NETGEAR ProSafe GS504 User manual

The GS504 Gigabit Fiber Switch is a high performance network switch that provides back-

bone connectivity for power workgroups,data centers,and server farms.It delivers the power

of Gigabit Ethernet to speed up network performance while preserving ease of use and plug

and play installation for the small business users. Once again, NETGEAR is making the

latest network technology available and affordable

for the small business market.

™

NETGEAR

Easy to install and use

The unit is plug and play with no software to

install and no complicated options to configure.

It preserves 10 and 100 Mbps Ethernet investment

via 10/100 switches with Gigabit uplink ports

such as the NETGEAR FS509 and FS518, and

is compatible with all major network software

and protocols.

Free 24-hour phone support

Free 7x24 technical support provided in English,

with local language support during office hours in

selected countries.This service ensures support

when you need it.

4 full-duplex Gigabit fiber ports

This network switch provides high-performance

backbone connectivity between workgroups, data

centers, and server farms. Multiple 100 Mbps users

can concurrently access the backbone and servers

without network congestion.

Powerful network switch

The GS504 is a nonblocking switch providing an

aggregate throughput of up to 5.9 million packets

per second and supporting 8,000 users or devices

on the network.It uses multimode fiber optics

technology to provide high security and a network

reach of up to 260 meters.

4 PORT

1000 GigabitFiberSwitch

Mbps GS504

MODELS

KEY FEATURES

•4 full-duplex Gigabit

fiber ports

•Powerful network

switch

•Easy to install and use

•Free 24-hour phone

support

GIGABIT

PERFORMANCE

EASY

INSTALLATION

1000BASE-

FIBER

www.NETGEARinc.com

NETGEAR™is a trademark of Bay Networks, Inc. Other brand and product

names are trademarks or registered trademarks of their respective holders.

Standards Compliance

IEEE 802.3z 1000BASE-SX Gigabit Ethernet

Network Port

Four Gigabit duplex SC connector for 62.5/125 or 50/125 multimode fiber

Status LEDs

Unit power

Per network port link, activity,full duplex/collision

Dimensions

W 330 mm (13”)

D 207 mm (8.2”)

H 43 mm (1.7”)

Weight

2.4 kg (5.3 lb)

AC power

25 W 100-240 volt AC

Localized power cord for North America, Japan,UK,Europe, Australia

Performance (64 byte packets)

Filter rate 1,480,000 packet per sec

Forward rate 1,480,000 packet per sec

Latency 30 usec max

MAC addresses 8,000

Environmental Specifications

Operating temperature:0°C to 40°C

Operating humidity: 90% max. relative humidity,non-condensing

Electromagnetic Compliance

CE mark, commercial

FCC Part 15 Class A

VCCI Class A

EN 55022 (CISPR 22), Class A, EN 50082-1

C-Tick

TUV EN 60950

Safety Agency Approvals

UL listed (UL 1950)/cUL

IEC950/EN60950

Warranty

Switch - 5 years

Power supply - 1 years

PACKAGE

CONTENTS

•Switch

•Power cord

•Rack-mount kit

•User guide

•Warranty card

•Support phone card

SPECIFICATIONS

•

ISO-9001

REGISTERED

QUALITY

NETGEAR Inc.

A Bay Networks Company

4401 Great America Parkway

Santa Clara,CA 95054

USA

Phone: 1-888-NETGEAR

www.NETGEARinc.com

Technical Support

Australia 1800-14-20-46

Austria 00800-06384327

Denmark 808-82179

Finland 0800-111-036

France 0800-771-753

Germany 00800-06384327

Holland 0800-023-0981

Japan 0120-66-5402

Korea 00308-11-0319

New Zealand 0800 444 626

Norway 800-12041

Sweden 020-790086

Switzerland 00800-06384327

UK 171-571-5120

US/Canada 1-800-211-2069

August 1999 www.NETGEARinc.com

FS518

MODEL

FastEthernet Switch

16PORT

10/100Mbps

Tx Rx FS509

MODEL

FastEthernet Switch

9PORT

10/100Mbps

Ethernet

GS504SX

MODEL

GigabitFiber Switch

4PORT

10/100Mbps

Ethernet

GS504 switch

FS509 switchFS518 switch

Key

1000 Mbps

100 Mbps

10 Mbps

PCs PCs

Server Server with GA620

Gigabit network card
