Get started Nokia N75

www.nokia.com/us

©2007 Nokia. All rights reserved. Nokia, Nokia Connecting People, the Nokia

Original Enhancements logo, Nseries and N75 are trademarks or registered

trademarks of Nokia Corporation. Printed in Mexico.

9252452 N4555 Ver. 1.0 03/07

Nokia N75

Get Started

Copyright © 2007 Nokia. All rights reserved.

Nokia, Nokia Connecting People, Visual Radio, and Pop-Port are trademarks or registered trademarks of Nokia Corporation.

Other product and company names mentioned herein may be trademarks or tradenames of their respective owners.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written

permission of Nokia is prohibited.

9252452, Issue 1 EN

Insert the SIM card and battery

Keep all SIM cards out of the reach of small children.

Always switch the device off, and disconnect the charger

before removing the battery.

1With the back of the device facing you, press the

release button (1), and slide off the cover (2).

2Slide the SIM card into the holder until it clicks. Make

sure that the bevelled corner on the card is facing the

left side of the device and that the contact area on

the card is facing down.

3Insert the battery.

4Replace the back cover.

To remove the SIM card, slide the lock (1) to the

right and pull out the SIM card (2).

Charge the battery

1Connect a compatible charger to a wall outlet

2Connect the power cord to the device. The battery

indicator bar starts scrolling. The device can be

used while charging. If the battery is completely

discharged, it may take a few minutes before the

charging indicator is shown.

3When the battery is fully charged, the bar stops scrolling. Disconnect the charger, first from

the device, then from the wall outlet.

Memory card

You can use a compatible microSD card as extra storage space to save the

memory on your device. You can also back up information from your device

to the memory card.

Insert the memory card

1To insert the memory card, place your finger in the recess

of the door of the memory card slot, and open the door.

2Insert the memory card in the slot. Make sure that the

contact area on the card is facing down and towards the

slot with the bevelled corner facing the base of the

device. Push the card in. You can hear a click when the

card locks into place.

3Close the door. You cannot use the memory card if the

door is open.

Eject the memory card

1Before you eject the card, press the power key, and select Remove mem. card. All applications

are closed.

2When Remove memory card and press 'OK' is displayed, open the door of the memory

card slot.

3Press the memory card to release it from the slot.

4Remove the memory card.

5If the device is switched on, select OK.

Important: Do not remove the memory card in the middle of an operation when the card

is being accessed. Removing the card in the middle of an operation may damage the

memory card as well as the device, and data stored on the card may be corrupted.

Switch the device on

1Press and hold the power button ( ).

2If the device asks for a (U)PIN code or lock code, enter

it, and press . The factory setting for the lock code

is 12345.

Your device has one internal antenna.

Note: As with any other radio transmitting device,

do not touch the antenna unnecessarily when the

device is switched on. Contact with the antenna

affects call quality and may cause the device to

operate at a higher power level than otherwise

needed. Not touching the antenna area during a

phone call optimizes the antenna performance

and the battery life.

• When you switch on the device for the first time, it may ask you to set the following

information: Select current city:, Time:, and Date:. Use the 4-way scroll key, the center

selection key, and the number keys. To find the city, enter the first letters of the city name.

The city you select also defines the time zone for the clock in your device.

• Depending on your service provider, the device might display the message Installing while

installing preloated applications. This will only occur during the first start up.

• Your Nokia N75 normally has MMS, GPRS, streaming, and mobile Internet settings

automatically configured in the device.

• Press to open the main menu.

Your service provider may have requested that certain features be disabled or not activated in

your device. If so, they will not appear on your device menu. Your device may also have been

specially configured. This configuration may include changes in menu names, menu order, and

icons. Contact your service provider for more information.

Connect the audio adapter and headset

Connect the audio adapter AD-41 to the

Pop-PortTM connector of your device, and

connect the headset HS-28 to the adapter.

1Open the connector cover on the device.

2Ensure the connector is ‘upside down’

before connecting to your device. Connect

the audio adapter connector. Do not use

excessive force.

3Connect the headset to the audio adaptor.

Warning: When you use the headset,

your ability to hear outside sounds may

be affected. Do not use the headset

where it can endanger your safety.

Keys and parts (fold open)

Light sensor (1)

Display screen (2)

4-way scroll key (3)

Right selection key ( ) (4)

Multimedia key ( ) (5)

End key ( ) (6)

Clear key ( ) (7)

Keypad (8)

( ) and internet shortcut key (9)

Edit key ( ) (10)

Call key ( ) (11)

Menu key ( ) (12)

Left selection key ( ) (13)

Center selection key ( ) (14)

Earpiece (15)
