Nokia BH 604 - Headset - Binaural User manual

Nokia Bluetooth Stereo Headset

BH-604 User Guide

9203660

Issue 2 EN

DECLARATION OF CONFORMITY

Hereby, NOKIA CORPORATION declares that this HS-96W product is in compliance with the

essential requirements and other relevant provisions of Directive 1999/5/EC.

A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/

declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this document

in any form without the prior written permission of Nokia is prohibited.

Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation. Other

product and company names mentioned herein may be trademarks or tradenames of their

respective owners.

Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes

and improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no

warranties of any kind, either express or implied, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose, are made in relation to the

accuracy, reliability or contents of this document. Nokia reserves the right to revise this

document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer

nearest to you.

Unauthorized changes or modifications to this device may void the user's authority to

operate the equipment.

Export Controls

This device may contain commodities, technology or software subject to export laws and

regulations from the US and other countries. Diversion contrary to law is prohibited.

9203660 / Issue 2 EN

Contents

1. Introduction ......................... 4

Bluetooth wireless technology .......... 4

2. Get started............................ 6

Overview .................................................. 6

Chargers ................................................... 6

Charge the battery ................................ 6

Switch the headset on or off ............. 7

Switch on ............................................. 7

Switch off............................................. 7

Pair and connect the headset ............ 8

Pair and connect the headset

with a mobile phone that has

a music player feature...................... 8

Pair and connect the headset

with a music player........................... 8

Disconnect the headset.................... 9

Reconnect the headset..................... 9

3. Basic use ............................. 10

Place the headset over the head..... 10

Adjust the volume............................... 10

Call handling......................................... 10

Listen to music..................................... 11

Clear the settings or

reset the headset................................. 11

4. Battery information ........... 12

Care and maintenance ........... 13

Introduction

1. Introduction

With the Nokia Bluetooth Stereo Headset BH-604 you can listen to

music from your compatible music player and make and receive

hands-free calls using your mobile phone. The music player can be the

music player feature of your mobile phone or a separate music device.

You can use the headset with compatible devices that support

Bluetooth wireless technology.

Read this user guide carefully before using the headset. Also read the

user guide for your mobile phone, which provides important safety and

maintenance information, and the user guide for your music device.

Keep the headset and its accessories out of reach of small children.

■Bluetooth wireless technology

Bluetooth wireless technology allows

you to connect compatible devices

without cables. A Bluetooth

connection does not require that the

headset and the other device be in line

of sight, but the maximum distance

between the devices is 10 meters

(30 feet). The closer the devices are to

each other, the better is the

performance. The optimal operating

range is shown in dark grey in the

picture. The connection is subject to interference from distance and

obstructions (shown in light grey) or other electronic devices.

The headset is compliant with Bluetooth Specification 2.0 + EDR

supporting the following profiles: Headset Profile 1.1, Hands-Free

Profile 1.5, Advanced Audio Distribution Profile (A2DP) 1.0, and Audio

Video Remote Control Profile 1.0. Check with the manufacturers of

other devices to determine their compatibility with this device.

Introduction

There may be restrictions on using Bluetooth technology in some

locations. Check with your local authorities or service provider.

Get started

2. Get started

■Overview

The headset contains the following parts:

• Fast forward key (1)

• Microphone (2)

• Volume key (3)

• Multifunction key (4)

• Play/pause key (5)

• Rewind key (6)

• Indicator light (7)

• Charger connector (8)

Before you can start using the headset, you must charge the battery and

pair the headset with a compatible mobile phone.

Parts of the headset are magnetic. Metallic materials may be attracted to the

headset. Do not place credit cards or other magnetic storage media near the

headset, because information stored on them may be erased.

■Chargers

Check the model number of any charger before using it with this headset. The

headset is intended for use with the AC-4, AC-5, and DC-4 chargers.

Warning: Use chargers approved by Nokia for use with this particular

enhancement. The use of any other types may invalidate any approval

or warranty, and may be dangerous.

When you disconnect the power cord of any enhancement, grasp and pull the

plug, not the cord.

■Charge the battery

The headset has an internal, nonremovable, rechargeable battery. Do

not attempt to remove the battery from the headset, as you may

damage the headset.

Get started

1. Connect the charger to a wall outlet.

2. Connect the charger cable to the charger connector. The indicator

light is red while charging. It may take a while before charging starts.

If charging does not start, disconnect the charger, plug it in again,

and retry.

Charging the battery fully takes less than 1 hour and 15 minutes.

3. When the battery is fully charged, the indicator light turns green.

Disconnect the charger from the headset and the wall outlet.

The fully charged battery has power for up to 18 hours of talk time, up to

2 weeks of standby time, or up to 19 hours of music playing time.

However, the times may vary with different compatible Bluetooth

devices, usage settings, usage styles, and environments.

When battery power is low, the headset beeps at regular intervals, and

the indicator light slowly flashes red. Recharge the battery.

■Switch the headset on or off

Switch on

To switch on, press and hold the multifunction key for about 2 seconds.

The headset beeps, and the green indicator light is briefly displayed.

When the headset tries to connect to the paired mobile phone or music

player that you have last used with it, the indicator light slowly flashes

green. When the headset is connected to a paired device and is ready for

use, the indicator light slowly flashes blue. If the headset has not been

paired with a device, it automatically enters the pairing mode (see “Pair

and connect the headset,” p. 8).

If you connect the headset to a device but do not use it for a while,

switch off the headset to save power.

Switch off

To switch off, press and hold the multifunction key for about 5 seconds.

The headset beeps, and the red indicator light is briefly displayed.

Get started

■Pair and connect the headset

Pair and connect the headset with a mobile phone that

has a music player feature

If your phone supports the A2DP Bluetooth profile and has a music

player feature, you can use the phone to make and receive calls and to

play music with the headset.

1. Ensure that your phone is switched on.

2. If the headset has not been previously paired with a device, switch

on the headset. The headset enters the pairing mode, and the

indicator light starts to flash blue quickly.

If the headset has been previously paired with another device, switch

off the headset, and press and hold the multifunction key until the

indicator light starts to flash blue quickly.

3. Activate the Bluetooth feature on the phone, and set it to search for

Bluetooth devices. See the user guide of your phone for instructions.

4. Select the headset from the list of found devices.

5. Enter the passcode 0000 to pair and connect the headset to your

phone. In some phones, you may need to make the connection

separately after pairing. You only need to pair the headset with your

phone once.

If pairing is successful, the headset appears in the menu of the mobile

phone where you can view the currently paired Bluetooth devices.

When the headset is connected with your mobile phone and ready for

use, the indicator light of the headset slowly flashes blue.

Pair and connect the headset with a music player

If your phone does not support the A2DP Bluetooth profile, you can

separately pair the headset with the phone and a music player that

supports this Bluetooth profile.

If you have paired and connected the headset with your phone,

disconnect the headset from it before pairing the headset with a music

player.

Get started

To pair the headset with a music player, follow the instructions in “Pair

and connect the headset with a mobile phone that has a music player

feature,” p. 8. If your music player does not have a keypad, it may use the

Bluetooth passcode 0000 by default. If this is not the case, see the user

guide of your music player to change the default Bluetooth passcode to

0000.

If pairing is successful and the headset is connected with your music

player, the indicator light of the headset slowly flashes blue.

Disconnect the headset

To disconnect the headset from your device, switch off the headset, or

disconnect it in the Bluetooth menu of your device.

You do not need to delete pairing with the headset to disconnect it.

Reconnect the headset

To connect the headset to the phone or music player that you have last

used with it, switch on the headset, or make the connection in the

Bluetooth menu of your device.

In your device, you may be able to allow the headset to connect to it

automatically when the headset is switched on. To do this in Nokia

devices, change your paired device settings in the Bluetooth menu.

Basic use

3. Basic use

■Place the headset over the head

Place the headset over your head so that the speaker pads rest

comfortably on your ears.

Place the pad indicated with L on the left ear and the pad with R on the

right ear. Adjust the headband length for the best fit.

Warning: When using the headset your ability to hear outside sounds

may be affected. Do not use the headset where it can endanger your

safety.

■Adjust the volume

To adjust the headset volume, slide the volume key forward to increase

or backward to decrease the volume during a call or while listening to

music.

■Call handling

To make a call, use your mobile phone in the normal way when the

headset is connected to it.

If your phone supports redialing with the headset, press the

multifunction key twice quickly when no call is in progress.

If your phone supports voice dialing with the headset, press and hold the

multifunction key for about 2 seconds until the phone starts voice

dialing, and proceed as instructed in the user guide of the phone. Voice

dialing cannot be used during a call.

To answer a call, press the multifunction key, or use the keys of the

phone. To reject the call, press the multifunction key twice quickly.

To end a call, press the multifunction key, or use the keys of the phone.

To mute or unmute the microphone during a call, press the play/pause

key.

Other manuals for BH 604 - Headset - Binaural

Table of contents

Other Nokia Headset manuals

Nokia

Nokia BH-900 User manual

Nokia

Nokia BH 213 - Headset - Over-the-ear User manual

Nokia

Nokia HDW 2 User manual

Nokia

Nokia HS 36W User manual

Nokia

Nokia BH-800 User manual

Nokia

Nokia BH-501 User manual

Nokia

Nokia BH-503 User manual

Nokia

Nokia BH-602 User manual

Nokia

Nokia BH-806 User manual

Nokia

Nokia BH-500 User manual

Nokia

Nokia BH-505 User manual

Nokia

Nokia BH 213 - Headset - Over-the-ear User manual

Nokia

Nokia BH 212 - Headset - Over-the-ear User manual

Nokia

Nokia HS-54W - Headset - Over-the-ear User manual

Nokia

Nokia BH-606 User manual

Nokia

Nokia BH 301 - Headset - Over-the-ear User manual

Nokia

Nokia HS 11W User manual

Nokia

Nokia HS HS 4W User manual

Nokia

Nokia BH-303 - Headset - Over-the-ear User manual

Nokia

Nokia BH105 - Bluetooth Headset Ice User manual

Nokia

Nokia BH-106 Black User manual

Nokia

Nokia BH-703 - Headset - Over-the-ear User manual

Nokia

Nokia BH 600 - Headset - Over-the-ear User manual

Nokia

Nokia WH-500 User manual

Popular Headset manuals by other brands

Sena

Sena SMH10 quick start guide

IASUS

IASUS Stealth IA-NT4-BASIC-BT manual

Sennheiser

Sennheiser EPOS ADAPT 230 user guide

Doro

Doro Flexus HS2005 user guide

GE 98971 datasheet

Hama

Hama 00184070 quick start guide

Plantronics

Plantronics Blackwire 3200 Series user guide

Blue Tiger

Blue Tiger Advantage PLUS user manual

Jawbone

Jawbone Icon user manual

Jabra

Jabra FR 20 user guide

Roxcore

Roxcore Flow A+ manual

Turtle Beach

Turtle Beach XP 510 user guide

Philips

Philips SHB6101 Specification sheet

Jabra

Jabra PRO 9460 Duo datasheet

HyperX

HyperX HyperX Cloud Flight manual

Bose

Bose MIE2 Mobile owner's guide

Jabra

Jabra Steel quick start guide

HyperX

HyperX cloud ii quick start guide
