NEFF B1322W0GB Safety guide

How to connect up,

build-in, set up, use and

look after your

B1322 oven

NEFF (UK) Ltd

Table of contents

Important Information . . . . . . . . . . 3

Packaging and old appliances . . . . . 3

Before installation . . . . . . . . . . . . . . 4

Safety information . . . . . . . . . . . . . . 4

Reasons for damage . . . . . . . . . . . . 5

Your new cooker . . . . . . . . . . . . . . 6

The control panel . . . . . . . . . . . . . . . 6

Function selector . . . . . . . . . . . . . . . 6

Temperature selector . . . . . . . . . . . . 7

Slide-in levels . . . . . . . . . . . . . . . . . . 7

Accessories . . . . . . . . . . . . . . . . . . 8

Before using your Appliance

for the first time . . . . . . . . . . . . . . . 9

Preliminary cleaning . . . . . . . . . . . . . 9

Initial burn-in . . . . . . . . . . . . . . . . . . 9

Time of day . . . . . . . . . . . . . . . . . . . 9

Electronic clock . . . . . . . . . . . . . . . 10

The control panel . . . . . . . . . . . . . . . 10

Minute timer . . . . . . . . . . . . . . . . . . 10

Automatic timer . . . . . . . . . . . . . . . . 11

Special functions . . . . . . . . . . . . . . . 12

Description of Oven Features . . . . 13

Switching the oven ON and OFF . 14

Inhaltsverzeichnis

Baking . . . . . . . . . . . . . . . . . . . . . . 15

Cooking Tips and Helpful Hints . . 16

Roasting . . . . . . . . . . . . . . . . . . . . . 17

Grilling . . . . . . . . . . . . . . . . . . . . . . 19

Surface grilling . . . . . . . . . . . . . . . . . 19

Defrosting and Cooking . . . . . . . . 20

Cleaning and Care . . . . . . . . . . . . . 22

Important cleaning basics . . . . . . . . 22

Catalytic oven surfaces . . . . . . . . . . 24

Removing/installing

the oven door . . . . . . . . . . . . . . . . . 25

Inset rack . . . . . . . . . . . . . . . . . . . . 26

Service and Repair information . . 27

Trouble-shooting Guide . . . . . . . . . 28

Assembly instructions

For the installer

and kitchen expert

Important installation notes . . . . . 30

Installation of the built-in oven . . . 31

Important information

Before using your new appliance, please read these

Instructions for Use carefully. They contain important

information concerning your Personal safety as well

as on use and care of the appliance.

The Instructions for Use apply to several versions of

this appliance. Accordingly, you may find

descriptions of individual features that do not apply

to your specific appliance.

Please keep the operating and installation

instructions in a safe place; this important

documentation may also be of use to a possible

subsequent owner.

Packaging and Your new appliance was protected by suitable

old appliances packaging while it was on its way to you. All materials

used for this purpose are environmentally friendly and

can be recycled. Please make a contribution to

protecting the environment by disposing of the

packaging appropriately.

Old appliances are not worthless rubbish.

Environmentally-conscious recycling can reclaim

valuable raw materials.

Before disposing of your old appliance, please make

sure that it is unusable, or label it with a sticker

stating „Caution, scrap”.

This appliance is labelled in accordance with

European Directive 2002/96/EG concerning used

electrical and electronic appliances (waste electrical

and electronic equipment – WEEE). The guideline

determines the framework for the return and

recycling of used appliances as applicable

throughout the EU.

Up-to-date information on how to dispose of your

old appliance and the packaging from the new one

can be obtained from your retailer or local authority.

Before installation

Transport damage Check the appliance after unpacking it. Do not

connect the appliance if it has been damaged in

transport.

Electrical connection The cooker may only be connected by an approved

specialist. Losses resulting from damage caused by

incorrect connection will invalidate warranty claimes.

Safety information This appliance is intended for domestic use only.

Only use the cooker for food preparation.

Hot oven Open the oven door carefully. Hot steam may escape.

Never touch the internal surfaces of the oven or the

heating elements. There is a risk of burning.

Children must be kept at a safe distance from the

appliance.

Never store combustible items in the oven.

Risk of fire. Never place flammable objects onto the

hot plates. Fire hazard!

Never place cables of electronic devices onto the hot

plates.

Never clamp leads of electrical appliances in the hot

oven door. The insulation on the leads could melt.

There is a risk of short-circuiting.

Remove all packaging remnants, e.g. polystyrene

parts, from the oven.

Repairs Incorrectly done repairs are dangerous. There is a

risk of electrocution.

Repairs may only be carried out by after-sales

service technicians who have been fully trained by

BSH.

If there is a fault, switch off the oven fuse at the fuse

box.

Call the after-sales service.

Reasons for

damage

Baking tray, aluminium foil Do not place the baking tray on the oven floor.

or dishes on the oven floor Do not cover it with aluminium foil.

Do not place dishes on the oven floor.

This will cause heat accumulation. The baking and

roasting times will no longer be correct and the

enamel will be damaged.

Baking paper If using circotherm *, do not place greaseproof

paper loosely in the oven (e.g. when heating the

oven).

The hot-air fan could draw in the paper which may

damage the heater and fan.

Water in the oven Never pour water directly into a hot oven.

This could damage the enamel.

Fruit juice When baking very moist fruit cakes, do not put too

much on the baking sheet. Fruit juice dripping from

the baking sheet leaves stains that cannot be

removed.

It is recommended that you use the deeper universal

pan.

Cooling with the oven door Only leave the oven to cool with the door closed. Do

not allow anything to become trapped in the oven

door. Even if you only leave the oven door open

slightly, the fronts of adjacent units may become

damaged over time.

Very dirty oven seal If the oven seal is very dirty, the oven door will no

longer close properly when the oven is in use.

The fronts of adjacent units could be damaged.

Keep the oven seal clean.

Using the oven door as a Do not stand or sit on the oven door.

seat

Care and cleaning Do not use high-pressure cleaners or steam jets.

Hotplates Keep an eye on pressure cookers during the heat-up

phase. As soon as the proper cooking pressure is

reached, reduce the heat setting.

Please observe the separate operating instructions

that came with your hob.

Electronic clock

Your new cooker

Here you will learn more about your new oven. The

control panel and its switches and indicators are

explained here. The heating modes and the

accessories included with your oven will be

explained here.

The control panel

Function selector Use the function selector to select the type of

heating for the oven.

Settings

Circotherm

)

Surface grilling, large area grill

Defrosting position

Oven light

Function

selector

Function

selector

Rotary

knob

Temperature selector

Settings

50 –275

Temperature in °C.

Slide-in levels Your oven features 4 slide-in levels. The slide-in

levels are counted from bottom to top.

The numbers are marked in the oven.

When using circotherm baking *or roasting, do

not use slide-in level »2«, in order not to block air

circulation.

Accessories Your appliance is supplied with:

Universal pan with grid Grid

Additional accessories can be obtained from a specialist dealer.

Before ordering, please check the Neff sales literature to

confirm which of the following items are available in the UK: Order no.

Note:

The guard prevents contact with the hot oven door.

This is particularly important with small children.

The baking tray or universal pan may distort while the oven is operating. This is

caused by major temperature differences on the utensil. These differences may occur

if only one part of the utensil was covered or if deep-frozen food, e.g. pizza, was

placed on the utensil.

The distortion will already subside again during baking, roasting or grilling.

Universal pan, non-stick

Soufflé pan

Baking tray, aluminium

Baking tray, enamelled

Baking tray, non-stick

Wire shelf, high/low

Wire shelf, dose mesh

Roasting tray

Upgrade set Clou, 3 pieces

Upgrade set Clou, 4 pieces

System steam cooker

Pizza stone

Universal pan Z 1232 X0

Z 1233 X0

Glas pane Z 1262 X0

Z 1272 X0

Z 1332 X0

Z 1342 X0

Z 1343 X0

Pizza tray Z 1352 X0

Z 1432 X0

Z 1442 X0

Z 1512 X0

Z 1742 X0

Z 1752 X0

N 8642 X0 EU

Z 1912 X0

Universal oval roaster enamelled Z 9930 X0

Oven door guard 440651

Before using your appliance

for the first time

Preliminary Ta ke the accessories out of the oven.

cleaning Remove all packaging remnants, e.g. polystyrene

parts, from the oven.

1. Clean the appliance exterior with a soft

moistened cloth.

2. Remove the shelf supports from the oven.

3. Clean the oven and the accessories with a hot

detergent solution.

Please observe the operating instructions

furnished with the hob.

Initial burn-in Before using the appliance for the first time, you

must set the current time on the electronic clock.

Heat the empty oven for approx. 30 minutes.

Select circotherm *at a setting of 190° C.

During the initial burn-in phase, please open the

kitchen windows to dissipate unpleasant odours.

Subsequent cleaning Clean the oven with a hot detergent solution.

Install the hook-in grilles.

Time of day After connecting to the mains, or after a power

Setting the time failure, the display 0:00 will blink.

Press the >button and set the current time with

the rotary knob (e.g. 15:00 hours).

To correct the time, press the >button until the

symbol flashes.

Then set the time.

Note: The time cannot be corrected if an automatic

function has been set (see Electronic clock for

cancelling automatic function).

Electronic clock

The electronic clock can be operated with one hand;

after pressing the button, set the time with the rotary

knob. Settings can be made for as long as the

function display flashes (~4 seconds).

The control panel

Minute timer

ON time OFF time

Rotary knob

To engage and

disengage, depress

gently

Time of day

Function selector

Minute timer 1. Press the >button and set the cooking time

(e.g. 5minutes).

When the timer switches on, the remaining time

is displayed.

2. When the time has elapsed, a signal is emitted

and the ,symbol flashes. To stop the signal,

press the >button.

This manual suits for next models

Table of contents

Other NEFF Oven manuals

NEFF

NEFF U15E42N0AU - annexe 2 User manual

NEFF

NEFF B57VS24H0B User manual

NEFF

NEFF B3ACE4A 0S Series User manual

NEFF

NEFF U17M72 0GB Series User manual

NEFF

NEFF B27CR22G0B Operating and maintenance instructions

NEFF

NEFF B45E62N0 User manual

NEFF

NEFF B 15H4 User manual

NEFF

NEFF B3AVH4H.0B User manual

NEFF

NEFF B44M42.3GB User manual

NEFF

NEFF C18MT37.0B User manual

NEFF

NEFF C15DR00N0 User manual

NEFF

NEFF J1ACE2H 0B Series User manual

NEFF

NEFF B47CR32.0 User manual

NEFF

NEFF N90 C24FS31 0B Series User manual

NEFF

NEFF B57VR22N0B User manual

NEFF

NEFF U16E74 5GB Series User manual

NEFF

NEFF B15M42.3AU User manual

NEFF

NEFF B15CR33 1B Series User manual

NEFF

NEFF B44S32 5GB Series User manual

NEFF

NEFF U16E74.3AU User manual

NEFF

NEFF T22S46N0AU User manual

NEFF

NEFF C24MR21 0B Series User manual

NEFF

NEFF B58VT28 0B Series User manual

NEFF

NEFF U1ACE5H.0B Operating and maintenance instructions

Popular Oven manuals by other brands

Bosch

Bosch HVA531NS0 instruction manual

Electrolux

Electrolux EOF6P46X user manual

Combi

Combi BLODGETT BC142GDS Specifications

AEG

AEG COMPETENCE 311704300 Installation and operating instructions

Falcon

Falcon DOMINATOR PLUS G3106 Series Servicing instructions

Rational

Rational SCC WE 61G installation manual

Smeg

Smeg DOSPA38X User manuals

Electrolux

Electrolux air-o-convect 20 GN 2/1 user manual

Miele

Miele HR 1954-2 operating instructions

KHIND

KHIND OT50 instruction manual

Henny Penny

Henny Penny Smoker Box installation manual

Lang

Lang ECOD-AP Installation and operation instructions

AEG

AEG BEK455310M user manual

Frigidaire

Frigidaire FNGE90JGR user manual

Hotpoint

Hotpoint FE9 S831 JSH IX user manual

GE Advantium SCB2000 owner's manual

AEG

AEG DE401301DM user manual

DeLonghi

DeLonghi XA660 Directions for use
