Montpellier MDI650X User manual

Operating Instructions - Dishwasher Montpellier MDI650X-

K-W

Control panel

1. Power On/Off Button

2. Remaining Time Indicator – Displays the programme times and remaining time on a programme.

You can adjust the delay timer by pressing the buttons on the indicator before the programme

starts.

3. Door Handle

4. Tablet Detergent Button – Press this button when using combined detergents that include salt

and rinse-aid.

5. Pre-Wash Button – This function improves washing performance by changing the water

temperature and washing time of some programmes. If a programme is not compatible with this

function, a buzzer will sound.

6. ½ Load Button – Using this function, 3 different sorts of washing can be done: The lower basket,

upper basket and both baskets.

For dishes in both baskets press the half load button and select the position in which both lamps

are highlighted.

For dishes only in the upper basket, press the half load button until just the upper lamp is

highlighted.

For dishes only in the lower basket, press the half load button until just the lower lamp is highlights.

Please note: To deactivate this function for a new program press the selected feature button again,

the indicator lamp goes out.

7. Start/Pause Button –To start or pause your wash programme.

8. Programme Select Knob –To select a suitable wash programme.

9. Salt Warning Indicator – When more salt is needed a warning indicator will come on.

10. Rinse Aid Warning Indicator – When more rinse aid is needed the rinse aid warning indicator will

come on.

11. Programme Monitor Lights – Programme status can be monitored via lights showing, Wash, Rinse,

Dry, End.

12. Child Lock –To activate the child lock, press “+” and “-“ on the remaining time indicator

simultaneously for 4 seconds, “CL” will appear for 2 seconds on the remaining time indicator.

Holding these buttons down again will remove the lock and “CL” will blink

Adding dishwasher detergent

Push the latch to open the detergent container as shown in image 1. The level lines can help to

measure the amount of detergent you use.

If the programme selected has a pre-wash cycle you should add detergent to the pre-wash

compartment (a).

Selecting a programme

•Press the power ON/OFF button

•Select your programme via the programme selection button

•Start programme by using the power start/pause key

Changing a programme

•Press once the power start/pause button

•After the programme stops, select your desired programme using the programme selection

button

•Start the programme by pressing the start/pause key

Cancelling a programme

•Press the start/pause button

•Turn programme selection button to reset

•The finished indicator lamp will turn on

•Press the power/start button once – the machine will discharge water for 30 seconds.

Programme selection table
