NeoMounts Floor stand User manual

FPMA-W820

TV wall mount

TV wandsteun

TV Wandhalterung

Support mural pour TV

Supporto TV a parete

Soporte de pared para TV

Suporte de parede para TV

Vægbeslag TV

TV veggfeste

TV-väggfäste

TV seinäteline

Uchwyt ścienny do TV

Nástěnný držák na TV

Nástenný držiak na TV

Suport TV de perete

±45°0°

180°

15.5mm 193mm

50mm-247mm

38.5mm

170mm

100mm

75mm

45mm

75mm

100mm

WWW.NEOMOUNTS.COM

INSTRUCTION MANUAL

PARTS

FPMA-W820

Tool Drill

75x75 -

100x100 mm

0-15 kg

5-25 cm

Install the wall mount on a stud wall

Bevestig de muurbeugel aan een houten balk

Befestigen Sie die Halterung an einem Holzbalken

Installez la plaque murale sur un mur en bois ou en

plaque au platre

Installare la piastra di parete su un perno in legno

Fije el soporte de pared a una viga de madera

Instale a placa so suporte de parede num poste de

madeira

Zamontuj płytę ścienną do drewnianej powierzchni

Install the wall mount on a solid brick or concrete wall

Bevestig de muurbeugel aan een stevige stenen of

betonnen muur

Installieren Sie die Halterung an einer soliden Ziegel-

oder Betonwand

Installez la plaque murale sur un mur de brique ou de

béton

Installare la piastra di parete su un muro di mattoni o

cemento

Fije el soporte de pared a una piedra sólida o muro de

hormigón

Instale a placa do suporte de parede numa parede só-

lida de tijolo ou betão

Zamontuj płytę ścienną do ściany z cegły lub betonu

A. (x1)

B. (x1) M-A. M4x14

(x4)

M-B. M5x14

(x4)

M-C. D5

(x4)

W-A. (x2) W-B. (x2)

W-A

W-B

STEP 1A

STEP 1B

* Not Included

Attach the screen to the bracket

Bevestig het scherm op de beugel

Befestigen Sie den Bildschirm an die Halterung

Attachez l'écran au support

Fissare lo schermo alla staffa

Coloque la pantalla en el soporte

Fixar o ecrã ao suporte

Przymocuj ekran do uchwytu

Adjust the torque

Stel het koppel in

Einstellen des Drehmoments

Réglage du couple

Regolazione della coppia

Ajuste el tornillo

Ajustar os parafusos

Regulacja momentu obrotowego

Adjust the screen to your desired position

Stel de steun in op de gewenste positie

Positionieren des Monitors in der gewünschten

Position

Réglez l'écran à la position désirée

Regolare lo schermo nella posizione desiderata

Ajuste la pantalla a la posición deseada

Ajuste a tela na posição desejada

Dostosuj pozycję ekranu do twoich wymagań

STEP 3

STEP 2

STEP 4

M-A

M-C

M-B

+45°

-45°

180° 180°

24.01
