Morphy Richards Atomist User manual

Instruction

manual

Please read and keep these

instructions for future use

RN360001 MUK REV1

Health & Safety

The use of any electrical appliance requires the following common sense safety rules.

Please read these instructions carefully before using the product.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

or knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

• Keep the appliance and its cord out of reach of children

less than 8 years of age at all times.

• The appliance must not be left unattended while it is

connected to the supply mains.

• The appliance must be used and rested on a stable

surface.

• When placing the iron on the base or on its heel, ensure

that the surface on which the heel or base is placed is

stable.

• The appliance is not to be used if it has been dropped, if

there are visible signs of damage or it is leaking.

• The plug must be removed from the socket outlet before

the water reservoir is ﬁlled with water.

• Do not operate with a damaged vapour mist cord,

power cable or grommet, they must be replaced by

the manufacturer, its service agent or similarly qualiﬁed

person in order to avoid a hazard.

• CAUTION - HOT: Burns can occur from touching

hot parts or the iron rest.

• WARNING: To avoid electric shock, do not immerse

appliance in water / liquid.

• Check that the voltage on the rating plate of your

appliance corresponds with your house electricity

supply which must be A.C. (Alternating current).

• Do not let the power cable come into contact with

the hot Thermoglass soleplate of the iron.

• Should the fuse in the mains plug require

changing, a 13 amp BS1362 fuse must be ﬁtted.

• WARNING: This appliance must be earthed.

2Re-attach the water tank. Plug in your ATOMiST

vapour iron.1Fill the water tank (6).

6See the creases disappear with ease through

the Thermoglass soleplate (3) without the need

for steam.

5Press the precision vapour mist trigger (2) to apply

a light vapour mist onto the creased areas of your

garment.

3Press the precision temperature button once to

turn on your atomist vapour iron. Scroll through

the temperature settings to select the desired

setting (see ‘Temperature guide’ on page 7).

When the temperature is reached, the

temperature indicator lights (15) will stop ﬂashing

and you can start ironing.

Quick start guide For more detailed information on using

your ATOMiST vapour iron, please read this

instruction manual.

Download the QR Reader App on your smart phone and scan

the QR code to see a visual demonstration of the ATOMiST iron.

or visit http://www.morphyrichards.co.uk/redeﬁne/how-to

this is where the similarity ends

this is where the exceptional begins

... the premium, highly innovative Morphy Richards product group.

Driven by principles of innovation and providing exceptional quality, the

Redeﬁne range is designed to fulﬁl the consumer need for brilliantly performing

products that have equal aesthetic consideration.

Now there’s a new way to iron: our

innovative ATOMiST vapour iron with

patented thermoglass and vapour mist

technology is designed to be gentle on

your garments while efﬁciently removing

the toughest of creases with ease.

The ATOMiST vapour iron is based on the

scientiﬁc principles of crease removal,

delivering the right amount of heat,

pressure and moisture for easier ironing,

without the need for steam.

It’s time to redeﬁne

your expectations.

1 Vapour mist nozzle

This patented technology makes ironing easy and gives

your clothes a superior ﬁnish without the need for steam,

using 75% less energy.

2 Precision vapour mist trigger

Simply press and hold to activate the mist that penetrates

deep into the ﬁbres to remove creases with ease. You can

apply a light mist to your garments before you start ironing

or apply a heavier mist for more stubborn creases. You

should not need to press the trigger at all times.

3 Thermoglass soleplate

This patented technology means the iron heats up quickly

and the impact resistant ceramic glass lets you see the

creases disappear as you iron.

4 Precision temperature control / Standby

One-touch heat selection lets you select the right

temperature for your clothes with ease.

One touch selection turns on your vapour iron. Press and

hold for three seconds to turn your vapour iron off / into

standby.

5 Limescale free

The patented vapour mist technology means no more

limescale build up and no need for cartridges.

6 Removable water tank

Easy to ﬁll straight from the tap, the iron uses 80% less

water and gives you up to 2 hours continuous ironing time.

7 A better experience

The vapour mist system is surprisingly quiet and doesn’t

create humidity like steam irons can.

8 Ergonomic design

The lightweight iron can be replaced on the heat-safe iron

rest (13) whilst ironing. The base is easy to carry and keep

the cable tidy for storage.

9 Power cable

Plug into the mains outlet to power the appliance.

10 Power cable storage

When the product is not in use, the power cable may be

stored here to keep the cable tidy.

11 Power light

This light remains constantly lit throughout use, except

when the auto shut-off feature is activated.

12 Vapour mist cord

Takes water from the water tank for applying vapour to

your garments.

13 Iron rest

With rubber heat-resistant pads to safely rest your iron

whilst in use.

WARNING: The metal area of the iron rest may get hot

during use.

14 Base

The easy to carry base pumps the water from the water

tank up through the vapour mist cord.

15 Temperature indicator lights

Flash until the selected temperature is reached and the

iron is ready to use.

Temperature

guide

Heat setting markings in the temperature

guide (below) match those of the International

Textile Care Labelling Code. Please check your

garment label before ironing to avoid damage.

Symbol (210ºC Max) Hot(120ºC Max) Cool (160ºC Max) Warm MAX setting

(220ºC)

Before use

Unwind and straighten the power cable (9) and vapour

mist cord (12).

For ﬁrst use, follow the ‘Quick Start Guide’ on page 3.

NOTE: When you have plugged in your ATOMiST

vapour iron, press the precision temperature control (4)

once to turn the product on.

NOTE: For ﬁrst use, you will need to hold the precision

vapour mist trigger (2) for up to one minute before

water vapour is produced from the vapour nozzle (1). It

is normal for the product to make a loud noise during

this process.

Textiles and clothes should carry ironing instructions.

If not, follow the temperature guide above, but test

the temperature by ironing the hem of the garment

or similar discreet area ﬁrst. It is advised to begin with

‘cool’ fabrics and work up to higher settings. An iron

heats up quicker than it cools down so you’ll save time

and electricity.

If you turn the temperature down from a hot setting to

a cooler setting, wait until the temperature indicator

lights (15) have stopped ﬂashing before you continue

ironing.

NOTE: Hold the base with both hands when handling,

moving and storing the unit.

Filling

Never use battery topping up ﬂuid or water

containing any substances like starch, sugar,

fragrant additives or defrosted water from a

refrigerator.

Unlike conventional irons, the ATOMiST vapour iron

is designed for use with tap water.

Re-filling during use:

If you press the precision vapour mist trigger (2), and

the water level is low, the vapour nozzle (1) will ﬂash,

a beep will be heard, and the unit will not produce

vapour. If this happens, remove the water tank (6) and

reﬁll with water (see steps 1 and 2 of ‘Quick Start Guide’

on page 3) and replace the water tank.

NOTE: You can still use your product without vapour.

Fabric Nylon,

Acetates,

synthetic

fabrics

Cotton,

Linen Rayon,

Rayon

mixtures

Wool,

Polyester

mixtures

Linen

Control Do not iron • ••••• MAX

Features

Dry ironing:

To use your ATOMiST vapour iron as a dry iron only,

follow steps 3, 4 and 6 of ‘Quick Start Guide’ on page

3. You do not need to put water in the tank (6).

Auto shut-off:

If the ATOMiST vapour iron is not used for 10 minutes,

the product will automatically enter standby mode,

both for safety and to save energy.

Wake the product by pressing either the precision

temperature control (4) or the precision vapour mist

trigger which will illuminate the power light (11). The

previous temperature setting will be restored.

Please wait until the temperature indicator lights (15)

stop ﬂashing before resuming ironing.

Emptying and

storing

When you have ﬁnished Ironing, press and hold the

precision temperature control (4) for three seconds to

switch the ATOMiST vapour iron into standby.

Unplug and empty all water from the water tank and

place the iron on the base (14). Use the power cable

storage hole (10) to keep the power cable (9) tidy.

NOTE: Do not store the vapour mist cord (12) in the

power cable storage (10), this is for the storage of the

power cable (9) only.

Maintenance

To clean the Thermoglass soleplate:

Wait until cold and use a damp cloth and mild

detergent to wipe over, then wipe dry. Do not spray

detergent directly onto the soleplate.

To remove fibres from the Thermoglass

soleplate:

If any man-made ﬁbres fuse to the Thermoglass

soleplate (3), set the iron to the 3-dot or MAX position

and pass it over a clean piece of cotton to draw the

deposit off the surface.

To clean the exterior:

Allow the unit to cool and wipe over with a damp cloth

and mild detergent, then wipe dry.

Troubleshooting

There is a loud noise when I press the

precision vapour mist trigger (2).

Solution

•This is normal when you operate the product for the

ﬁrst time as the vapour system is being primed.

•If you hear a loud noise but no vapour is sprayed,

check for blockages as above.

When I press the precision vapour mist

trigger (2), no vapour sprays from the

vapour mist nozzle (1) but the nozzle

flashes and beeps.

Solution

•Check the water tank (6) is full and the base (14) is

resting on a level surface. The water may be below

the minimum level.

•If the water tank is full, check the water tank is

correctly located in the base.

When I press the precision vapour mist

trigger (2) the nozzle light turns on, I can

hear the pump but no water sprays out

of the vapour mist nozzle (1).

Solution

•There may be a blockage in the vapour system. You

need to remove the vapour mist nozzle (1):

1Turn the clear nozzle cover anti-clockwise until it is

released.

2Unscrew the nozzle by rotating it anti-clockwise.

3Tap the vapour nozzle gently on a hard surface to

remove any loose debris.

4Plug the product in and press the precision vapour

mist trigger (2) for around 30 seconds to remove any

blockages from the system. Do this over a sink or

suitable container.

NOTE: Water will jet out under high pressure.

Reassemble the vapour nozzle and nozzle cover;

this is a reversal of the removal procedure. Press the

precision vapour mist trigger to test the system. If

the system is still blocked, repeat the process or call

our helpline for further instructions.

Helpline

If you are having a problem with your appliance,

please call our Helpline, as we are more likely to be

able to help than the store you purchased the item

from. Please have the product name, model number

and serial number to hand when you call to help us

deal with your enquiry quicker.

UK Helpline 0344 871 0945

EIRE Helpline 1800 409 119

Talk To Us

If you have any questions or comments, or want

some great tips to help you get the most out of your

products, join us online:

Website www.morphyrichards.co.uk/redeﬁne

Blog www.morphyrichards.co.uk/blog

Facebook facebook.com/morphyrichardsuk

Twitter @loveyourmorphy

Email [email protected]

The iron does not get hot enough. Solution

•Check the garments are not too damp through the

use of too much vapour mist.

•Check that the temperature indicator light (15) is set

to the right level (see ‘Temperature guide’ on page

7).

The temperature will default to MAX when the iron

is ﬁrst turned on.

Troubleshooting (continued)

The iron is plugged in and switched on

at the socket but will not heat up.

Solution

•This product has an auto shut-off feature. Check

that this has not been activated by pressing either

the precision vapour mist trigger (2) or the precision

temperature control (4) which will wake the product.

•Check that the thermoglass soleplate (3) is not

damaged. For your safety, this product will not

power up if it is damaged.

•Check that the main fuse board in your house has

not tripped. If tripped, contact the customer helpline

(see below).

•Check the fuse in the plug.

Table of contents

Other Morphy Richards Iron manuals

Morphy Richards

Morphy Richards 40725 User manual

Morphy Richards

Morphy Richards RN40715 User manual

Morphy Richards

Morphy Richards ELITE STEAM GENERATOR - REV 1 User manual

Morphy Richards

Morphy Richards 40684 User manual

Morphy Richards

Morphy Richards IB421XX User manual

Morphy Richards

Morphy Richards COMFIGRIP User manual

Morphy Richards

Morphy Richards RN40635 User manual

Morphy Richards

Morphy Richards IB40702 User manual

Morphy Richards

Morphy Richards Turbosteam User manual

Morphy Richards

Morphy Richards RN303100MUK User manual

Morphy Richards

Morphy Richards Comfigrip Advanced 40741 User manual

Morphy Richards

Morphy Richards SPEED STEAMPRO User manual

Morphy Richards

Morphy Richards IB40460 User manual

Morphy Richards

Morphy Richards VAPOCARE User manual

Morphy Richards

Morphy Richards Saturn IntelliTemp 305003 User manual

Morphy Richards

Morphy Richards Jet Stream Elite S User manual

Morphy Richards

Morphy Richards 40734 User manual

Morphy Richards

Morphy Richards ELITE 42288 User manual

Morphy Richards

Morphy Richards INTELLIDOME User manual

Morphy Richards

Morphy Richards SEMI-ELECTRONIC 40715 User manual

Morphy Richards

Morphy Richards COMFIGRIP RN40854 User manual

Morphy Richards

Morphy Richards JET STREAM User manual

Morphy Richards

Morphy Richards SPEED STEAM Series User manual

Morphy Richards

Morphy Richards Turbosteam iron User manual

Popular Iron manuals by other brands

Clatronic

Clatronic DB 3703 instruction manual

TEFAL

TEFAL FV4093Z0 manual

Gorenje

Gorenje SIH 2200 BS instruction manual

Philips

Philips GC6012 Service manual

Bosch

Bosch 2 Series operating instructions

Riffel

Riffel Catena KB-819 instruction manual

Texi

Texi Hestia Instructions for use

Maxwell

Maxwell MW-3010 Manual instruction

TREVIDEA

TREVIDEA Girmi ST60 user manual

Philips

Philips HI5914/30 quick start guide

Primula

Primula Vapormat instruction manual

Magio

Magio MG-541 manual

Scarlett

Scarlett SC-1334S instruction manual

Bosch

Bosch Sensixx B22L manual

Philips

Philips GC651 Specifications

Vitek

Vitek VT-1247 VT Manual instruction

Cleanmaxx

Cleanmaxx 3397 instruction manual

Philips

Philips GC800 user manual
