Conversion Kit to Convert NA-LX100

for use with Panasonic LX100II Camera

Instruction Manual

FOREWORD

Thank you for your purchase of a NAUTICAM product.

At NAUTICAM, we pride ourselves in the ability to recognize the requirements

of professional as well as amateur underwater photographers and fulfill them

through the innovative designs of our products. We strive to achieve a high

level of user-friendliness by allowing stress-free installation and easy

operation of all important functions of the camera.

Please read this manual carefully before using the product, this will maximize

its performance as well as its lifetime.

WARRANTY

All NAUTICAM Housing Products are warranted against any material and

manufacturing defects for two years from the date of purchase for consumer

use. This warranty only applies to products purchased from authorized

NAUTICAM dealers and does not extend beyond the original retail purchaser.

To return your product for service, please contact your regional authorized

service center(s). Please note that this warranty only applies when the product

is purchased in the territory where the service center is located.

NAUTICAM does not hold responsibility for damage, of any nature, to any

equipment used with and/or placed within our products.

NAUTICAM accepts no liability for any loss of captured images or the inability

to capture images even if it is due to the malfunctioning of our products.

Unauthorized modifications and/or repairs of our products will automatically

invalidate the warranty.

IDENTIFICATION OF PARTS

INSTALLATION

1. Remove the gray tap from the Zoom lever

2. Unscrew the screw inside of the Zoom lever

3. By unscrewing screws on the ON/OFF switch box, remove

the ON/OFF switch box.

4. Remove the gear of Exposure compensation dial by

unscrewing the straight screw

5. By unscrewing the two screws, remove the right camera

holder (in the yellow)

Zoom controller

for LX100II

Rubber Tips for

Zoom lever

Screw for

Zoom lever

Additional

screw x 4

Current as of 2018-12-19

6. By unscrewing the two screws, remove the Shutter Release

Actuator assembly and Zoom controller (Red arrow).

7. After attach Zoom controller for LX100II, reverse the above

steps to complete the installing.

8. Check vacuum to make sure the installing is perfect after

complete all the steps.

Remark: All Nauticam product manual will be changed to e-manual in end of

2018. Please download corresponding product manuals on Nauticam.com

website, or contact us for e-manuals.
