Motorola EX212 User manual

Dummy Page - To be discarded before printing

Use this template with A7MotoPortraitProduct1

StructApps. See the Reference Pages for template

user instructions.

MOTOROLA

EX212

68016172001_no warranty.fm Page -1 Friday, June 3, 2011 10:10 AM

68016172001_no warranty.fm Page 0 Friday, June 3, 2011 10:10 AM

1Congratulations

Congratulations

elegant. None of those extra complications.

• Dual SIM slots. No need to change SIM cards. Use

two SIM cards at the same time.

• Stylish notification. Your phone lights up when you

receive a call or have a notification.

• Entertainment always. Listen to music or use your

phone’s camera to take photos and send them to

your friends.

We’ve crammed all the main features of your phone

into this handy guide, and in a matter of minutes we’ll

show you just how easy your phone is to use. You may

be surprised at what you discover.

• Support: Go to www.motorola.com/support.

• Accessories: Find accessories for your phone at

www.motorola.com/products.

Caution: Before assembling, charging or using your

phone for the first time, please read “Safety,

Regulatory & Legal” on page 34.

68016172001_no warranty.fm Page 1 Friday, June 3, 2011 10:10 AM

Your MOTOROLA EX212 with DUAL SIM is slim and

2Congratulations

Your phone

the important keys & connectors

Note: Your phone might look a little different.

Right Soft Key

Power/End

Key

Call/Answer

Key

Select Key

Left Soft Key

Navigation

Key

Display

Volume Key

Back

cover

release

Headset

port

Charger

connector

68016172001_no warranty.fm Page 2 Friday, June 3, 2011 10:10 AM

3Contents

Contents

Your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . . 16

Manage your life . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Photos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Media player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 34

68016172001_no warranty.fm Page 3 Friday, June 3, 2011 10:10 AM

4Let’s go

Let’s go

let’s get you up and running

Assemble & charge

Caution: Please read “Battery Use & Safety” on

page 34.

1cover off 2SIM cards in

3micro SD in 4battery in

5cover on 6charge up

68016172001_no warranty.fm Page 4 Friday, June 3, 2011 10:10 AM

5Let’s go

Turn it on & off

To turn your phone on or

off, press and hold .

Activate SIM cards

Your phone supports two

SIM cards. When two SIM cards are installed, you can

activate one or both of them.

1Press > Settings > DUAL SIM settings.

2Select Dual SIM open, Only SIM1 open, or Only

SIM2 open.

Note: If only one SIM card is installed, your phone

activates it by default.

Make & answer calls

To make a call from the home screen, enter a number,

then press .

Note: If two SIM cards are activated, choose which

SIM card you want to use.

To answer a call, press . To turn off the incoming

call alert, press the Volume Key down.

To end a call, press .

Power/End

Key

68016172001_no warranty.fm Page 5 Friday, June 3, 2011 10:10 AM

6Let’s go

Adjust volume

Press the volume keys to

change the ring volume

(in the home screen),

or the earpiece volume

(during a call).

Cool content & more

Surf the web for cool content and more “Web” on

page 15. An optional microSD memory card can be

installed in your phone—you can load it up with

photos, videos, and music from your computer.

Up/Down

Volume

Key

68016172001_no warranty.fm Page 6 Friday, June 3, 2011 10:10 AM

7Home screen

Home screen

quick access to the things you need most

Quick start: Home screen

You see the home screen when you turn on the phone

or press End from a menu. It’s basically like this:

Note: Your home screen might look a little different.

MenuMenu

00:00

2011.01.01 Sat

MusicMusicMusic Menu

00:00

SIM1 Carrier

SIM2 Carrier

Battery level

Right

Soft

Key

Left

Soft

Key

SIM card

status

68016172001_no warranty.fm Page 7 Friday, June 3, 2011 10:10 AM

8Home screen

Main menu

From the home screen, select Menu (the right soft

key) to see the main menu

Use to scroll left, right, up, or down through the

menu options. Press to select a highlighted option.

Phone status & notifications

The status bar at the top of the screen contains icons

that tell you about messages and phone status.

status indicators

Signal Strength Music Player On

Active Voice Call Silent Mode

Missed Call Ringer On

Phone Lock Vibrate On

Alarm Lock Ringer & Vibrate On

New Messages Headset

New Multimedia

Messages

Bluetooth

New Web Push

Messages

Battery

Java running Roaming Service

GGPRS running

68016172001_no warranty.fm Page 8 Friday, June 3, 2011 10:10 AM
