Motorola XTL 5000 Installation guide

March 2008 San Diego Fire-Rescue Department

Motorola XTL 5000 800 MHz Mobile

Radio Training

San Diego Fire-Rescue Department

March 2008 San Diego Fire-Rescue Department

Objectives

•Review basic operating features

•Learn how to navigate through channels

and zones

•Learn how to build scanning lists

March 2008 San Diego Fire-Rescue Department

Specifications & Features

Motorola XTL 5000 Digital Mobile Radio

• 512 Channel/32 radio zones capability

•Scan up to 16 channels only

• 14 digit character display

• 45 Watts power output

• Digital or analog operating system

March 2008 San Diego Fire-Rescue Department

POWER BUTTON

(DISCONNECTED)

4 WAY NAVIGATION

BAR

DISPLAY BACKLIGHT

HOME BUTTON

MICROPHONE

ROTARY SELECTOR

XTL 5000 MOBILE RADIO CONTROL HEAD

EMERGENCY

BUTTON

VOLUME SELECTOR

March 2008 San Diego Fire-Rescue Department

• VOLUME SELECTOR: Used to adjust radio volume.

•DISPLAY BACKLIGHT: Used to adjust the display brightness. There are three levels of intensity.

• ROTARY SELECTOR: Channel and zone selector.

• EMERGENCY BUTTON: Activates the emergency alert system. Hold down for 2 seconds

to alert and hold down for 4 seconds to reset.

• HOME BUTTON: Used to go back to the departments selected Home channel (7A DISP), push and

hold for one second and also as enter/confirm function.

•MICROPHONE: Microphone connector.

• POWER BUTTON: This button is disconnected. The radio turns on automatically once the apparatus

electrical power is turned on.

•4 WAY NAVIGATION BAR: Used to navigate through zones when building a scan group only

(USE THE ROTARY SELECTOR FOR NAVIGATING THROUGH CHANNELS AND ZONES).

Motorola XTL 5000 Mobile Radio Operations

March 2008 San Diego Fire-Rescue Department

XTL 5000 MOBILE RADIO CONTROL HEAD

SOFT KEYS

VIEW SOFT KEYS:

PRESS TO VIEW RADIO ID

AND VIEW SCAN LIST

SCAN SOFT KEYS:

PRESS TO TURN SCAN

ON/OFF

PROGRAM SOFT KEYS:

PRESS TO ADD OR DELETE

SCAN CHANNELS

ZONE SOFT KEYS:

PRESS TO CHANGE

RADIO ZONE

F/R SOFT KEYS:

FRONT/REAR RADIO

HEAD SELECTOR

March 2008 San Diego Fire-Rescue Department

SOFT KEYS: Used to activate display functions.

•ZONE SOFT KEY: Used to change radio zones.

•PROGRAM SOFT KEY: Used to program scan list.

•SCAN SOFT KEY: Used to turn scan on or off.

•VIEW SOFT KEY: Used to view radio ID and scan list.

•F/R (FRONT/REAR) SOFT KEY: Used to change radio operations from front to

rear.

Motorola XTL 5000 Mobile Radio Operations

March 2008 San Diego Fire-Rescue Department

DISPLAY BRIGHTNESS AND CHANNEL CHANGING

ROTARY SELECTOR: CHANNELS

1. ROTATE CLOCKWISE TO MOVE UP ( A-P)

2. ROTATE COUNTER CLOCKWISE TO MOVE

DOWN (P-A)

DISPLAY BACKLIGHT:

1. PRESS BUTTON FOR DESIRED

BRIGHTNESS (3 SETTINGS)

March 2008 San Diego Fire-Rescue Department

ZONE CHANGING

4 TURN ROTARY KNOB

CLOCKWISE OR

COUNTER CLOCKWISE

FOR DESIRED CHANNEL

1PRESS ZONE SOFT KEY

3PRESS HOME BUTTON

KEY 2TURN ROTARY KNOB

CLOCKWISE OR COUNTER

CLOCKWISE FOR DESIRED ZONE

March 2008 San Diego Fire-Rescue Department

SCANNING - ADDING OR DELETEING

2PRESS PROG (PROGRAM)

SOFT KEY

3PRESS SCAN SOFT KEY

1PRESS SCAN SOFT KEY

TO TURN SCAN OFF
