Nilfisk-Advance GD 930 Guide

BOOK B

B0.3.3

04-06

SPARE PART LIST - KIT SETS

GD 930 & GD 930S2, UZ 930S & UZ 930S2

DESCRIPTION PLAN

Fan unit & Cord B - 0.3.3 - 3

Filters & Upper parts B - 0.3.3 - 5

Wheels & Lower parts B - 0.3.3 - 7

Nozzles B - 0.3.3 - 9

Hose & Tubes B - 0.3.3 -11

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

FAN UNIT & CORD

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

FAN UNIT & CORD 3

1 140 7902 500 1 Fan unit 230V Suspension & springs 7319519605785

1 140 7902 510 1 Fan unit 110-120V ” 7319519605792

1 140 7902 520 1 Fan unit 240V ” 7319519605808

1 140 7902 530 1 Fan unit 100V ” 7319519605815

1 140 7902 540 1 Fan unit 127V ” 7319519605822

2 140 6423 500 1 Cord 15 m EU-plug Double insulated 7319519631777

2 140 6423 510 1 Cord 10 m EU-plug ” 7319519631784

2 140 6423 520 1 Cord 15 m CH-plug ” 7319519631791

2 140 6423 530 1 Cord 15 m UK-plug ” 7319519631807

2 140 6423 540 1 Cord 10 m UK-plug ” 7319519631814

2 140 6423 550 1 Cord 15m US-plug Double insulated 7319519631821

2 140 6423 560 1 Cord 10m US-plug Grounded 7319519631838

2140 6423 570 1 Cord 15 m JP-plug Double insulated 7319519631845

2140 6423 580 1 Cord 14 m AU-plug ” 7319519631852

3 140 7035 500 1 Sleeve W. anti strain clip 7319519631968

3 140 7035 510 1 Sleeve, UL W. anti strain clip 7319519631975

4 140 7033 500 1 Switch on/off 7319519632613

5 140 7023 500 1 Switch, two speed For S2-versions 7319519632583

6 010 9678 500 1 Electrical outlet 230V 7319519632378

6 140 7665 500 1 Electrical outlet 250V 15A UL-approved 7319519632637

7 140 7012 500 1 Motor plate, W. thermo protector 7319519632521

7 140 7012 510 1 Motor plate, UL W. thermo protector 7319519632538

8 140 7024 500 1 Board anti static 7319519632590

9 140 7026 500 1 Two speed curcuit board 220-240V 7319519629170

9 140 7026 510 1 Two speed curcuit board 100-120V 7319519629187

Pos. No. Part No Qty. Description Note EAN code

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

FILTERS & UPPER PARTS4

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

FILTERS & UPPER PARTS 5

1 140 1515 500 1 Filter main Foam 7319519632385

2 140 3260 500 5 Filter paper 5-pcs. 7319519632415

3 140 7801 500 1 Lid with filter 7319519632651

3 140 7801 510 1 Lid with HEPA-filter 7319519632668

4 140 2666 010 1 HEPA-filter 7319519371475

5 140 1535 500 1 Motor protection With gasket 7319519632392

6 140 7014 500 3 Locking dustbag 7319519632545

7 140 7015 040 10 Dust bag, paper 10 pcs. 7319519400052

7 140 7019 500 1 Cloth dust bag 7319519404692

7 140 7313 020 10 Dust bag 10 pcs. 7319519408188

8 140 7800 500 1 Handle Gasket and 7319519632644

screws

9 140 7020 510 1 Container Chromed 7319519632569

10 140 7832 500 2 Latches 2 snap lockings 7319519632675

w. screws

Pos. No. Part No Qty. Description Note EAN code

NOTE: Container 140 7020 520 is replaced by container 140 7020 510.

05-08

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

WHEEL & LOWER PARTS

05-10

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

WHEEL & LOWER PARTS 7

Pos. No. Part No Qty. Description Note EAN code

1 140 7010 500 1 Stand 7319519632460

1 140 7010 510 1 Stand S2 version 7319519632477

1 140 7010 530 1 Stand UL-listed 7319519632484

1 140 7010 540 1 Stand S2 version UL-listed 7319519632491

2 140 7011 500 1 Base and bumber 7319519632507

2 140 7011 510 1 Base and bumber UL-listed 7319519632514

3 140 5055 500 2 Wheel rear 2-p 2 wheels and 7319519632439

2 washers

4 140 7025 500 1 Wheel front 1 wheel 7319519632606

5 >>140 5058 500 6 Lock washers 6 pcs. 7319519652796

05-10

>> Means: New or changed ref. number or/and changed/new specifications

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

NOZZLES Ø 32 MM8

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

NOZZLES Ø 32 MM 9

1 140 7087 500 1 Combi nozzle Colour: Black 7319519632620

2 140 5634 500 1 Combi nozzle Colour: Black 7319519632453

3 010 3098 500 1 Crevice nozzle Colour: Black 7319519629156

4 011 3104 500 1

Small combi nozzle

Colour: Black 7319519629163

Pos. No. Part No Qty. Description Note EAN code

BOOK B

B0.3.3

04-06

SPARE PARTS GD 930 & GD 930S2, UZ 930S & UZ 930S2

HOSE & TUBES Ø 32 MM10
