Ntron 100-POE4 Installation and operating instructions

(Revised 2011-09-02)

100-POE4

Unmanaged Industrial 4-Port

Mid-Span POE PSE

User Manual &

Installation

Guide

(Revised 2011-09-02)

Industrial 4-Port Mid-Span POE PSE Installation Guide

100-POE4

(Revised 2011-09-02)

820 S. University Blvd., Suite 4E

Mobile, AL USA 36609

Corp. is prohibited, except as allowed under copyright laws.

Ethernet is a registered trademark of Xerox Corporation. All other product names, company names, logos

or other designations mentioned herein are trademarks of their respective owners.

The information contained in this document is subject to change without notice. N-TRON Corp. makes no

warranty of any kind with regard to this material, including, but not limited to, the implied warranties of

merchantability or fitness for a particular purpose. In no event shall N-TRON Corp. be liable for any

incidental, special, indirect or consequential damages whatsoever included but not limited to lost profits

arising out of errors or omissions in this manual or the information contained herein.

Contact Information :

N-TRON Corp.

820 South University Blvd.

Suite 4E

Mobile, AL 36609

TEL: (251) 342-2164

FAX: (251) 342-6353

Website: www.n-tron.com

Email: [email protected]

(Revised 2011-09-02)

GENERAL SAFETY WARNINGS

WARNING: Do not operate the equipment in the presence of flammable gasses or fumes. Operating

electrical equipment in such an environment constitutes a definite safety hazard.

WARNING: If the equipment is used in the manner not specified by N-TRON Corp., the protection provided

by the equipment may be impaired.

WARNING: Do not perform any services on the unit unless qualified to do so. Do not substitute

unauthorized parts or make unauthorized modifications to the unit.

WARNING: Do not operate the unit with the end plates removed, as this could create a shock or fire

hazard.

WARNING: Properly ground the unit before connecting anything else to the unit. Units not properly grounded

may result in a safety risk and could be hazardous and may void the warranty. See the grounding technique

section of this user manual for proper ways to ground the unit.

WARNING: Do not operate the equipment in a manner not specified by this manual.

ENVIRONMENTAL SAFETY WARNINGS

WARNING: Disconnect the power and allow to cool 5 minutes before touching.

ELECTRICAL SAFETY WARNINGS

WARNING: Disconnect the power cable before removing the end plates.

WARNING: Do not operate the unit with the end plates removed.

WARNING: Do not work on equipment or cables during periods of lightning activity.

WARNING: Do not perform any services on the unit unless qualified to do so.

WARNING: Observe proper DC Voltage polarity when installing power input cables. Reversing voltage

polarity can cause permanent damage to the unit and void the warranty.

(Revised 2011-09-02)

HAZARDOUS LOCATION INSTALLATION REQUIREMENTS

1. This equipment is suitable for use in Class I, Div 2, Groups A, B, C, and D, or unclassified or non-

hazardous locations only.

2. WARNING: Explosion Hazard - Substitution of components may impair suitability for Class I,

Division 2.

3. WARNING: Explosion hazard, do not disconnect while the circuit is live or unless the area is known to be

non-hazardous.

4. WARNING: Explosion Hazard - Do not remove or replace the device unless power has been switched off

or the area is known to be non-hazardous.

5. Use 60/75ºC rated Copper wire, (0.22Nm) 2 inch-lbs Tightening torque for field installed connectors.

6. WARNING: Install only in accordance with Local & National Codes of Authorities Having Jurisdiction.

7. Class I, Div 2 installations require that all devices connected to this product must be UL listed for the area in

which it is installed.

8. WARNING: Damage may occur to the RJ-45 port of the powered device (PD), if the 100-POE4 is not

powered down before disconnecting the Cat5E cable.

(Revised 2011-09-02)

Functional Overview

The 100-POE4 industrial 4-port Mid-Span POE PSE is designed to provide power over Ethernet for POE

capable devices where running a power line is either not possible or not cost effective. This feature allows

an end user to power a POE camera, wireless access point, or any other POE capable device without the

need for running separate wires for power. This also allows the ability for a centralized battery backup for

all these devices.

Key Features

Compact, space saving package

IEEE 802.3af Compliant

Four 10/100Base-TX RJ-45 Ports (DATA IN)

Four 10/100Base-TX RJ-45 POE Ports (DATA & POWER OUT)

Unmanaged operation

Extended Environmental Specifications

-40°C to 85°C Operating and Storage Temperature

Operating Humidity: 10% to 90% (Non Condensing)

Full Wire Speed Communications

LED POE Status Indication

Power Fault Status LEDs

Up to 0.8 Gb/s Maximum Throughput

Industry Standard 35mm DIN Rail Mounted Enclosure

Redundant power inputs (46-49 VDC)

Supports up to 15.4Watts per channel (13 Watts at the Powered Device (PD ))

Hardened metal DIN Rail Enclosure

(Revised 2011-09-02)

PACKAGE CONTENTS

Please make sure the package contains the following items:

1. 100-POE4

2. Instruction Sheet

Contact your carrier if any items are damaged.

UNPACKING

Remove all the equipment from the packaging, and store the packaging in a safe place. File any damage

claims with the carrier.

CLEANING

Clean only with a damp cloth.

INSTALLATION

Read the following warnings before beginning the installation:

WARNING

Never install or work on electrical equipment or cabling during periods of lightning activity. Never connect

or disconnect power when hazardous gasses are present.

(Revised 2011-09-02)

DIN-Rail Mounting

Install the unit in a standard DIN rail. Recess the unit to allow at least 2” of horizontal clearance for CAT5e

cable bend radius.

To install the unit to 35mm industrial DIN rail,

place the top edge of the included mounting

bracket on the back of the unit against the DIN

rail at a 15° angle as shown. Rotate the bottom of

the unit to the back (away from you) until it

snaps into place.

To remove the unit from the 35mm industrial

DIN rail, place a flat head screwdriver into the

release clip found at the bottom of the unit, and

apply downward force on the clip until it

disengages from the bottom of the unit from the

DIN rail. Rotate the bottom of the unit towards

you and up at an approximate 15° upward angle

to completely remove the unit.

Most N-Tron™ products are

designed to be mounted on industry

standard 35mm DIN rail. However,

DIN rail mounting may not be

suitable for all applications. Our

Universal Rack Mount Kit (P/N:

URMK) may be used to mount the

100-POE4 enclosures to standard 19"

racks as an option.

(Revised 2011-09-02)

FRONT PANEL

From Top to Bottom:

Power LED

V1 POE POE is being applied on the respective port with V1 as a valid source of power.

V2 POE is being applied on the respective port with V2 as a valid source of power.

LEDs: The table below describes the operating modes (Port LEDs are for power supply status only and

do NOT indicate link or activity):

Note: Redundant power inputs will not balance the power load. Only load from one power supply is used

at a time.

(Revised 2011-09-02)

APPLYING POWER (Top View)

Unscrew & Remove the DC Voltage Input Plug from the top header.

Install the DC Power Cables into the Plug (observing polarity on unit).

Plug the Voltage Input Plug back into the top header.

Tightening torque for the terminal block power plug is 0.22 Nm/0.162 Pound Foot.

Turn the power on the wire.

Note: It is only safe to turn the power on the wires after the wires have been secured to the

100-POE4.

WARNING: Inserting the input plug while the 48VDC is applied may cause arcing, and damage

the input connector permanently.

Verify the Power LED stays ON (GREEN).

Note: Either V1or V2can be connected to power for minimal operation. For redundant power

operation, V1and V2plugs must be connected to separate DC Voltage sources. Use wire sizes of 20-10

gauge. The power cord should be limited to less than 10 meters in order to ensure optimum

performance.

Recommended 48V DC Power Supplies, similar to:

100-240VAC:

N-Tron NTPS-48-5, DC 48V/5A or N-Tron NTPS-48-2, DC 48V/2A
