1. Introduction
R718UBB all-in-one series is a ClassAtype testing device based on LoRaWAN open protocol of Netvox, which can support multiple
combinations of temperature and humidity, CO2, vibration, atmospheric pressure and illumination sensors, and is compatible with
LoRaWAN protocol.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other
communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance. Widely
used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation device,
wireless security systems, industrial monitoring. Main features include small size, low power consumption, transmission distance,
anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and
gateways from different manufacturers.
The specific model of R718UBB all-in-one is shown in the following table:
UBB represents the basic function of battery power CO2
“1” represents temperature and humidity,
“2” represents vibration
“3” represents air pressure
“5” represents light
Device Model Product functions
R718UBB CO2
R718UBB1 CO2, temperature and humidity
R718UBB12 CO2, temperature and humidity, vibration
R718UBB123 CO2, temperature and humidity, vibration, air pressure
R718UBB23 CO2, vibration, air pressure
R718UBB25 CO2, vibration, light
R718UBB125 CO2, temperature and humidity, vibration, light
R718UBB235 CO2, vibration, air pressure, light
R718UBB1235 CO2, temperature and humidity, vibration, air pressure, light
