Nokia 8810 Quick start guide
Nokia 88xx series and 8210
03.02.00
Copyright ã1995 - 2000. Nokia. All rights reserved. 1(9)
This Quick Guide is a generic guide for all Nokia 88xx series and 8210 phones. When you are asked to select the
modem you will see
Nokia ****
, please select one of the following:
Nokia 8810 Nokia 8810
Nokia 8850 Nokia 8850
Nokia 8210 Nokia 8210
Quick Guide to Using your Nokia Phone with Windows 95 Fax -
Exchange for Windows 95 or Windows Messaging for Windows 95
1. Installing and setting up
This guide assumes that you have already installed your Nokia Phone on your computer.
Microsoft Windows 95 fax support can be installed with the Windows 95 mail application (exchange or messaging -
hereafter called mail in this document).
1. Ensure that you have fax and mail components installed on your computer. This can be done by opening the
Control Panel and clicking ‘Add/Remove Programs’. Select the ‘Windows Setup’ window (Figure 1).
Figure1.InstallingWindows95faxcomponents.
You can install fax support for mail the first time you start mail or later by clicking the mail icon in the Control Panel
or selecting Tools - Services.. in mail.
Copyright ã1995 - 2000. Nokia. All rights reserved. 2(9)
2. If Microsoft Fax does not appear in the Services window, you can install it by clicking the Add…- button and
selecting the Microsoft Fax option in the Add Service to Profile window.
3. Click OK (Figure 2).
Figure2.AddingMicrosoftFaxatWindows95mail.
4. Next you must give the information needed in the fax application. Click the Yes- button shown in Figure 3.
Figure3.Confirmationoffaxsupportinstallationformail.
Copyright ã1995 - 2000. Nokia. All rights reserved. 3(9)
5. Enter the required information (Figure 4.)
Figure4.UserinformationforMicrosoftmail.
6. Select your fax modem from the ‘Available fax modems’ box and click the ‘Set as Active Fax Modem’ button below
(Figure 5).
Copyright ã1995 - 2000. Nokia. All rights reserved. 4(9)
Figure5.Selectthefaxmodemyou wantto use withyourfax.
You may also change the modem’s properties or add a new modem.
Click the ‘Properties..’ button. Set the answer mode to the ‘Answer after # rings’ if you want to receive faxes. Set the
speaker volume control to the off position. Click the ‘Advanced…’ button. You must check ‘Use Class 2 if available’ to
obtain the best functionality - Class 2 is slightly slower than Class 1, but it is more reliable (Figure 6). Close the
Modem properties window and click the ‘OK’ button.
Copyright ã1995 - 2000. Nokia. All rights reserved. 5(9)
Figure6.Modempropertiesand advanced settings.
Now the fax support is installed in your mail application. You have a new menu: Start - Programs - Accessories -
Fax. There you can find the Compose new fax, cover page editor and request a fax applications.
1.1 Sending a fax
After installation you can send a fax from mail by selecting Compose - New Fax or directly from the application, for
example Write, by using Microsoft Fax as default printer (Figure 7). Check that the information in ‘Print to the
following port’ box is correct. The third way to send a fax is to open Start - Programs - Accessories - Fax and
select Compose New Fax.
Copyright ã1995 - 2000. Nokia. All rights reserved. 6(9)
Figure7.SettingMicrosoftFaxasthedefaultprinter.
The fax wizard starts automatically when you send a fax. Fill in the recipient's name and fax number. Click ‘Add to
list’. You may define as many recipients as you want. After that click ‘Next’ (Figure 8).
Copyright ã1995 - 2000. Nokia. All rights reserved. 7(9)
Figure8.Sendingafax.
Then you may select the cover page. After that you may write your message (Figure 9).
Figure9.Selectinga cover page and writingamessage.
Next you may add a text file to your fax. Now your fax is ready to send. Click the ‘Finish’ button.
The progress of the fax transmission will be shown step by step (Figures 10-13).
Copyright ã1995 - 2000. Nokia. All rights reserved. 8(9)
figures10-13.Fax sending process.
Receiving
You must have either the ‘Answer after # rings’ or the ‘Manual answer’ option on, in Fax modem properties, if you
want to receive a fax (Figure 6). If you have a Nokia Phone connected to your computer via IrDA, the phone on and in
service and autoanswer enabled, Microsoft fax will answer incoming fax calls automatically.
Figure14.Microsoft faxreceivingafax
Copyright ã1995 - 2000. Nokia. All rights reserved. 9(9)
LEGAL NOTICE
Copyright © Nokia Mobile Phones 2000. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents of this document in any form without the prior written permission of
Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of the Nokia Corporation. Other product and company names mentioned herein
may be trademarks or tradenames of their respective owners.
Nokia operates a policy of continuous development. Therefore we reserve the right to make changes and improvements to any of the products
described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages
howsoever caused.
The contents of this document are provided "as is". Except as required by the applicable law, no warranties of any kind, either express or implied,
including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy,
reliability or contents of this document. Nokia reserves the right to revise this document or to withdraw it at any time without prior notice.
