NOMA 043-7339-2 User manual
TRUE HEPA AIR PURIFIER
SMALL
PRODUCT NO. 043-7339-2
USER MANUAL
READ AND SAVE THESE INSTRUCTIONS
2
TABLE OF CONTENTS
01. KNOW YOUR AIR PURIFIER
02. OPERATING INSTRUCTIONS
03. CLEANING INSTRUCTIONS
04. FILTER REPLACEMENT
05. PRODUCT SPECIFICATIONS
06. FAQs
07. SAFETY / CAUTIONS
08. TROUBLESHOOTING
09. WARRANTY & DISPOSAL
3
7
11
13
15
16
17
19
20
43
KNOW YOUR AIR PURIFIER
FEATURES
01.
02.
03.
04.
AIR OUTPUT VENT
CONTROL PANEL
AIR INPUT GRILL
AC PLUG
01 01
04
02
03
65
KNOW YOUR AIR PURIFIER
COMPONENTS
01.
02.
03.
04.
FAN HOUSING
TRUE HEPA FILTER
PRE-FILTER
AIR INTAKE GRILL
01 01
03
04
02
02
OPERATING INSTRUCTIONS
SET UP DIRECTIONS
87
01. Place
Place your air purier on the oor and be sure nothing is covering the air
intake grill.
04. Relax
Enjoy your air purier in quiet, peaceful, bliss.
03. Set
Select your optimal settings by referring to the OPERATING INSTRUCTIONS
(pages 9 - 10).
02. Power
Plug in the air purier and press the Power Button once. The unit will
start immediately on the Medium fan speed.
02.
109
02
03. Timer Button
Set the purifying duration for 2, 4 or 8 hours.
04. Ionizer Switch
Turn on the optional Ionizer to help your air purier trap airborne
particles more efciently.
01. Power Button
Push once to turn on the air purier and the unit will start immediately on
the Medium fan speed.
02. Fan Speed Button
Change the fan speed to Low, Medium or High.
OPERATING INSTRUCTIONS
CONTROLS AND SETTINGS
03 02 01
04
06. Night Mode
To dim the indicator lights, press and hold the Power Button for 2
seconds. To exit night mode, press and hold the Power Button for 2
seconds again.
05. Filter Replacement Indicator
Only when the True HEPA lter needs to be replaced will the indicator
beside the Power Button illuminate. Follow the FILTER REPLACEMENT
instructions on pages 13-14 and when completed, reset the indicator
by pressing and holding the Power and Timer buttons for 2
seconds.
11
CLEANING INSTRUCTIONS
CARE & MAINTENANCE
Make sure the air purier is turned off and unplugged.
For a quick clean, wipe down the unit with a soft, lightly dampened
cloth. Do not get the fan housing too wet as it may cause issues.
For a more thorough cleaning, dust the air output vent and air intake
grill with a small soft brush and use a dry, soft cloth to wipe it down the
interior.
To clean the pre-lter, follow Pre-Filter Maintenance for instructions.
When the Filter Replacement Indicator turns on, the True HEPA lter
needs to be replaced. Follow FILTER REPLACEMENT directions on page
13 for instructions. Do not wash the True HEPA lter.
General Maintenance
01.
02.
03.
04.
05.
12
03
Make sure the air purier is turned off and unplugged.
Follow the rst 2 operations of FILTER REPLACEMENT on page13.
Vacuum the pre-lter or machine wash in cool water and dry on the
gentle cycle.
Be sure the pre-lter is dry and slip it back onto the True HEPA lter by
following the last 2 operations of FILTER REPLACEMENT on page 14.
Pre-Filter Maintenance
01.
02.
03.
04.
13
Rotate the fan housing
counter-clockwise and lift from air
intake grill.
Take the lter our of the air intake grill.
Remove the pre-lter from the True HEPA
lter.
0201
14
04
FILTER REPLACEMENT
TRUE HEPA FILTER REPLACEMENT
True HEPA lter should be replaced every 3-6 months. The life of the lter
will vary depending on air quality and usage.
Dispose of the used True HEPA lter and
replace with a new lter.
Slip the pre-lter back onto the True
HEPA lter and place back into the air
intake grill.
Put the fan housing back onto the air
intake grill, rotating clockwise until the
fasteners lock into the groove.
Reset the Filter Replacement Indicator
by pressing and holding the Power and
Timer buttons for 2 seconds
0403
15
05
PRODUCT SPECIFICATIONS
OVERVIEW
Product Name NOMA® True HEPA Small Air
Purier
Product No. 043-7339-2
Clean Air Delivery Rate
(CADR) 70
Optimal Room Size SMALL SPACE:
100 sq. ft. (9.3 m2)
Pre-Filter Used NOMA® Reusable Small Air
Purier Pre-Filter
Main Filter Used NOMA® True HEPA Small Air
Purier Replacement Filter
Ionizer Switch Yes
Number of Fan Speeds 3
Energy Star Certied Yes
cETLus Listed Yes
AHAM Certied Yes
Input Voltage AC 120 V | 60Hz
16
06
FAQs
FREQUENTLY ASKED QUESTIONS
Q: What does the Clean Air Delivery Rate (CADR) mean?
A: CADR is a measure of the volume of air that is processed
by the purier. The higher the CADR, the more powerful the air
purier.
Q: What does a pre-filter do?
A: It extends the life of your True HEPA filter by initially filtering out
larger particles, such as mold and pollen.
Q: What does an Ionizer do?
A: Ionizers electrically charge a room’s air molecules so your air
purier can trap airborne particles more efciently.
Q: Will my settings be saved if I turn off my air purifier?
A: Yes, if kept plugged in, the air purier will return to the last
settings it was on before being turned off. If unplugged, the unit
will return to the default Medium fan speed when turned back
on.
17 18
SAFETY / CAUTIONS
SAFETY CONCERNS
•
•
•
•
•
•
•
ENSURE THAT ALL AIR OPENINGS ARE NOT RESTRICTED OF COVERED
IN ANY WAY. DO NOT PLACE ANYTHING ON TOP OF THE UNIT.
NEVER DROP OR INSERT ANY OBJECT INTO ANY OPENINGS.
DO NOT PLACE AIR PURIFIER NEAR HEAT SOURCES SUCH AS STOVES,
RADIATORS, AND HEATERS. DO LOCATE YOUR AIR PURIFIER ON AN
INSIDE WALL NEAR AN ELECTRICAL OUTLET.
DO NOT OPERATE THE AIR PURIFIER IF THERE IS DAMAGE TO
THE POWER CORD OR IF THE AIR PURIFIER HAS BEEN DROPPED,
DAMAGED OR MALFUNCTIONS. RETURN THE AIR PURIFIER TO AN
AUTHORIZED SERVICE FACILITY.
DO NOT ATTEMPT TO REPAIR OR ADJUST ANY ELECTRICAL OR
MECHANICAL FUNCTIONS ON THIS UNIT. DOING SO WILL VOID
YOUR WARRANTY. THE INSIDE OF THE UNIT CONTAINS NO USER
SERVICEABLE PARTS.
TO AVOID FIRE OR SHOCK HAZARD, PLUG THE AIR PURIFIER DIRECTLY
INTO A 120V AC ELECTRICAL OUTLET.
TO AVOID FIRE HAZARD, NEVER PLACE THE CORD UNDER RUGS OR
NEAR HEAT REGISTERS.
07
•
•
•
•
•
•
•
•
DO NOT ALLOW CHILDREN TO HANDLE THE AIR PURIFIER.
SUPERVISION REQUIRED WHEN PLACED IN A ROOM WITH CHILDREN.
USE AIR PURIFIER ONLY FOR INTENDED HOUSEHOLD USE AS
DESCRIBED IN THIS MANUAL. ANY OTHER USE NOT RECOMMENDED
BY THE MANUFACTURER MAY CAUSE FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS. THE USE OF ATTACHMENTS NOT
RECOMMENDED OR SOLD BY THE MANUFACTURER MAY CAUSE
HAZARDS.
DO NOT USE OUTDOORS.
AIR PURIFIER SHOULD BE UNPLUGGED WHEN NOT IN USE. BE SURE TO
UNPLUG THE UNIT BY PULLING ON THE PLUG AND NOT THE CORD.
THIS AIR PURIFIER REQUIRES MAINTENANCE TO OPERATE EFFICIENTLY.
REFER TO CLEANING AND MAINTENANCE PROCEDURES.
NEVER CLEAN THE AIR PURIFIER WHILE IT IS PLUGGED IN. DO NOT
ATTEMPT TO WASH THE UNIT UNDER RUNNING WATER.
DO NOT PLUG IN THE CORD WITH WET HANDS: ELECTRIC SHOCK
COULD RESULT.
THIS PRODUCT COMPLIES WITH THE MAXIMUM ALLOWABLE
CONCENTRATION OF OZONE OF 0.050 PARTS PER MILLION BY
VOLUME (PPMV) IN A 24-HOUR PERIOD.
