NETGEAR Nighthawk AC1900 R7000 User manual
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134 USA
August 2013
Trademarks
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks
and/or registered trademarks of NETGEAR, Inc. and/or its subsidiaries in the
United States and/or other countries. Information is subject to change without
notice. © NETGEAR, Inc. All rights reserved.
Compliance
For the current EU Declarations of Conformity, visit
http://support.netgear.com/app/answers/detail/a_id/11621/.
Nighthawk
AC1900 Smart WiFi Router
Model R7000 Installation Guide
Package Contents
The box contains the following items.
In some regions, a resource CD is included in the package.
Installation Video
To view the Nighthawk installation video, visit
http://www.netgear.com/R7000_QR_IG_EN
or use this QR code:
Ethernet cable
Nighthawk AC 1900 Smart WiFi Router
Power adapter
Antennas (3)
You can use this diagram to connect your router or follow the detailed instructions in this booklet.
2. Prepare your modem.
3. Connect your modem.
Unplug your modem’s power. If it has a battery
backup, remove the battery.
Plug in your modem. Put the battery
back in. Then cable the modem to
the router Internet port.
Modem
Internet
Router
DSL or cable
5. Connect a computer.
4. Power on the router.
6. Launch a browser.
The Power LED lights amber and then turns white
when the router is ready.
You can use an Ethernet cable or connect with WiFi.
To connect with WiFi, use the WiFi network name and
password on the router label.
NETGEAR genie displays.
Follow the genie steps to connect to the
Internet.
If you do not see genie, type
www.routerlogin.net. Then type admin
for the user name and password as the
password.
1. Attach the antennas.
Attach the antennas on the
threaded antenna posts.
Position the antennas for the best
WiFi performance.
NETGEAR recommends that the
center antenna be vertical and that
you aim the others outward at 45
degree angles, as shown.
Download the free genie app from
www.NETGEAR.com/genie.
Get the genie app.
Easily share media, files, and
printers on the network from your
smartphone, tablet, or laptop.
Support
Thank you for selecting NETGEAR products.
After installing your device, locate the serial number on the label of
your product and use it to register your product at
https://my.netgear.com.
You must register your product before you can use NETGEAR
telephone support. NETGEAR recommends registering your product
through the NETGEAR website.
For product updates and web support, visit
http://support.netgear.com.
NETGEAR recommends that you use only the official NETGEAR
support resources.
You can get the user manual online at
http://downloadcenter.netgear.com or through a link in the product’s
user interface.
1
Contents
Install Your Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1. Attach the antennas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. Prepare your modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3. Connect your modem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4. Add power to the router. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
5. Connect a computer.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6. Launch a web browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
WiFi Network and Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Join the WiFi Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
View or Change the Router Settings . . . . . . . . . . . . . . . . . . . . . . . . 8
Prioritize with Quality of Service . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Share a USB Drive on the Network . . . . . . . . . . . . . . . . . . . . . . . . 12
NETGEAR genie App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
ReadySHARE Vault Backup App . . . . . . . . . . . . . . . . . . . . . . . . . 14
Share a USB Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
More Premium Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2
Install Your Router
Make sure that your Internet service is active before you install your
router.
To install your router:
1. Attach the antennas.
a. Align the antennas with the antenna posts on the router.
b. Attach the antennas on the threaded antenna posts.
c. Position the antennas for the best WiFi performance.
NETGEAR recommends that the center antenna be vertical
and that you aim the others outward at 45 degree angles, as
shown.
2. Prepare your modem.
a. Unplug your modem’s
power.
b. If the modem has a battery
backup, remove its batteries.
c. If your modem was already
connected to another router,
disconnect the cable
between your modem and
that router.
Internet
DSL or cable
Modem
3
Make sure that your modem is turned off and is cabled only to the
wall jack for your Internet service.
3. Connect your modem.
a. Plug in, then turn on your modem. (Replace the batteries if
you removed them previously.)
b. With the yellow Ethernet cable that came with the router,
connect your modem to the Internet port of your router.
4. Add power to the router.
a. Connect the power adapter to the router, and plug the power
adapter into an outlet.
Router
Modem
On/Off
4
b. Wait for the Power LED on the front panel to light amber
and turn white. If no LEDs are lit, press the Power On/Off
button on the rear panel of the router.
5. Connect a computer.
You can use an Ethernet cable or connect with WiFi:
•For a wired connection, use an Ethernet cable (not included)
to connect your computer to a black Ethernet LAN port on
your router.
•To connect with WiFi, use the WiFi settings on the router
label.
6. Launch a web browser.
The first time that you connect to the router, the genie screen
displays. Follow the genie steps to connect to the Internet.
If the genie screen does not display, try the following:
•Close and reopen the browser.
•Make sure that your computer is connected to one of the four
black LAN Ethernet ports on the router, or that you are
connected to your WiFi network.
•Make sure that the router has full power, and that its Power
LED is lit.
5
•If your computer is set to a static or fixed IP address (this is
uncommon), change it to obtain an IP address automatically from
the router.
If you still do not see the genie screen, log in to the router so that
genie can detect your Internet connection.
To log in to the router:
1. In the address field of your web browser, type
www.routerlogin.net or www.routerlogin.com.
A login screen displays.
2. Enter admin for the user name and password for the password.
The router BASIC Home screen displays. If your Internet
connection is not set up yet, genie automatically detects your
Internet connection.
LEDs
The LEDs on the top of the router light to indicate router activity:
Power
Internet
2.4 GHZ WiFi
5 GHZ WiFi
USB 1 (USB 3.0 port on the front panel)
USB 2 (USB 2.0 port on the rear panel)
Ethernet ports 1–4
WiFi On/Off button with LED
WPS button with LED
6
WiFi Network and Security
The preset WiFi network name (SSID) and network key (password)
are unique to your router, like a serial number. Because the router
automatically uses WiFi security, you don’t need to set it up. The WiFi
settings are on the label.
NETGEAR recommends that you use the preset WiFi settings
because you can check the router label if you forget them. NETGEAR
genie lets you change these settings if you want. If you do so, write
down the new WiFi settings and store them in a safe place.
You can write the WiFi settings from your router’s label in this space
for easy reference.
WiFi network name (SSID):
Network key (password):
If you change the WiFi settings, write the new settings here for easy
reference and store this booklet in a safe place.
WiFi network name (SSID):
Network key (password):
7
Join the WiFi Network
You can either use Wi-Fi Protected Setup (WPS) or select your WiFi
network and type its password.
To join the network using WPS:
1. Press the WPS button on the router.
2. Within two minutes, on your computer or wireless device, press its
WPS button or click its onscreen WPS button.
For help with the WPS button on your computer or wireless
device, check the instructions or online help that came with that
computer or device. Some older equipment cannot use WPS.
To select your network and enter its password:
1. On your computer or wireless device, open the software that
manages its WiFi connections.
This software scans for WiFi networks in your area.
2. Find and select your WiFi network.
The WiFi network name and password are on the router’s label.
3. Enter the WiFi password and click the Connect button.
8
View or Change the Router Settings
After you use genie to set up the router, you can log in to the router to
view or change its settings.
Log In to the Router
To log in to the router:
1. Connect a computer or wireless device to the router.
You can use an Ethernet cable or connect with WiFi.
•For a wired connection, use an Ethernet cable (not included)
to connect your computer to a black Ethernet LAN port on
your router.
•To connect with WiFi, select and join your WiFi network.
2. Launch a web browser.
3. Type www.routerlogin.net in the address field of the browser.
A login screen displays.
4. Enter admin for the user name and password for the password.
The router BASIC Home screen displays.
Change the Admin Password
To change the admin password:
1. Log in to the router.
2. Click the ADVANCED tab.
3. Select Administration > Set Password.
4. Type your old password and type the new password twice.
5. Select the Enable Password Recovery check box.
6. Click the Apply button.
7. When prompted, answer security questions.
The answers are saved.
