Notifier ID50 SERIES Instruction Manual
ID50/60 installation,
commissioning &
configuration
manual
997-263, Issue 4 September 2002
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
i 997-263, Issue 4
Se tember 2002
Contents
1 Introduction 1
1.1 Manual Purpose 1
1.2 System Design and Planning 1
1.3 General 2
1.3.1 Date-dependent Functions 2
1.4 CE Marking 3
1.5 EN54 unctions 3
1.6 Ancillary unctions 4
1.7 Related Documents 5
1.8 Warnings and Cautions 5
1.9 Tips 5
1.10 Glossary of Icons 6
2 Installation Guide 7
2.1 How to Use this Section 7
2.2 Pre-Installation Check List 7
2.1.1 Some Panel DOs and DONTs 7
2.3 Transient Protection 8
2.4 Product Inspection 9
2.4.1 Chec ing Your Panel for Damage 9
2.4.2 What to do if Panel is Damaged
or Suspect 10
2.5 Dismantling the Panel 11
2.5.1 Removing the Cover 11
2.5.2 Removing the Panel Electronics 12
2.5.3 Bac Box Fixing 13
2.5.4 Semi-Flush Mounting Bezel (Optional) 14
2.6 Assembling the Panel 15
2.7 RS485 Communications Link 16
2.7.1 Fitting the RS485 Interface Module PCB 17
2.8 RS232 Interface Connections 18
3 Cabling 19
3.1 Cabling Instructions 19
3.1.1 Cable Terminations 20
3.2 Cabling Installation Notes 21
3.2.1 Introduction 21
3.2.2 Quality of Cable and of Cable Installation 21
3.3 EMC Considerations 22
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
ii997-263, Issue 4
Se tember 2002
3.3.1 Screen Termination 22
3.3.2 Ferrite Sleeves (Optional) 22
3.4 MICC Cables 22
4 Commissioning 23
4.1 Introduction 23
4.2 Preliminary Checks 23
4.3 Internal Checks 24
4.3.1 Jumper Lin Options 24
4.4 External Wiring Checks 25
4.4.1 Loop Wiring 26
4.4.2 RS485 Communications Lin 27
4.4.3 DC Auxiliary Output 27
4.4.4 Sounder Circuit Outputs 28
4.4.5 CFG Outputs C and D 29
4.4.6 -VE Outputs 30
4.4.7 Digital / ÜE Inputs 30
4.4.8 Switch Connections 30
4.5 Powering the Panel 31
4.5.1 Start-up Language Selection 31
4.5.2 Batteries 32
4.6 Configuration and Handover 33
4.7 Commissioning Tests 34
4.7.1 Test LEDs 34
4.7.2 Test LCD 34
4.7.3 Test Zones 34
4.7.4 Test Auto High Test 34
4.7.5 Test Outputs 34
4.7.6 Test Buzzer 34
4.7.7 Test Keyboard 34
4.8 Sensors and Modules 35
4.8.1 EN54 Requirements 35
4.8.2 Loop Wiring Testing 35
5 Configuration 36
5.1 Introduction 36
5.2 Navigation and Number Entry 36
5.3 Level 2 Configuration Options 36
5.4 Level 3 Configuration Options 37
5.5 Setup Options 38
5.5.1 Language 38
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
iii 997-263, Issue 4
Se tember 2002
5.5.2 Date Format 39
5.5.3 Primary/Extend Delay Timers 39
5.5.4 Extinguishing System Delay 40
5.5.5 Extinguishing System Soa 40
5.5.6 Hold Switch Operation 41
5.5.7 Device Blin ing 41
5.5.8 Pulse On/Off Ratio 42
5.5.9 Service Phone Number 42
5.5.10 Site Name 43
5.5.11 Control Keys 43
5.5.12 RS232 Protocol 44
5.5.13 Print Control or Third Party 44
5.5.14 Repeater Protocol 45
5.5.15 Number of Repeaters 46
5.5.16 Transmission Device 46
5.5.17 FW4Input Disable 46
5.5.18 Digital Input 1 47
5.5.19 Day Mode Activity 48
5.5.20 Wee end Night Mode 49
5.5.21 Auto High Test 49
5.5.22 Diagnostic Mode 50
5.5.23 VdS Compatibility 50
5.6 Circuit Options 51
5.6.1 Signalling Line Circuit (SLC) - Devices 51
5.6.2 Signalling Line Circuit (SLC) - Learn 59
5.6.3 On-Board Circuits 60
5.7 Control-By-Event Output Rules 62
5.7.1 Output Type 65
5.7.2 Filter-by-type 66
5.7.3 Evacuation 67
5.7.4 Silence 67
5.7.5 Interrupt Delay 68
5.7.6 Class Change 68
5.7.7 Two Zone 69
5.7.8 Zones 70
5.7.9 Device Inputs 71
5.7.10 Soa Timer 72
5.8 Zone Texts 72
5.9 Access Options 74
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
iv997-263, Issue
September 2002
5.10 System Options 75
5.10.1 Crystal Frequency 75
5.10.2 Wipe Memory 76
5.11 Normal 76
Appendix 1 - Specification A1-1 to A1-6
Appendix 2 - ID60 Sin le Loop Panel
Differences A2-1 to A2-5
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
1 997-263, Issue
October 2002
1 Introduction
1.1 Manual Purpose
This purpose of this manual is to provide the user with
all recommended procedures and full technical details
for the successful installation, commissioning and
programming of a NOTIFIER ID50 Series Panel.
The descriptions and procedures also apply to the
NOTIFIER ID60 panel. Differences between the ID50 and
ID60 panels are given in Appendix 2.
Procedures described in this manual include appropriate
warnings and cautions to guide the user towards adopting
safe and methodical work practices during the installation,
commissioning and programming phases.
Important Note
This manual must be read, and its content clearly
understood, before proceeding with any work relating to
the ID50 Series Panel. Damage to the control panel may
result from NOT following the recommended procedures
described in this manual.
This manual provides all necessary instructions for the
ID50 Series Panel and applies only to fire panels fitted
with compatible software.
CAUTION: In particular, care must be taken when
powering up down any repeaters.
If there are any areas of doubt, consult your supplier
before continuing with the system installation,
commissioning and programming.
1.2 System Design and Planning
It is assumed that the system, of which the ID50 Series
Panel equipment is a part, has been designed by a
competent fire alarm system designer in accordance with
the requirements of EN5 Part 1 and any other local
codes of practice that are applicable.
The design drawings should clearly show the positions
of all the ID50 Series Panel control equipment and field
devices.
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
2997-263, Issue 4
ctober 2002
1.3 General
The ID50 Series Panel is designed for use with
N TIFIERs range of addressable analogue sensors,
control and monitoring modules and addressable call
points. A unique signalling protocol is used, having digital
address and control signals and analogue pulse width
monitoring for the reply data from devices.
The serial communications interface operates under
RS485 protocol and enables communications between
the fire panel and repeaters.
While every effort is made to ensure the accuracy of the
content of this manual, the manufacturer reserves the
right to change the information without notice.
Installation
The ID50 Series Panel is easy to install providing the
recommended procedures described in this manual are
followed. To avoid inadvertent contamination of the PCB
Assembly, the manufacturer recommends it be installed
in the back box only after all other trades have completed
their tasks.
Commissioning
To commission the ID50 Series Panel, follow the
recommended procedures described in this manual. The
manufacturer recommends that during commissioning
and maintenance, ALL RS485 signal cables are
disconnected at the Panel end, BEF RE powering down
the system and are connected AFTER powering up the
system.
Configuration
To configure the panel and system, carefully read and
follow the procedures given in this manual. These
procedures describe the menus that are displayed on
the Liquid Crystal Display (LCD) Unit.
Refer to the ID50 Series perating manual (ref: 997-
264) for a description of compatible addressable
Signalling Loop Circuit (SLC) analogue devices.
1.3.1 Date-dependent Functions
The calendar end date for this product is 31/12/2063
(two thousand and sixty-three) and it will perform correctly
up to this date.
The calendar function has not been tested beyond
this date.
Only fit the electronics
module after all the other
trades have completed
their tasks!
Only suitably-qualified
engineers must install,
commission and
configure this product
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
3 997-263, Issue 4
ctober 2002
1.4 CE Marking
This panel is CE Marked to show that it conforms to the
requirements of the following European Community
Directives:
nElectromagnetic Compatibility Directive 89/336/EEC
(and the amending Directives 92/31/EEC, 93/68/EEC)
nLow Voltage Directive 73/23/EEC (and the amending
Directive 93/68/EEC).
1.5 EN54 Functions
This fire control panel is designed to comply with the
requirements of EN54 Part2/4:1997. In addition to the
basic requirements of EN54-2, the panel may be configured
to conform with the following optional functions - the
applicable clauses of EN54-2 are referenced as follows:
Options Clause
Indications:
Fault signals from points 8.3
Recording of the number of entries
into fire alarm condition 7.13
Controls:
Coincidence detection 7.12
Dela of the immediate actioning of outputs 7.11
Disablement of each address point 9.5
Test condition 10
Outputs:
Fire alarm device(s) (Sounders) 7.8
Fire alarm routing equipment 7.9
Fire protection equipment 7.10
Fault warning routing equipment 8.9
(requires monitoring b fault routing equipment)
The following features are provided by the Power Supply
Unit (PSU) of the ID50 Series Panel to comply with
EN54-4.
Features of the ID50 EN54-4
Power Supply Unit (PSU Clause
Derive power from the mains suppl 5.1
Derive power from a standb batter source 5.2
Charge and monitor the standb
batter /batteries 5.3
Detect and signal various PSU faults 5.4
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
4997-263, Issue 4
ctober 2002
1.6 Ancillary Functions
The following is a list of ancillary functions that are
provided by the ID50 Series panel in addition to the those
required by EN54-2/4. These functions are described in
the section of this manual as referenced (except those
marked thus * which are described in 997-264-XXX,
ID50 Series Panel-Operating Manual):
Ancillar Manual
Functions Section Refs.
Site Specific Setup Options 5.5
Access Options 5.9
Voltage Indications *4.11.7
Control-b -Event 5.7
Output modes 5.7.1
Input t pe pattern 5.7.9
Disable/enablement *4.9
Repeater interface 2.7
Self-learn configuration - manual 5.6.1
Self-learn configuration - auto 5.6.2
Module supervision options 5.6.1
Module silence options 5.7.4
Text editing 5.8
Sensor LED blinking on/off 5.5.7
Bell pulsing ratio 5.5.8
Displa of alarm count *4.11.6
Extend dela timer 5.5.3
Sounder Volt-free contact options 4.4.5
Rela drive output option 4.4.6
Extinguishing s stem features 5.5.4, 5.5.5, 5.5.6,
5.7.1
ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
5 997-263, Issue
September 2002
1.7 Related Documents
This manual only describes the installation,
commissioning and configuration of the ID50 Series
Panel. All operating functions are covered by the:
nID50 Series Panel Operating Manual (ref:
997-26 -XXX)
Note: XXX is the country code for the manual. For the
UK this code is blank.
The Panel can support repeaters via the RS 85
communications link. This manual does not provide
details about the repeaters; these are described in:
nIDR-2A, -2P & -6A Repeaters User Manual
(ref:997- 11-XXX).
nIDR Mimic Installation and Commissioning Manual
(ref:997- 12-XXX).
Note: XXX is the country code for the manual. For the
UK this code is blank.
The ID50 Panel can also support the VIEWTM sensor.
This manual does not attempt to cover all the VIEWTM
sensor programming and calibration issues as these are
described in some detail in the following, which is
available from NOTIFIERs Technical Support
Department:
nVIEWTM Application Guide (ref:997-198).
1.8 Warnings and Cautions
Where appropriate, the manual includes advisory
warnings and cautions to remind you to consider safety
at all times, especially when following the procedures
described herein.
You are alerted to any areas where high voltage [i.e. non-
Safety Extra-Low Voltage (SELV)] is present, or where
there may be a risk of damage to static-sensitive devices
if the recommended procedures described in this manual
are not followed.
An example of a high voltage warning and an anti-static
caution is provided to the left of this paragraph.
The ID50 Series Panel incorporates some features
which, if used inappropriately, may contravene the
requirements of EN5 . Where there is a possibility of
such an occurrence, a suitable warning is given with brief
details of the EN5 requirement. A typical EN5 non-
compliance warning is illustrated at left.
1.9 Tips
Handy tips are included, where appropriate, to assist
you in following quick and safe procedures for fire
detection system installation and integration.
Look for the TIP! icon and supporting text, typically
illustrated at left.
Magnetise the tip of your
screwdriver to help when
offering small screws to
holes in confined spaces.
W RNING: High Voltage!
Take suitable precautions to
avoid electric shock
EN54-2:-8.8
One hardware-
configurable output
must be configured
as a fault relay
Other manuals for ID50 SERIES
3
This manual suits for next models
1
Table of contents
Other Notifier Fire Alarm manuals
Notifier
Notifier CAB-5 Technical manual
Notifier
Notifier AM2020 User manual
Notifier
Notifier UniNet 2000 Simplex 4010 NION User manual
Notifier
Notifier AM2020 User manual
Notifier
Notifier INERTIA-2464/64 User manual
Notifier
Notifier RP-1001 User manual
Notifier
Notifier AFP-200 User manual
Notifier
Notifier ID50 SERIES Instruction sheet
Notifier
Notifier ONYX Series User manual
Notifier
Notifier ACS Series User manual
Notifier
Notifier NBG-12LO User manual
Notifier
Notifier NFS-640 Owner's manual
Notifier
Notifier LCD-80F User manual
Notifier
Notifier UZC-256 User manual
Notifier
Notifier AFP-300 Owner's manual
Notifier
Notifier NFS-3030/E Owner's manual
Notifier
Notifier NFS-640 User manual
Notifier
Notifier IFS-2600 Instruction Manual
Notifier
Notifier AFC-600 User manual
Notifier
Notifier ID50 SERIES User manual
Popular Fire Alarm manuals by other brands
Zeta Alarm Systems
Zeta Alarm Systems INFINITY ID2 installation manual
System Sensor
System Sensor 22051TLE-RF-26 Installation and maintenance instructions
Pittway
Pittway Notifier AM2020 troubleshooting guide
Ampac
Ampac ZoneSense user manual
Kidde
Kidde VM-1 Technical reference manual
LST
LST SIM016-3 Specification sheet
