Nauticam NA-EM5 User manual
0
1
Thank you for your purchase of a NAUTICAM camera housing.
At NAUTICAM, we pride ourselves on the a ility to recognise the
requirements of professional as well as amateur underwater
photographers and fulfill them through the innovative designs of our
products. We strive to achieve a high level of user-friendliness y
allowing stress-free installation and easy operation of all important
functions of the camera.
Each NA-EM5 housing is individually inspected and water pressure
tested to ensure optimum quality.
Please read this manual carefully efore using the housing, this will
maximise its performance as well as its lifetime.
2
1. All NAUTICAM Products are warranted against any material and
manufacturing defects for one year from the date of purchase for
consumer use.
2. NAUTICAM accepts no lia ility for any damage to and defects in the
housing caused y improper use and/or poor maintenance; it is the
responsi ility of the owner to carefully follow the instructions in
this manual.
3. NAUTICAM does not hold responsi ility for damage, of any nature,
to any equipment used with and/or placed within the housing.
4. NAUTICAM accepts no lia ility for any loss of captured images or
the ina ility to capture images even if it is due to the
malfunctioning or leakage of the housing.
5. This warranty only applies to products purchased from authorised
NAUTICAM dealers and does not extend eyond the original retail
purchaser.
6. Unauthorised modifications and/or repairs of the housing will
automatically invalidate this warranty.
7. To return products for service, please contact our regional
distri utor, normally you would need to notify them y email first
and ship them the product y registered mail, along with your
contact details and a rief description of the defect.
3
1. NA-EM5 housing
2. Instruction manual
3. Spare silicone ru er housing o-ring
4. O-ring remover
5. CR2032 attery (for moisture alarm)
6. Lu ricant
7. Set of Allen keys
Spare silicone ru er o-ring
Lu ricant Set of Allen keys
CR2032 attery
O-ring remover
4
1. A water-tight test without the camera inside the housing is highly
recommended when using the system for the first time and after
the changing of port and O-ring(s).
2. Do not use lu ricants from other rands with the silicone ru er O-
ring on this housing, only use the lu ricant provided y NAUTICAM.
3. Discontinue use immediately should you notice any leakage.
4. Store the housing in a ro ust, shock-proof container during
transportation; avoid transporting with any equipment, such as a
camera, inside the housing.
5. When travelling y air, do not close the housing if the port is
installed, as this may lead to a pressure difference etween the
atmosphere and inside the housing.
6. Care must e taken when opening the housing, as pressure may
uild up inside the housing which increases the opening force.
7. Do not open the product in a wet or sandy environment. Protect
the interior from moisture and de ris in order to prevent
malfunction or leakage.
8. Do not store the product in an environment of high humidity.
9. Do not leave the housing and the camera in direct sunlight for
prolonged periods.
10. Keep out of reach of children, failure to do so could result in injury.
11. Defective products should e shipped to our distri utors for service,
unauthorized disassem ling and/or modifications could result in
malfunction or leakage.
5
Specifications 6
Identification of Parts 7
Preparation of the Housing 12
Opening and Locking the Housing 14
Installing the Camera 1
Mounting the Port 16
Care and Maintenance 18
Optional Accessories 19
6
Construction
Housing ody: Aluminium alloy
Surface treatment: Hard anodised
Display window: A rasion resistant polycar onate
Dimensions
Width: 185mm
Height: 152mm
Depth: 105mm
Weight Approx. 1.1kg (without camera)
Buoyancy A out neutral
Depth rating 100 metres
Features
Moisture alarm: Blinking LED and audi le alarm
TTL capa ility:
Optical fi re mount included for
external stro es connection,
utilising the camera’s pop-up flash
as trigger.
Port mount: Patented easy port installation
system.
Main and Su dials:
Easily reached y thum or
forefinger.
Fn1, Fn2 uttons: Easily reached y thum or
forefinger.
7
1 Optical fi re mount 8 Port alignment index
2 M10 stro e mounting ase 9 Lens release utton
3 Su dial 10 Main dial
4 Shutter release lever 11 Fn2 utton
5 Accessory coldshoe 12 Movie lever
6 M16 accessory socket 13 Housing lock safety utton
7 Zoom/Focus kno 14 Housing lock
1
2
3
4
7
8
6
9
11
13
14
10
12
5
8
15 Mode dial 22 Up selection utton
16 Moisture alarm window 23 Left selection utton
17 Live view lever 24 OK utton
18 Fn1 utton 25 Right selection utton
19 Play ack utton 26 Down selection utton
20 Menu utton 27 On/Off lever
21 Info utton 28 Erase utton
15
17
16
18
21
22
23
28
19
20
24
25
26
27
9
29 Port release safety utton 31 1/4”–20UNC tripod socket x 2*
30 Port lock/release latch
* The maximum length of screws that can e
used with the tripod sockets is 4mm
29
30
31
