Motorola RG2200 User manual

• Simultaneously decodes up to three concurrent streams of

MPEG-2 digital video

• Supports MPEG-2 and Dolby®Digital audio streams

• Open architecture supports 3rd party Interactive Program Guide,

PPV, VOD and IP-based interactive TV solutions

• High-resolution on-screen graphics

• Inherent security with conditional access validation on a per

channel change basis

• Can use CAT-5 Ethernet cabling or existing in-home coaxial cable

for quick and easy installations

Residential Gateway

Innovative “whole home” solution for

delivering broadcast and on-demand

video, data and interactive TV services

to the home.

HIGHLIGHTS:

Motorola’s Residential Gateway 2200 (RG2200) is among the world’s

most advanced set-top box for supporting cable and satellite

competitive communications and entertainment services over the

telecommunications infrastructure. A key component of the Motorola

Multi-Service Access Platform, the RG2200 is the single set-top

interface to the complete end-to-end solution for bundled services –

voice, data, broadcast, and on-demand video services.

The RG2200 family of products provides customers with a “whole

home” solution. Operating as a single access device to the home, the

RG2200 can deliver two or three concurrent streams of DVD-quality

video, providing the functionality of multiple high-quality set-top

boxes. Additionally, it can be used to offer compelling and lucrative

capabilities such as high speed Internet access, on-screen caller ID,

and interactive features (e.g., Pay-Per-View (PPV), Video-On-Demand

(VOD)), and interactive TV applications.

Each member of the RG2200 family – the RG2200A (ADSL+), RG2200V

(VDSL 998), RG2200C (VDSL, future), RG2200B (ADSL2+, future) and

the RG22200E (Ethernet, future) supports a different transport

technology and provides common user interfaces, design, subscriber

provisioning, and management features. Subscribers will enjoy the

same user experience and cable providers will be familiar with

installation, provisioning, and support issues.

Using a separate remote control, each TV viewing environment may

be fully customized with its own channel line up, channel changing

preferences, parental locks and voice caller-ID/message

waiting characteristics.

Specifications are subject to change without notice.

Motorola, Inc.

Next Level Communications

5789 State Farm Drive

Rohnert Park, California 94928

1.707.584.6820

www.motorola.com/nextlevel

508933-001

5601 - 1003 - 2.5K

MGBI

COMMON FEATURES

• MPEG-1 and MPEG-2 main level profile video

• ATSC standard Dolby Digital (AC-3) audio

• MPEG-2, layer 1 and 2 audio

• High-resolution, bitmapped graphics display (16 bit)

• Wide screen (16 x 9) video support

• Macrovision copy protection

• Vertical Blanking Interval (VBI) features (Closed

captioning and teletext)

• Displays Emergency Alert Service overlay

• Secondary Audio Program

• On-Screen caller ID

• Up to three IR and UHF remotes per Residential Gateway

• Support for tethered IR blaster

• 10/100 BaseT Ethernet data port

• On-screen network and CPE diagnostic tools

• Front panel diagnostic indicators

• Downloads software updates automatically

• ADSL+ compatible

• Reach of up to 9 kft (2750 meters) on 24 AWG (2 video streams)

12kft (3650 meters) (1 video stream )

• Downstream rate up to 10.5 Mbps

• Upstream rate up to 1 Mbps

• Complies with T1 .413 and ITU-T G.992

• Two concurrent MPEG-2 digital quality video streams

• 16 bit graphics

• 32 Mb applications memory per video decoder

RG2200A FEATURE SET

STANDARD INTERFACES

• Network In: RJ-45 jack

• Network In/TV Out: F connector (female)

• Video: RCA phono jack (yellow)

• S-Video: 4-position circular mini-DIN

• Audio-L/R: RCA phono jacks

• Dolby Digital (AC-3): RCA phono jack

• AC In: 2-prong, non-polarized AC inlet

• Ethernet (10/100BaseT) RJ-45 plug in option

• 998 Plan VDSL compatible

• Reach of up to 4200 ft. (1280 meters) on 24 AWG (3 video

streams) 5500 ft.(1675 meters) (2 video streams)

• Downstream rate up to 26 Mbps

• Upstream rate up to 7.7 Mbps

• Complies with T1 .424 and ITU-T G.993

• Three concurrent MPEG-2 digital quality video streams

• 16 bit graphics

• 32 Mb applications memory per video decoder

RG2200V FEATURE SET

• VDSL band plan compatible

• Reach of up to 4500 ft. (1371 meters) on 24 AWG (3 video

streams) 5500 ft.(1675 meters) (2 video streams)

• Downstream rate up to 26 Mbps

• Upstream rate up to 7.7 Mbps

• Three concurrent MPEG-2 digital quality video streams

• 16 bit graphics

• 32 Mb applications memory per video decoder

RG2C FEATURE SET

OPTIONAL FEATURES

• DVB common de-scrambling and smart card

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or

service names are the property of their respective owners. Dolby is a trademark of Dolby Laboratories; Dolby

Digital is manufactured under license from Dolby Laboratories. © Motorola, Inc. 2003.
