprinting.

Symbols used in this manual:

Incorrect

Manual

operation

Operation

order

Automatic

operation

Operation

sound

Indicator on

Indicator

blinking

Attention

Depress

halfway

PREPARATIONS

ADVANCED

TECHNIQUES

CAMERA

MAINTENANCE

BASIC OPERATIONS

Namesandfunctionsofparts …… 4

Viewfinderdisplay/LCD panel …… 6

Diopter adjustment ....................... 7

Usingthestrap............................... 8

Outline of operations ·········· 10

Loading the batteries ········· 12

Checking the batteries ······· 13

Points to remember ············ 14

Loadingthefilm...................................................................................................... 16

Taking pictures ················································································

Unloadingthefilm ···························································· 23

Menu selection ······························ 24

Usingtheflashmodes ·················· 25

Usingthesubjectmodes ··············· 29

Spot ···································· 30

Auto-Zoom ······························ 32

Night Scene ······························ 33

AF-P..............................................

Infinity.............................

Double exposure

....................

Selftimer ································· 38

Remote control (optional) ..............39

Printing the date and time..............40

Correcting the data ........................41

Caring for your weatherproof camera................................... 42

Questionsandanswers ................................................ 44

Care

and

storage......................................................................................................

Battery handling

......................................................................................................

Troubleshooting ..................................................................... 47

Specifications ......................................................................... 50

NAMES AND FUNCTIONS OF PARTS

MENU SELECT

dial

(See

24.)

Shutter release

button

(See

15.)

Power ON/OFF

switch

(See

18.)

Flash

Light sensor

Strap eyelet

Viewfinder

Lens

Zoom

buttons

(See

19.)

zooms in — telephoto.

zooms out — wide-angle.

LCD panel

Displays the camera's mode

and operation conditions.

(See

p. 6.)

Date indicator

Selftimer

indicator

Autofocus

windows

PREPARATIONS

Selftimer / remote control

button

(See

38.)

Mid-roll rewind

button

(See

23.)

MENU button

(See

24.)

MODE and SET

buttons for

date unit

(See

p. 40 /

41.)

Tripod socket

Battery compartment

cover

Back cover

release

Film window

Viewfinder

(See

p. 6.)

Diopter adjustment

Control

(See

p. 7.)

VIEWFINDER DISPLAY/LCD PANEL

Viewfinder Display

Autofocus mark

Position your subject

within the autofocus

mark.

LCDPanel

Orange lamp

Lights when the flash

willfire.

Green lamp

Lights when the subject is

in focus.

Auto-zoom (p. 32)

Night scene (p. 33)

AF-P

(p. 34)

Double exposure

(p. 36)

Infinity (p. 35)

Spot (p. 30)

Normal

Flash modes (p. 25)

Selftimer/remote control (p. 38 / 39)

Battery check (p. 13)

Exposure counter (p. 17)

Close-up correction marks

At a close distance, your subject must

be positioned within the close-up

correction marks.

DIOPTER ADJUSTMENT

To Adjust the Viewfinder to Compensate for Near- and Farsighted Vision.

Turn the diopter adjustment control

until the viewfinder display becomes

clear.

Turn to the left if you

arefarsighted orto

the right if you are

nearsighted.

Attaching the Strap

USINGTHESTRAP

Using the Soft Case (optional)

The

optional

remote control

can also be

attachedto

the loop on the

outside of the

case.

OUTLINE OF OPERATIONS

Basic Shooting Procedures

Press the zoom buttons for

telephoto or wide-angle

photography (p. 18).

Place the autofocus mark on the

subject you want to take a

pictureof(p. 19).

Depress the shutter release

button halfway to make sure the

green lamp lights (p. 20).

Load the film (p. 16).

Open the back cover (p. 16).

Load the batteries (p. 12).
