Introduction 1English

Introduction

Congratulations on purchasing your Motorola Timeport i2000,

digital, portable global phone. The use of state-of-the-art

technology, called GSM (Global System for Mobile

Communications) and iDEN, provides world-wide services to keep

you in touch constantly with your business and personal contacts

wherever you travel.

A removable SIM (Subscriber Identity Module) card holds all your

personal information, including secure Personal Identification

Numbers (PINs), names, and phone numbers. Just as you protect

your credit and bank cards with PINs, you can safeguard your SIM

card with a PIN.

AThis user guide describes the features of the i2000 as they

were set up by Motorola. However, your Service Provider or

your organisation may have changed or added features. For

more information, check with your Service Provider or your

organisation.

Your i2000 offers:

•Phone Mode - for cellular phone operation.

•Messaging Services - for messages and voice mail.

i2000_en.bk : intro.fm5 Page 1 Wednesday, February 23, 2000 7:58 AM

Introduction

English

1. Antenna Extend for optimal signal.

2. Earpiece Listen to calls when the speaker phone is

off.

3. Volume

Control

Buttons

Press to adjust volume levels in the Phone

mode. In mail menus, press to scroll

forward and backward.

4. Backlight

Button

Press and hold to activate the backlight in

the display. (Insufficient light conditions

only).

5. Scroll Key Press the left side to scroll backward or the

right side to scroll forward through menu

options and lists. When entering text, press

the left side to erase text or right side to

add a space.

6. Mode Key Press to select either phone mode or

programming mode.

7. LED (Light

Emitting

Diode)

Check the phone’s status.

8. On/Off Key Press and hold to turn your i2000 on or

off.

9. Vibe-All Key Press to silence or turn on the ringer tone.

10. Microphone Speak into this during calls.

11. Alphanumeric

Display

View up to four lines (up to 12 characters

per line) on the display.

12. Option Keys Press the right or left option key to select

the menu option that appears directly

above the key.

13. Send/End Key Press to answer an incoming phone call.

After entering a phone number, press to

dial the call or to redial the entered phone

number. Press to end phone calls.

14. Menu Key Press to scroll through menu options.

15. Alphanumeric

Keypad

Enter telephone numbers and

alphanumeric characters.

16. Speaker

Phone Key

Press to activate the speaker phone during

a phone call.

17. Accessory

Connector

Use to connect accessories or the battery

charger.

i2000_en.bk : intro.fm5 Page 2 Wednesday, February 23, 2000 7:58 AM

Introduction 3English

Getting Started

In order to get started straight away with your new i2000, follow

these steps:

Charge the Battery

!Before you use your phone, please read the following

for important information on battery charging.

1Remove the battery from its holder and clip it into your phone.

2Connect the travel charger to the phone and plug it into a

standard mains socket.

Powering On

1Insert the SIM card into the tray on the back of your phone

(under the battery).

AThe i2000 supports a 3 Volt SIM card only.

2Press Sto switch on.

3If prompted, enter your PIN code.

Once a GSM or iDEN network is located by your phone, it

connects and the network name appears on the display.

Making a Call

1Enter the number you want to call.

AEven if you call a local number, you must include the full

area code but not the country code. However, to call a local

number when you are in the USA, you must include both

the country code and the area code.

AIf you make a mistake, press ´once to move back one

digit, or select Cancl to start again.

2Press °to place the call.

IMPORTANT! Ending a Call

When you have finished your conversation, you must end the

call, even if the other person terminates the call. To end the call,

press °.

AIf you do not end the call, you will remain connected and

you will be charged for the duration of the connection.

i2000_en.bk : intro.fm5 Page 3 Wednesday, February 23, 2000 7:58 AM

Introduction

English

Understanding this Manual

Many of your phone options are accessed by a simple menu

system. A full description of how to navigate around your phone

is covered in the next section Navigation.

Key Presses

Key presses are represented in this manual using symbols so that

you may locate and use the required sequence quickly. A

sequence of key presses may be shown as follows:

³48

This means that you should press the ³key followed by the

4key and then the 8key, in sequence, not

simultaneously.

Entering Information

When you are requested to enter information, such as the

number of the phone you wish to call, this is represented in bold

type. For example:

C- enter the required telephone number.

A- enter your Personal Identification Number.

B- enter your unlock code.

Prompts and Messages

Your phone responds to key presses by displaying either easy to

understand prompts that guide you to the next action, or simple

messages confirming that your action is complete. Prompts and

messages are represented in this manual in LCD style, for

example:

Enter PIN or Completed.

Other Symbols

You will find the following symbols used throughout this manual:

AA Note contains additional information which is relevant to

the feature/item.

!A Caution contains important additional information

which is relevant to the efficient and/or safe usage of

your phone.

i2000_en.bk : intro.fm5 Page 4 Wednesday, February 23, 2000 7:58 AM

Introduction 5English

Navigation

A large number of your phone's options are accessed by using

menus which use a common approach for selection, change and

cancellation.

Please read this section carefully before attempting to access a

menu option. When you understand the common approach to

menu navigation and how the menus are shown on the page,

you will be able to access and change options with ease.

About Menus

To select menu options:

1Press $until you see the desired menu option.

2Press ±under the desired menu option to select it.

For example, when there is the word PRGM above the ±key,

pressing this key takes you into the Programming menus.

i2000_en.bk : intro.fm5 Page 5 Wednesday, February 23, 2000 7:58 AM

Introduction

English

Total Customer Satisfaction

At Motorola, Total Customer Satisfaction is a top priority. If you

have a question, a suggestion or a concern about your Motorola

Cellular Phone, Motorola wants to hear from you.

Please contact the Motorola Cellular Response Centre by fax on:

+44 (0) 131 458 6732, or use one of the local phone numbers in

the following countries:

Austria 0800 297246

Belgium 0800 72 370

Czech Republic 00420 2 21 85 21 01

Denmark 4348 8005

Egypt 02 3411800

Eire 01 402 6887

Finland 0800 117 036

France 0 803 303 302

Germany 0180 35050

Greece 00800 441 28150

Italy 02 696 333 16

Jordan 06 863750

Kuwait 484 2000 Ext 1177

Lebanon 01 744156

Luxembourg 0800 21 99

Netherlands 0800 022 27 43

Norway 22 55 10 04

Oman 790925

Portugal 01 318 0051

Qatar 418999

Saudi Arabia 01 2303294

South Africa 0800 11 48 49

Spain 902 100 077

Sweden 08 445 1210

Switzerland 0800 553 109

Turkey 0212 425 9090

UK 0500 55 55 55

United Arab Emirates 04 32 11 66

Hong Kong 852 25063888

People’s Republic of China 86 10 68466060

Singapore 65 4855 333

Taiwan 886 2 87731746

United States of America 1 800 331 6456

Canada 1 800 461 4575

For e-mail queries contact:mcr[email protected]

For Internet queries contact:http://www.mot.com

i2000_en.bk : intro.fm5 Page 6 Wednesday, February 23, 2000 7:58 AM

Introduction 7English

Motorola’s Warranty

Your Cellular Phone is warranted by Motorola to be of

satisfactory quality, fit for its purpose and comply with applicable

Motorola specifications for a period of twelve (12) months from

the date you bought it (verified by reference to your proof of

purchase).

This warranty does not apply if the phone has:

1been mishandled, misused, wilfully damaged, neglected,

improperly tested, repaired, altered or defaced in any way.

2a defect arising as a result of any failure to follow instructions

either in the manual or product specification.

3a defect which has arisen from the use of non-Motorola

approved accessories or ancillary items attached to or in

connection with the telephone.

This warranty does not affect your statutory rights as a consumer.

Warranty conditions may vary depending on the country in which

you bought the phone.

i2000_en.bk : intro.fm5 Page 7 Wednesday, February 23, 2000 7:58 AM

Introduction

English

i2000_en.bk : intro.fm5 Page 8 Wednesday, February 23, 2000 7:58 AM

Contents 9English

Contents

Safety

Important information for the efficient and safe operation of your phone ..............................................................................11

About Your Phone, Battery and SIM Card

Introduces your phone, explains how to charge and maintain batteries, explains about your SIM Card...............................15

Making and Receiving Phone Calls

Explains how to make single or conference calls, how to redial, how to transfer a call, and how to end a call....................21

Using Your Phone’s Features

Describes how to set up your phone, select networks, Voice Mail and SMS Message Services ..............................................35

Setting Programming Menus

Explains how to customise the settings on your phone by using the Programming Menu .....................................................43

Accessories

Details the accessories available for use with your phone..........................................................................................................47

What To Do If...

Helps you to solve any problems that may occur and provides a list of status messages........................................................49

Index

A comprehensive Index ..................................................................................................................................................................53
