Motorola HS830 HANSFREE Instruction Manual

DRAFT

START HERE >

HS830

Wireless Headset Module

with Bluetooth

Technology

DRAFT

Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen the

Motorola HS830 Wireless Module with Bluetooth ®

technology.

The Motorola HS830 Wireless Module with Bluetooth

technology defies traditional expectations. This latest product

by Motorola makes connectivity invisible and reliable. It is

astonishingly advanced, yet intuitive and simple to use. And

although you are no longer connected by wires, you are

connected to a growing group of leading-edge technology

pioneers who are embracing the global Bluetooth movement.

6809482A59-O

DRAFT

Safety and General Information

. . . . . . . . . . . . . . . . . . . . 3

Introduction

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

What Is Bluetooth Wireless Technology? . . . . . . . . . . . . . 6

Wireless Module Features . . . . . . . . . . . . . . . . . . . . . . . . 7

Using Your Wireless Module

. . . . . . . . . . . . . . . . . . . . . . . 8

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Wearing Your Wireless Module . . . . . . . . . . . . . . . . . . . . 10

Pairing Your Wireless Module and Phone. . . . . . . . . . . . 11

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Making and Receiving Calls . . . . . . . . . . . . . . . . . . . . . . 13

Using Your Module’s Indicator LED. . . . . . . . . . . . . . . . . 15

Other Wireless Module Adapter Applications . . . . . . . . . 18

DRAFT

Safety and General

Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT

OPERATION. READ THIS INFORMATION BEFORE USING

YOUR DEVICE.

Users are not permitted to make changes or modify the

device in any way. Changes or modifications not expressly

approved by the party responsible for compliance could void

the user’s authority to operate the equipment. See 47 CFR

Sec. 15.21.

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation. See 47

CFR Sec. 15.19(3).

Electromagnetic Interference/Compatibility

Note:

Nearly every electronic device is susceptible to

electromagnetic interference (EMI) if inadequately shielded,

designed, or otherwise configured for electromagnetic

compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility

conflicts, turn off your device in any facility where posted

DRAFT

notices instruct you to do so. Hospitals or health care facilities

may be using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your device when on board

an aircraft. Any use of a device must be in accordance with

applicable regulations per airline crew instructions.

Medical Devices

Hearing Aids

Some devices may interfere with some hearing aids. In the

event of such interference, you may want to consult with your

hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the

manufacturer of your device to determine if it is adequately

shielded from RF energy. Your physician may be able to

assist you in obtaining this information.

Industry Canada Notice to Users

Operation is subject to the following two conditions: (1) This

device may not cause interference and (2) This device must

accept any interference, including interference that may

cause undesired operation of the device Ref IC RSS 210

Sec. 5.11. The term “IC:” before the certification/registration

number only signifies that registration was performed based

on a Declaration of Conformity indicating that Industry

Canada technical specifications were met. It does not imply

that Industry Canada approved the equipment. See Ref IC

Self-Marking 6(f) and RSP-100 Sec. 4.

DRAFT

FCC Notice to Users

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the

receiver.

•

Connect the equipment to an outlet on a circuit different

from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician

for help.

DRAFT

Introduction

What Is Bluetooth Wireless

Technology?

Bluetooth is a wireless way to connect and transfer

information between mobile phones, accessories, computers,

and other communication devices. It's more than simple

handsfree convenience. By eliminating the cable, sharing

becomes easier, work becomes more efficient and multi-

tasking takes on a new dimension. And it's an open standard,

which means that this product will work seamlessly with any

Bluetooth enabled phone.

Note:

The use of wireless devices and their accessories may

be prohibited or restricted in certain areas. Always obey the

laws and regulations on the use of these products.

For more information on this or Motorola's other innovative

Bluetooth products, visit www.motorola.com/bluetooth.

DRAFT

Wireless Module Features

1 Multifunction Button (MFB)—

Controls multiple

headset functions.

2 Charging Port—

Accepts the plug for the battery charger.

3 Heaadset Jack—

Accepts the plug for the earbud and

microphone..

4 LED Indicator—

Provides a visual cue about wireless

module status.

5 Volume Up Button—

Adjusts speaker volume up.

6 Volume Down Button—

Adjusts speaker volume down.

Charging

Port

Headset Jac

Volume Up

Button Volume Dow

Button

Multifunction

Button (MFB) LED Indicato

DRAFT

Using Your Wireless

Module

Charging the Battery

When to Charge

First-Time Use

—Before you can use your wireless module,

charge its self-contained battery for two hours.

Recharging

—When you hear five rapid high tones,

repeated at 20-second intervals, the wireless module battery

needs recharging.

Over time, batteries gradually wear down and require longer

charging times. This is normal. Your battery will have less

standby time the more you talk on the phone with your

wireless module.

The rechargeable batteries that power your

wireless module must be disposed of properly and

may need to be recycled. Contact your local

recycling center for proper disposal methods.

Warning:

Never dispose of batteries in a fire because they

may explode.
