Motorola ATRIX 2 User manual

MOTOROLAATRIX™2

User’sGu

Calendar CameraMarket

ttp://www.

11:35

AT&T

1Welcome

Welcome

MOTOROLA ATRIX™ 2

Powerful just got a lot more fun.

•Browse in the fast lane: 4G and the

1GHz dual-core processor deliver up to

2x faster processing power than

single-core smartphones.

•ZumoCast™: Our free ZumoCast app

gives you secure, unlimited access to

music, pictures and videos straight

from your computer (see “File Access”

on page 50).

•Capture the moment: Capture every

detail with the 8MP camera and 1080p

HD video recorder (see “Photos &

Videos” on page 33).

•Music to your ears: Music, Motorola’s

music player, connects you to your

favorite artists, lyrics, music news, and

more (see “Music” on page 36).

•The Big Time: Connect to an optional

Motorola HD Station to browse or play

high-res video on the big screen (see

“Screen Connections” on page 43).

This product meets the applicable

limit for exposure to radio waves

(known as SAR) of 1.6 W/kg (FCC).

The limits and guidelines include a

substantial safety margin designed to

assure the safety of all persons,

regardless of age and health. The highest

SAR values measured for this device are

listed in the regulatory information

packaged with your product.

Caution: Before assembling, charging,

or using your phone for the first time,

please read the important safety,

regulatory and legal information

provided with your phone.

2Contents

Contents

Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Find More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Let’s Go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Touchscreen & Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Text Messaging & Email . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Photos & Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Music. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

AT&T Features & Services . . . . . . . . . . . . . . . . . . . . . . . . . 38

Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Screen Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Bluetooth™ & Wi-Fi Connections . . . . . . . . . . . . . . . . . 45

File Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Tips & Tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . 64

3Your Phone

Your Phone

the important keys & connectors

Calendar CameraMarket

11:35

AT&T

Cam

ttp://www.

Microphone

Micro

USB

Micro

HDMI

Volume

Power/

Sleep

Hold=

power

Press=

sleep

Webcam

Message

Light

Back

3.5mm

Headset

Home

Touch a text box (like in a message or

search) to enter text:

•Choose a keyboard: Touch and hold a

blank spot in a text box, then choose

Input Method.

•Close the keyboard: Touch B ack .

•Find out more: See “Text Entry” on

page 31.

ZXCVBNM

ASDFGHJKL

QWE R T Y U I OP

Done

Enter message here

?123

DEL

11:35

AT&T

Delete

ReturnSymbols

Press=symbols

Hold=settings

Shift Voice

4 Find More Information

Find More Information

•On your phone—Touch > Help

Center.

•On any phone—Call AT&T Customer

Care at 1-800-331-0500 or dial 611

from any AT&T mobile phone for

assistance with your service or device.

•On the web—You can also get support

online:

Interactive web tutorials are available

at att.com/Tutorials. Select

Manufacturer: Motorola and Model:

ATRIX 2 from the drop-down menus.

For detailed support information

including device specifications, the

user manual, troubleshooting, user

forums and knowledgebase articles, go

to att.com/DeviceSupport

For information about your wireless

account, service plan or network, go to

att.com/Wireless

•Accessories—You can find accessories

for your phone at

att.com/WirelessAccessories or visit

your local AT&T store.

5Let’s Go

Let’s Go

let’s get you up and running

Assemble & Charge

Caution: Please read “Battery Use &

Safety” on page 64.

1Coveroff.

HD1080p

SIMin.

HD1080p

3Batteryin. 4Coveron.

HD1080p

5Chargeup.

6Powerup.

To save battery life, see “Battery Tips” on

page 57.

Note: This phone supports apps and

services that use a lot of data, so make

sure your data plan meets your needs.

Contact your service provider for details.

After you power up, create or log into

your Google™ account so you can

download apps from Android Market™,

back up your Contacts, and more. You

can also add your email or social

networking accounts. Later, you can add

or remove accounts by touching >

Accounts.

Note: If you want to use a Wi-Fi network

for even faster Internet access,

touch Menu > Settings> Wireless &

networks> Wi-Fi settings. Touch Wi-Fi

to search for and connect to wireless

networks. There’s more in “Wi-Fi

Networks” on page 48.

6 Touchscreen & Keys

Touchscreen & Keys

a few essentials

Quick Start:Touchscreen

It’s all in the touch:

•Touch: Choose an icon or option.

•Touch & hold: Move items on the home

screen, or open options for items in

lists.

Calendar CameraMarket

1 of 8

See all your apps.

Touch the Launcher icon.

11:35

AT&T

Touchtoopen.Touch&

holdtomoveordelete.

Dragorﬂicktoscroll

panels(orlonglists).

Touch&holdanempty

spottoaddashortcut

orwidget.

•Drag or flick: Scroll slowly (drag) or

quickly (flick).

•Pinch or double-tap: Zoom in and out

on websites, photos, and maps.

Tips & tricks

•Flick & stop: When you flick a long list,

like Contacts, a scroll bar appears at

the right. Drag the scroll bar to move

quickly, or touch the screen to stop it

where you want.

•Maps: Twist a map with two fingers to

rotate it, and pull two fingers down to

tilt it.

•Sleep: To make the screen sleep or

wake up, press Power .

Note: Your

touchscreen might

stay dark if the

sensor just above it is covered. Don't

use covers or screen protectors (even

clear ones) that cover this sensor.

7Touchscreen & Keys

•Security: To make the screen lock

when you’re not using it, touch Menu >

Settings> Location & security > Set

up screen lock.

•Rotate: In many apps, the touchscreen

switches from portrait to landscape

when you rotate your phone. To turn

this on or off, touch Menu > Settings

> Display> Auto-rotate screen.

Power & Sleep Key

Press and hold Power to

open a menu where you can

turn off sound (Silent

mode), network and wireless

connections (Airplane mode), or the

phone (Power off).

To save your battery, prevent accidental

touches, or when you want to wipe

smudges off your touchscreen, put the

touchscreen to sleep by

pressing Power . To wake up the

touchscreen, just press Power again.

To change how long your phone waits

before the screen goes to sleep

automatically, touch Menu > Settings

> Display> Screen timeout.

Tip: To make the screen lock when it goes

to sleep, see “Security” on page 55.

Volume Keys

Press the volume keys on the side of the

phone to change the ring volume (in the

home screen), or the earpiece volume

(during a call).

Menu, Home, Search, & Back

Keys

Touch Menu to open menu options in

your home screen, lists, and other places.

Touch Home to close any menu or app

and return to the home screen. Touch

8 Home Screen

and hold Home to show the last few

apps you used, then touch an app to

open it. In the home screen,

touch Home to open or close the app

menu.

Touch Search to open “Search” on

page 10.

Touch Back to go to the previous

screen.

Home Screen

quick access to the thing s you need most

Quick Start:Home Screen

Use your home screen for quick access

to apps, notifications, and more.

You’ll see the home screen when you turn

on the phone or touch Home from a

menu:

Calendar CameraMarket

1 of 8

See all your apps.

Touch the Launcher icon.

11:35

AT&T

Notiﬁcations

Flickdownfordetails.

StatusIndicators

Shortcuts

Opentheappmenu.

Widgets

Touchtoopen.Touch&

holdtomoveordelete.

Dragorﬂicktoscroll

throughpanels.
