Nilfisk-Advance MX 307 H Operating instructions

11-600203072REVA

MX 307 H

EXTRACTOR

220 - 240V

CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ

ALL SECTIONS OF THIS INSTRUCTION MANUAL

INFORMATION

OPERATING

INSTRUCTIONS

20122007

11-600203072REVA

IMPORTANT SAFETY INSTRUCTIONS

This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops,

and offices other than normal residential housekeeping purposes.

When using any electrical appliance, basic precautions should always be followed, including the following:

NOTE: Read all instructions before using this machine.

WARNING!

To reduce the risk of fire, electric shock, or injury:

•Do not leave the machine unattended when it is plugged-in. Unplug the unit from the power outlet when

not in use.

•Unplug the machine from the power outlet before cleaning or servicing.

•To avoid electric shock, do not expose to rain or snow. Store, and use, indoors.

•Wear hearing protection if desired. The measured sound level of the MX 307 H is 79dB(A).

•Do not allow to be used as a toy. Close attention is necessary when used near children.

•Use only as described in this manual. Use only the manufacturer’s recommended attachments.

•Inspect the power cord regularly for damage, such as cracking, ageing, or damaged insulation. Replace

the power cord with the same type as original if any damage is found. Do not use with damaged cord or

plug.

•Do not use the power recepticles on the machine for any use other than to operate the machine.

•If the machine is not working as it should, has been dropped, damaged, left outdoors or flooded with

water, return it to a service center.

•Do not pull the machine by the cord, do not use the cord as a handle, close a door on the cord, or pull

the cord around sharp edges or corners. Do not run the machine over the cord. Keep the cord away

from heated surfaces. To unplug, grasp the plug, not the cord.

•Do not handle the plug, the cord, or the machine with wet hands.

•Extension cords must be 12/3 and no longer than 50 feet. Replace the cord or unplug immediately if the

ground prong becomes damaged.

•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair,

and anything that may reduce air flow.

•Keep loose clothing, hair, fingers, and all parts of body away from openings and moving parts.

•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes, or any

health endangering dusts. Do not use to pick up flammable or combustible liquids such as gasoline or

use in areas where they may be present.

•Turn off all controls before unplugging.

•Use extra care when cleaning on stairs.

•Liquid ejected at the spray nozzle could be dangerous as a result of its temperature, pressure,or

chemical content.

11-600203072REVA

INSPECTION:

Carefully unpack and inspect your MX 307 H for shipping damage. Each machine is tested and

inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You

should notify the carrier immediately if you notice damage to the box or to the machine or parts.

CLEANING SOLUTIONS:

We recommend liquid cleaning chemicals. Powder chemicals may be used, but unless mixed very

thoroughly they could cause a build-up in the pump, lines, heat exchanger and/or quick disconnects.

Any problem caused by a chemical build-up is not covered by warranty. Use a neutral cleaner with a

pH between 6 and 9 to avoid premature wear of the pump, seals, and/or other components.

Damage caused by the use of strong chemicals is not covered by the warranty.

MAINTENANCE:

For optimum performance flush the machine with clear water at the end of each working day. Once

a month, minimum, run a flushing compound through the machine to break up any mineral or

chemical build-up that may have formed. The vacuum motors and the pump do not require any

scheduled maintenance; however, the vacuum motors may require replacement brushes after 1000 -

1500 hours. Clean the body with an all purpose detergent, and protect it with an automobile interior

polish. Lubricate the wheels, castors, and quick disconnects with an all purpose silicone spray.

Serial Number: __________________

Model: MX 307 H

Purchase Date:_____________

Write the name and phone number of your

distributor:

_____________________________________

RECORD AND KEEP THE FOLLOWING INFORMATION

(anddon’tforgettoregisteryourwarranty)

11-600203072REVA

NILFISK LABEL

MACHINE DESCRIPTIONS

Operator Handle (1) - Operator holds this to move the machine from one location to another.

Solution Tank Lid (2) - Fill Solution Tank here with warm water and chemicals.

Switch Plate (3) - This is where the switches are located that operate the pump, vacuum and heater.

Recovery Tank Lid (4) - The Recovery Tank can be flushed out by running clean water into this opening

withtheDrainGate(7) open. ThevacuumfloatShut-OFFcanalsobeaccessedthroughthisopeningfor

maintenance.

Vacuum Inlet (5) - This is where the vacuum hose attaches to the machine.

Latch (6) -Open the latches to access the base compartment, which contains the motors and heater.

Drain Gate (7) -Open this gate to drain the recovered solution out of the machine. Be sure to keep this

gateclean.

Castor (8) -Thecastorswivelsforeasy maneuvering in tight spots.

Wheel (9) -Large,non-markingwheelsforeaseof transport.

Power Cord(10) -One, 25 foot cord. Do not use if the cord is damaged.

BECOME FAMILAR WITH YOUR NEW EXTRACTOR

11-600203072REVA

CAUTION!

If water or foam comes out of the

vacuum exhaust, turn the machine off immediately

OPERATION

1Inspect the machine, hoses, and cleaning tools for cleanliness and completeness.

2Fill the Solution Tank with warm water. Using warm water may be a benefit in cleaning

effectiveness, but do not use hot water (above 54°C / 130°F+) in the tank. Add liquid cleaning

solution with a pH value of between 6 and 9. High pH detergents and/or acid rinses will

accelerate the wear of the seals and will void the warranty.

3Plug in the power cords. Turn the Heat switch on.

4Attach the spray hose to the solution quick disconnect on the front of the machine and attach

the vacuum hose to the hose barb on the recovery tank. Attach the other ends of the hoses to

the cleaningtool.

5Allow the heat exchanger two minutes to reach operating temperature.

6Turn the pump on. Turn the vacuum on. NOTE: the pump has a built in pressure switch; the

pump runs only while you are spraying.

7Begin cleaning using the correct hoses and tool.

8Use defoamer in the recovery tank any time foaming occurs.

9Monitor the water level in the solution tank. Do not let the pump run dry.

10 When the solution tank gets low, turn off the pump, fill the solution tank, empty and clean the

recovery tank.

11 When finished with the job, remove any unused solution from the solution tank, and run a few

gallons of clean water through the system to rinse out any detergent.

BALL FLOAT VACUUM SHUT-OFF

Prior to using the machine, always check that the float filter is clean and the ball can travel freely.

When the recovery tank is full, the ball float will rise and will shut off the vacuum flow to prevent any

more water from entering the tank. Turn off the vacuum, and empty the recovery tank.

NOTE: if foam is present or if the ball float is prevented from rising, the float will not be able to stop

the air flow, and the tank may over fill.

CAUTION!

To avoid vacuum motor damage, always make sure the float filter is clean and the ball can travel

freely prior to using the machine. And always use a defoamer when foaming occurs.

11-600203072REVA

20 18

20 December 2007

Nilfisk Label

MX 307 H

11-600203072REVA

MX 307H EXTRACTOR

PART LIST

220 - 240V

1 1 600730701 Lid kit, vac tank and holding tank

2 1 600730703 Heat system replacement kit, 1600W

4 1 600730704 Switch kit

5 1 600730705 Filter kit

6 1 600730706 Holding tank kit

7 1 600730707 Pump kit

8 1 600730708 Vacuum motor kit

9 1 600730709 Vacuum hose kit, internal hoses

10 1 600730710 Ball float & manifold kit

11 1 600730711 Vacuum tank

12 1 600730712 Vacuum inlet kit

13 1 600730713 Drain Gate kit

14 1 600730714 Latch kit

15 1 600730715 Louver kit

16 2 600730716 Castor kit

17 1 600730717 Wheel kit

18 1 600730718 Base

19 1 600730722 Power cord kit, UK plug

600730719 Power cord kit, EU plug

20 1 600730720 Gasket

21 1 600730721 Heat repair kit

23 1 600730723 Label Kit

24 1 600730724 Fuse kit

25 1 600730725 Switch plate

26 1 600730726 QD kit

27 1 600730727 RFI filter

ITEM QTY PART No. DESCRIPTION

11-600203072REVA

TROUBLESHOOTING

CHECK THIS

Solution tank is empty.

Cloggedspraytip.

Pumpnot running.

Valveontoolnot operating.

Solution path is plugged. Pump should only run while spraying.

Solution tank may be empty, or nearly empty.

No power to pump. Test the switch. Test the pump motor.

Partiallypluggedsolutionpath(hose, heater, tool).

Worn pressure switch in pump. Adjust pressure sensor in pump head.

Debrismaybepluggingthe cleaning tool or vacuum hose.

Drain gate is not completely closed, or seals are damaged.

Internalvacuumhose is cracked.

Recovery tank lid is not closed, is cracked, or gasket is damaged.

Debrisimpeding air movement onvacmotor impellors.

No power to motor. Test the switch. Test the vacuum motor.

Trying to spray too long. Try spraying for 10 - 12 seconds per cycle

Heatexchangerneeds to be flushed

Wrong tool being used. Too much water passing through

Longerhose, or larger diameter hose,thanstandard

Heat switch is off

No power in the wall outlet — check to see if breaker has tripped

Check to see if the fuse has blown.

No power to heat switch — check power cord for ‘opens’

No power out of heat switch. Check power at Bi-metalic switch

Follow troubleshooting steps to isolate the problem. Call your distributor.

IF PROBLEM OCCURS

NOSPRAY

PUMP

DOESN’T

RUN

PUMP

PULSATES

LOW

SUCTION

NOSUCTION

LOW

HEAT

Ifyou are unable to diagnosethe problem, contact the companyfrom whom you purchasedyour MX 307H

SPECIFICATIONS:

Rotomolded Body:

Vacuum:

Heat Exchanger:

VAC Shutoff:

Pump:

Suction:

Weight:

Dimensions:

Lifetime Warranty

3-stage

1600 W

Ball float

7 Bar / 100 psi, demand

28 KPA

34.3 Kg

79 X45 X 86 cm

ALWAYS UNPLUG THE MACHINE

BEFORE DISCONNECTING OR

CONNECTING ANY WIRES OR

COMPONENTS.

11-600203072REVA

MX 307 H

EXTRACTOR

220- 240V

NOTES:

MAINTENANCE SCHEDULE

CLEANALLFILTERS X

FLUSH OUT with DESCALER

DAILY

WEEKLY

MONTHLY

OTHER

CHECK POWER CORD

REPLACE VAC MOTOR BRUSHES

YEARLY

Around1500hours

11-600203072REVA

MX 307 H

EXTRACTEUR

220-240V

PRUDENCE : N’UTILISEZ PAS LA MACHINE AVANT D’AVOIR LU

TOUTES LES SECTIONS DU PRÉSENT MANUEL

INFORMATIONS

& MODE

D’EMPLOI

20122007

Other manuals for MX 307 H

Table of contents

Languages:

Other Nilfisk-Advance Scrubber manuals

Nilfisk-Advance

Nilfisk-Advance SC530 53 BD GO User manual

Nilfisk-Advance

Nilfisk-Advance Liberty SC60 User manual

Nilfisk-Advance

Nilfisk-Advance ATTIX 751-0H EU User manual

Nilfisk-Advance

Nilfisk-Advance SC350 User manual

Nilfisk-Advance

Nilfisk-Advance Convertamatic 24 User manual

Nilfisk-Advance

Nilfisk-Advance Advance SC400 User manual

Nilfisk-Advance

Nilfisk-Advance SC450 User manual

Nilfisk-Advance

Nilfisk-Advance SC800 User manual

Nilfisk-Advance

Nilfisk-Advance Retriever 4000B User manual

Nilfisk-Advance

Nilfisk-Advance HSC 585 Operating instructions

Nilfisk-Advance

Nilfisk-Advance Advance SC370 User manual

Nilfisk-Advance

Nilfisk-Advance BA 5321 User manual

Nilfisk-Advance

Nilfisk-Advance ROS1300 User manual

Nilfisk-Advance

Nilfisk-Advance SC6500 Parts list manual

Nilfisk-Advance

Nilfisk-Advance ECOFLEX BR1100S User manual

Nilfisk-Advance

Nilfisk-Advance Advance SC750 ST User manual

Nilfisk-Advance

Nilfisk-Advance Advance BR 1100S Operating and installation instructions

Nilfisk-Advance

Nilfisk-Advance SC401 Series User manual

Nilfisk-Advance

Nilfisk-Advance SW8000 Installation and user guide

Nilfisk-Advance

Nilfisk-Advance Advolution UHR 70-1700 User manual

Nilfisk-Advance

Nilfisk-Advance Advance Condor 56413000 User manual

Nilfisk-Advance

Nilfisk-Advance SW4000 User manual

Nilfisk-Advance

Nilfisk-Advance SC500 User manual

Nilfisk-Advance

Nilfisk-Advance MX 107 C User manual

Popular Scrubber manuals by other brands

Olympus

Olympus M200H operating manual

Clarke

Clarke BEXT 100H Operation?and safety

JOHNY VAC

JOHNY VAC JVC70BCT user guide

RCm

RCm Elan Series Instruction and maintenance handbook

Kärcher

Kärcher B 120 W quick start

Truvox

Truvox Orbis MotorScrubber 20 user manual

Numatic

Numatic TTB 4045/100 Original instructions

U.S. Products

U.S. Products PEX 500-C-TICK Information & operating instructions

Mclennan

Mclennan C510 Operator's manual

Tennant

Tennant T20 LPG Operator's manual

Columbus

Columbus ARA 66 BM 100 operating manual

Numatic

Numatic TTV 678G / 300T Owner's instructions

American-Lincoln

American-Lincoln 505-945 Instructions for use

FIORENTINI

FIORENTINI ET 65-75 user manual

Floorpul

Floorpul ruby 48 blt Use and maintenance

Onyx

Onyx RX-34 Operator's manual

Dustbane

Dustbane Hurricane 400 Operation manual

Sana

Sana EUJ-702 user manual
