moon Nova User manual
NOVA
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás
2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
3
read this manual carefully and keep for future reference. Visit www.moon-sport.com for
manual updates
Features
1 CREE XH-G high brightness LED
AA alkaline battery
Water resistant (IPX 4)
3 steady modes, 2 flashing modes
Quick release handlebar mount (fits 22-31.8mm)
High precision optical lens
Side visibility
Contents
NOVA
AA alkaline battery
RB-07 (Handlebar bracket)
Optional accessories:
RB-06 (Helmet bracket)
4
Operation
1. Press power button to turn on the light.
2. Press power button to choose modes.
3. Double click power button to toggle
between steady and flashing modes.
4. Press power button for 1 sec to turn off the light.
Mode 1
Mode 2
Mode 3
Power button
Press
Double click
FL 1
FL 2
5
Mode 1
Mode 2
Mode 3
FL 1
FL 2
LUMEN
20 40 100 40 100
H: MIN
13:00
6:00
3:00
11:00
10:00
Total
Angle
Spot
Angle
6
Handlebar mounting
1. Install the bracket onto handlebar by wrapping rubber strap
around post/bar and stretching strap around hook to secure.
2. Slide headlight forward onto bracket until it clicks into place.
3. Press down release lever to remove.
Install
Release
Press
Click
Release
Lever
Rubber
strap
7
Helmet mounting (Optional)
1. Wrap belt around helmet and return the belt onto slotted space.
2. Twist screw knob clockwise until tight.
3. Slide headlight forward onto bracket until it clicks into place.
4. Press down release lever to remove.
5. To adjust the vertical beam angle when mounted on the
helmet, loosen the screw knob and rotate the light up or
down to your preferred angle, then tighten the screw knob to
secure the light in place.
Install
Click
Press
Press
Release
Screw
knob
Release
lever
Belt
8
Battery instalation
1. Twist the light cap to remove the battery case.
2. Tick out and remove the battery for replacement.
3. Install new battery.
Light cap point
Open
Light cap point
Align
Release
Install
9
4.Align the “point O” to the light cap point. Install the battery
case into the light body.
5. Turn the light cap clockwise until the “point L” align the
light cap point.
Unplug the battery if no use
Tick out
Battery case
Close
10
Warning
* Understand country lighting laws and regulations before use.
* Do not shine directly in the eyes.
* Light may get hot when in use.
* Adjust the angle downward to prevent from blinding the
oncoming vehicles on the public roads.
* Do not submerge the battery or the whole light into water.
* Unplug the light once the battery is fully charged.
* Do not dismantle the light which will void warranty.
* Do not leave the light on and unattended.
* Keep the light away from fire and combustible materials.
* Do not store head unit when hot or straightway after use.
* Release the battery before storage to prevent light turning on.
