Monessen Hearth ILDV30 User manual

REVEAL DIRECT VENT INSERT SYSTEM

Monessen

Introducing t e Reveal from Monessen.

It’s easy to turn an old inefficient masonry fireplace into a cozy cost-effective heat source with

a direct vent insert from Monessen. Our Reveal insert is the perfect choice. With a large

viewing area, 30,000 BTUs and a host of sensible options, the Reveal will show you just what

a fireplace can do for your home. Standard features include Cottage Clay firebrick, a variable

thermostat controlled forced air blower and Natural Flame™ burner with a strikingly realistic

fiber ceramic log set. The valve is located conveniently on the outside of the box for easy

access and maintenance, and two styles and colors of designer facings make the unit a

perfect fit for any room.

MON7508INT_REVEAL_ILDV_DV_FNL.qxd:Final2007T mplat _V rmont_CastingsREVSt ph.qxd 11/6/08 5:00 PM Pag 1

To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the

product and all applicable building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this brochure

are for illustrative purposes only and are not intended for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the product

A Brand of Monessen Heart Systems Co.

149 Cleveland Drive, Paris, Kentucky 40361

www.monessenhearth.com

Ver.01 MON7508INT

Monessen

Direct Vent Insert System

Standard Features Surrounds & Options

Your Monessen Dealer:

HPBA

Hearth, Patio & Barbecue Association

MADE IN U.S.A.

On/Off shut-off valve with easy access panel

conveniently located on side of the firebox

Colonial and Bevelled surrounds offered in

Iron Age and Black Texture

Bevelled

Colonial

Model ILDV30

BTU / HR 30,000

FE Ratings (Cdn. Fireplace Efficiency) 71.9% NG / 83.7% LP

Afue Efficiency 66% NG / 69% LP

T ermal Efficiency Up to 80%

Dimensions (Actual) 34 3/8”W x 20 3/4”H x 17 5/8”D

Minimum Fireplace Opening 28”W (Front width) x 21”H x 16”D x 20” (Rear width)

Glass Viewing Area 409 sq. in.

• Clean face design

• Viewing area: ILDV30 409 sq. in.

• Natural Flame™ burner with fiber ceramic log set

•

Cottage Clay

firebrick

• Optional surrounds

• Thermostat blower (160 cfm) standard

• 3" flue outlet

• 18" flex line with On/Off shut-off valve

• CSA design certified

ILDV30 with Black Texture Bevelled surround

Cottage Clay

Firebrick Detail

Image on front - ILDV30 with Iron Age Colonial surround Colonial surround features cast iron 4 3/4” mantle shelf

MON7508INT_REVEAL_ILDV_DV_FNL.qxd:Final2007T mplat _V rmont_CastingsREVSt ph.qxd 11/6/08 5:00 PM Pag 2
