Cateye V2C - Instruction manual

The purpose of this quick-start manual is to help you more easily navigate the new V2c (CC-

TR200DW) wireless speed & cadence cyclo-computer. (This setup sequence will delete all data in

computer and restore to the factory default settings.)

First make sure to remove the paper tab behind the battery in the computer head unit.

1. Press and hold the silver MENU button on the back of the head unit. Then use a

paperclip to press the silver AC button for several seconds. Continue to hold the

MENU button as the screen shows all available characters then stops at a screen with

a large 24h on the top part of the screen.

2. Select your preferred date format (YY/MM/DD) by pressing the M1/+ button (top right).

Confirm your selection by pressing the SSE button (bottom left).

3. Enter the “Year”, “Month”, and “Day” in the display order selected in step 2 using the

M1/+ and M2/-. Confirm each unit using the SSE button.

4. Select the clock display format (24h vs. 12h) using the M1/+. Confirm using SSE.

5. Enter the “Hour” and “Minute” using the M1/+ and M2- (please pay attention to the

AM/PM indication at the bottom right). Confirm using SSE.

6. After you set the date/clock press the silver MENU button on back to proceed.

7. Enter the tire circumference on the bicycle wheel in millimeters (tire size chart

available in product manual or at www.cateye.com) Enter the last two digits of the tire

circumference by using the M1/+ and M2/-. Confirm with SSE. Now enter the first two

digits the same way using M1/+ and M2/-. Confirm with SSE.

8. After choosing the tire circumference measurement press the silver MENU button on

the back.

9. While holding the computer head unit near the sensor, press and release the SSE

button, then pass a magnet back and forth across one of the sensor zone areas. l

Searching is completed when the screen display reads “ID-OK”

10.Press the silver MENU button on the back to select speed unit. Use M1/+ to toggle

between mile and km. To confirm press the silver MENU button on the back.

The setup is now complete. The unit is ready to use.

Note: The data accumulated on a single ride can be zeroed out by pressing SSE and M2/-

simultaneously then releasing the buttons.

Operation Test – to test for proper installation and function of the speed/ cadence sensor

follow these steps:

1. After programming the computer head unit, start by pushing the M1/+ button

once

2. Raise the rear wheel, spin, when numbers show up on the top row the speed

sensor is operating normally

3. Turn the crank, when numbers show up in the middle section of the screen the

cadence sensor is operating normally

4. If either the Speed or Cadence measurements fail to operate normally you will

need to re-adjust the magnet position. You will need to adjust the magnet

sensor position to get the magnet within 5mm or less from the sensor pickup

zones.

MENU – Additional features you may wish to modify after you have completed the head unit

programming

1. FILE VIEW – to view file info press the silver MENU button on the back, then SSE to

view file info, to scroll through lap data use the M1/+ and M2/2 buttons, when done

press silver MENU button on back of computer

NOTE: ride data must be 00 to make changes to cadence zone. To do this you must return to the

main MENU then simultaneously press the SSE & M2/- buttons for several seconds then release

2. Cadence Zone – to setup cadence zone press the silver MENU button on the back,

press M1/+ until you get to the CDC.ZONE screen, then SSE, then press M1/+, then

SSE so that the lower number flashes, use the M1/+ and M2/- to select the lower

cadence limit, when finished press SSE, use M1/+ and M2/- to select the upper

cadence limit, SSE will toggle you though the zone numbers again in case you need to

make any changes, press silver MENU button to confirm

3. Sound – to set sound press the silver MENU button, then press M1/+ until you get to

the SOUND screen, then SSE, M1/+ will toggle the CDC. ALARM sound between On

and Off, press SSE, M1/+ will toggle BUTTOn sound between On and Off. MENU

button to confirm.

4. Count Down Distance – to enter a target trip distance for the countdown distance

feature press the silver MENU button on the back, press M1/+ until you get to the C.D.

DST screen, press SSE, use M1/+ and M2/- to choose far right digit, press SSE to

index one digit to the left, M1/+ and M2/- to set next digit, SSE to scroll to the next

digit, when complete press silver MENU button

5. Auto Mode – to switch between the auto and manual ride recording features– press

the silver MENU button, press the M1/+ until you get to the AUTO MODE screen.

Press SSE, then press M1/+ to toggle between On and OFF, press silver MENU

button to confirm

6. Odometer Input – to enter previous odometer miles press the silver MENU button,

press the M1/+ until you get to the ODO INPUT screen. Press SSE to start entering

an odometer number starting with the far right number first. Use the M1/+ and M2/- to

toggle though each number, press SSE to move over to the next digit to the left.

When complete press silver MENU button on back of computer

NOTE: ride data must be 00 to make changes to measurement unit. To do this you must return to

the mail MENU then simultaneously press the SSE & M2/- buttons for several seconds then release

7. Unit - to change unit of measure from mph to kmh press the silver MENU button on

the back of the computer, then press SSE, use the M1/+ to toggle between mile and

km, to confirm press the silver MENU button on the back

8. Sensor-ID – to check or change sensor ID press the silver MENU button on the back

of the computer, press the M1/+ until you get to the SENSOR-ID screen, then press

the SSE button to view the sensor number. To change or re-sync sensor press SSE

then spin your rear wheel until the “ID-OK” screen appears

9. Wheel: to change tire size press the silver MENU button on the back, then M1/+ until

you get to the WHEEL screen. You may set two tire sizes. The “A” tire size will be

visible first. Press SSE to get the “A” to flash. To set up the “B” tire size for use on a

second bike press the M1 /+ so that Wheel: “B” is showing. (If you do not want to

program an additional tire size just press the SSE button while the “A” flashes) Now

use the M1/+ and M2/- to program the last two digits, then press the SSE to get the

first two digits to flash, use the M1/+ and M2/- to set the first two digits. When

complete press the SSE button. From here you can program the “B” tire size by

pressing the M1/+ button while the “A” is flashing. After toggling to the “B” you will

press SSE and follow the process above. Once complete press the silver MENU

button

10.Clock.Date – to set the clock/ date press the silver MENU button on the back, then

M1/+ to toggle to the CLOCK.DATE screen. Press the SSE to get the hour

measurement to flash, press the M1/+ button to toggle between 12h and 24h clock,

press SSE to select 12h vs 24h clock with the M1/+ & M2/+ buttons, press SSE to set

minutes using M1/+ & M2/-, press SSE to get to the date measurement area to flash,

use the M1+ button to toggle between date formats, to select date format press SSE,

now the far right column of numbers will flash, use the M1/+ & M2/- to toggle through

numbers, press SSE to index over to the next measurement to the left, use M1/+ and

M2/- to toggle through numbers, press SSE to index to the next measurement to the

left, use M1/+ and M2/- to toggle through numbers, press SSE, if you made a mistake

with any of the numbers you may fix it here by pressing the SSE button until you get to

the number that needs to be changed, then use the M1/+ and M2/- to make any

changes, when satisfied press the silver MENU button on the back
