Norac UC5 Rogator 600 User manual
Spray Height Controlle
r
Rogato
r
(600)
Installation Manual
RG09
Printed in Canada
Copyright 2009 by NORAC Systems International Inc.
Reorder P/N: UC5-BC-RG09-INST Rev A (Rogator 600)
NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and
without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information
contained in this manual. The technical information in this manual was reviewed at the time of approval for publication.
Contents
1Introduction.....................................................................................................1
2General UC5 System Layout.........................................................................2
3Kit Parts ...........................................................................................................3
4Ultrasonic Sensor Installation .......................................................................6
5Roll Sensor Installation ............................................................................... 10
6Module Installation ...................................................................................... 12
7Connecting the Sensors to the CANbus................................................... 17
8Hydraulic Installation .................................................................................. 18
9Software Setup............................................................................................. 22
10Cable Drawings ............................................................................................ 23
1
1Introduction
Congratulations on your purchase of the NORAC UC5 Spray Height Controller. This system
is manufactured with top quality components and is engineered using the latest technology to
provide operating reliability unmatched for years to come.
When properly used the system can provide protection from sprayer boom damage, improve
sprayer efficiency, and ensure chemicals are applied correctly.
Please take the time to read this manual completely before attempting to install the system. A
thorough understanding of this manual will ensure that you receive the maximum benefit from
the system.
Your input can help make us better! If you find issues or have suggestions regarding the parts
list or the installation procedure, please don’t hesitate to contact us.
Every effort has been made to ensure the accuracy of the information contained in
this manual. All parts supplied are selected to specially fit the sprayer to facilitate
a complete installation. However, NORAC cannot guarantee all parts fit as
intended due to the variations of the sprayer by the manufacturer.
Please read this manual in its entirety before attempting installation.
2
2General UC5 System Layout
Figure 1 illustrates the general layout of the UC5 system components:
Figure 1: General UC5 System Layout
The use of dielectric grease is not recommended on any NORAC electrical
connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of
the supplied Permatex Anti-seize grease to all threaded parts upon installation.
Permatex Anti-seize lubricant is preferred, but other similar anti-seize products
may be used.
3
3Kit Parts
3.1 Kit Overview
Figure 2: RG09 System Parts
4
3.2 Hydraulic Plumbing
Figure 3: RG09 Hydraulic Plumbing
5
3.3 List of Parts
Item Part Number Name Quantity
C01 43220-10 CABLE UC5 NETWORK 14 AWG 10M 1
C02 43220-01 CABLE UC5 NETWORK 14 AWG 1M 1
C04 43210-01 CABLE UC5 NETWORK 18 AWG 1M 2
C05 43210-10 CABLE UC5 NETWORK 18 AWG 10M 4
C10 43230-04 CABLE UC5 VALVE 2PIN DT TO 2PIN DT 4
C20 43240-01 CABLE UC5 INTERFACE TILT DT 1
C21 43240-31 CABLE UC5 INTERFACE MAIN DT (WITH AUX 1, 2 & 3) 1
E01 43710 UC5 CONTROLLER MODULE 1
E02 43720 UC5 VALVE MODULE 1
E03 43732 UC5 INPUT MODULE PASS THRU 1
E04 43740 UC5 ROLL SENSOR 2
E05 43750 UC5 ULTRASONIC SENSOR 3
E10 43760 UC5 NETWORK COUPLER 3-WAY 2
E11 43765 UC5 NETWORK COUPLER 8-WAY 1
E12 43764 UC5 NETWORK COUPLER 2-WAY 1
E20 43764T UC5 NETWORK COUPLER 2-WAY WITH TERMINATOR 2
F01 44928 ORIFICE INSERT .047 IN ONE WAY 2
M01 UC5-BC-MANUAL-ECH0/VT MANUAL UC5 OPERATORS - VIRTUAL TERMINAL 1
M02 UC5-BC-RG09-INST MANUAL INSTALLATION UC5 ROGATOR (600) 1
P01 106034 UC5 NETWORK 2 PIN PLUG 4
P02 106035 UC5 NETWORK 12 PIN PLUG (A-KEY) 1
P03 106162 UC5 NETWORK 6 PIN PLUG 4
V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT 1
6
4Ultrasonic Sensor Installation
4.1 Ultrasonic Sensor Serial Number Arrangement
When installing the UC5 sensors, start with the smallest serial number on the left-hand side,
and proceed to the largest serial number on the right hand side. Each UC5 sensor has a serial
number stamped on the sensor housing.
Apply a light coating of the supplied Permatex Anti-seize grease to all threaded
parts upon installation.
Figure 4: Sensor Serial Number Arrangement
7
4.2 Wing Sensor Installation
1. The sensor bracket should be oriented forward (ahead of the boom).
2. Mount the wing sensor brackets inside of the breakaway sections.
3. Mount the NORAC UC5 ultrasonic sensor into the sensor bracket and run the sensor
cable behind the bracket.
Figure 5: Outer Wing Sensor Bracket Location and Mounting
Figure 6: Inner Wing Sensor Bracket Mounting
