Motorola 80FLIWBM5DG User manual
0
1
CONTENTS
•SAFETY PRECAUTIONS 2
•INSTALLATION INSTRUCTIONS 10
•NAME OF PARTS 16
•ACCESSORIES 17
•SPECIFICATION SHEET 18
•LOCK AND UNLOCK METHOD 19
•INTRODUCTION TO EACH COMPARTMENT
•OF DETERGENT BOX 20
•CONTROL PANEL 21
•PROGRAM INTRODUCTION 23
•VARIOUS FUNCTIONS 28
•CLEAN AND MAINTENANCE 30
•NON - FAILURE CONDITIONS 33
•TROUBLE SHOOTING GUIDE 35
•DISPOSAL & ROHS DECLARATION 37
•WARRANTY TERMS & CONDITIONS 38
2
SAFETY PRECAUTIONS
•To protect the user and other people’s health and property, be sure to
observe the following safety notice.
WARNINGS
PLEASE READ THIS PART OF MANUAL CAREFULLY FOR PROPER OPERATION
BEFORE USING YOUR MACHINE.
•The precautions stated here are classified as “Warning” and “Attention”
according to the damage and the emergency caused by misoperation, and
are described respectively in line with the marks below.
Warning
With no respect to mark, the misoperation may cause death or GBH.
Attention
With no respect to mark, the misoperation may cause body harm or object
damage.
This mark indicates the content of warning or attention.
This mark indicates the prohibited action.
This mark indicates the compulsory action to be carried out.
Warning
•Dismantling, repair or alterations should only be carried out by
3
professional technician as otherwise you may be subject to electric
shock, may cause fire or get injured.
•Electricity supply must be unplugged with dry hands. Otherwise, this may
cause electric shock.
•Damaged or loosen wire or plug should not be used.
Otherwise electric shock, short circuit or fire may take place.
•Do not damage wire. Do not damage or alter the wire forcibly bend, pull
twist or handle the wire. Beside, please do not put weigh on or trap the
wire.
Damage of wire may case electric shock or fire
•Do not put water in direct contact with the unit during maintenance and
repair. This may cause short circuit or electric shock.
4
•Do not put gasoline, benzine, alcohol, thinner of fabrics with these stains
into or near to the washing machine. To prevent fire or explosion which
may cause injuries.
•This washing machine is equipped with the electricity wire with
grounding socket. The creepage protector shall be used if possible.
To prevent electricity leak which may cause injuries.
Please use the single socket with special voltage and current
matched with plug marked specification. The share of the same
socket with other electric appliances may cause fire due to excessive.
Thoroughly wipe the power plug when dirt is adhering the prong or
around the base of the prong. Failure to do so may cause a fire.
•Washing machine should not be installed in humid place or in places
exposed to wind and rain. Otherwise, electricity leak causing electric
shock or fire may occur.
5
•This washing machine is strictly prohibited to get close to the locations
with candle, mosquito repellent incense, dog-end or other kinds of open
flame.
To avoid injuries caused by the lock damage.
•Do not operate the machine when there is gas leak.
6
WARNINGS
•Keep children away from the washing spinning basket and do not place
box or shelves next to the washing machine. Children may fall into the
basket resulting in injuries. This appliance is not intended for use by
persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•The glass door becomes hot in process of high-temperature washing. Do
not touch the door when the machine is on, especially children.
•If you need to open the door during high-temperature washing program,
wait until the temperature drop to safe standard, and the door unlocked
automatically.
•Packing material may be dangerous to kids, please keep all packing
material (plastic bag foam etc) far away from the kids.
Attention
•Do not pull the wire from the socket when unplugging the unit.
To avoid electric shock or fire cause by short circuit may result.
7
Electricity supply must be unplugged with dry hands during
maintenance and repair. Otherwise, electric leakage causing
injuries may occur.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
•Do not wash, rinse and spin the water proof fabric or cloth.
Sleeping bag, raincoat, cover of skiing, utilities, bicycles, cars and motors.
Otherwise may lead to injury by abnormal vibration during spinning or
damage the washing machine, wall, floor and clothes.
•Keep hands and feet away from the bottom of the washing when it is
motion.
Parts in motion beneath the unit may cause injuries.
8
Water supply hose should be tightly screwed to the unit.
Failure to do so may result in water leakage. Used for a long
period of time, the unit may result in water leakage caused by
loosen union nut. So please check it in time and screw tightly
again.
Please unplug the unit when not using the unit for a long period
of time. Electric shock or leakage may occur due to deformation of
plastic parts of the unit.
•Water of above 50°C should not be used for washing.
Electric shock or leakage may occur due to deformation of plastic parts
of the unit.
•Do not stand on or put weight on the top of the unit.
Otherwise, deformation and damage may result causing injuries.
•Two people are required in moving or transportation.
9
•Check water supply hose connection by turning on the water
before washing.
To prevent damages caused by possible water leakage due to
loosen screw or not tightly.
•The new hose-sets supplied with the appliance are to be used and
that old hose-sets should not be reused.
•Do not block the ventilation openings on the bottom of washer by
carpeting when the washer is installed on a carpeted floor.
•Please turn off the water tap when not using the unit.
To prevent damages caused by water leakage.
