ML Accessories BL01BK Instruction Manual

INSTALLATION & MAINTENANCE MANUAL

BL01BK

These instructions should be read carefully and retained after installation by the

end user for future reference and maintenance.

These instructions should be used to aid installation of the following product:

BL01BK

GENERAL INSTRUCTIONS

SAFETY

• This product must be installed in accordance with the latest edition of the IEE Wiring

Regulations (BS7671) and current Building Regulations. If in any doubt, consult a

qualiﬁed electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this product is ﬁtted) does not exceed

the rating of the circuit cable, fuse or circuit breaker

• Please note the IP (Ingress Protection) rating of this product when deciding the location

for installation

• This product is Class I and must be earthed

• This product is IP44 rated

INSTALLATION & MAINTENANCE MANUAL

These instructions should be read carefully and retained after installation by the end user for future reference

and maintenance.

These instructions should be used to aid installation of the following product:

BL01BK

SAFETY

•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations

(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician

•Please isolate mains prior to installation or maintenance

•Check the total load on the circuit (including when this product is fitted) does not exceed the rating of

the circuit cable, fuse or circuit breaker

•Please note the IP (Ingress Protection) rating of this product when deciding the location for installation

•This product is Class I and must be earthed

•This product is IP44 rated

INSTALLATION

•Provide power to the required point of installation (refer to BS7671 for correct cabling methods).

Suitable IP rated junction boxes should be used where required

•Round cable should be used for the mains supply. The use of flat cable will cause water ingress to the

fitting

•Carefully remove the fascia and glass from the luminaire housing by unfastening the two screws on the

front (see Fig. 1)

Fig .1

•Cut a suitable recess in the mounting surface, mark the location of the fixing holes, and drill the holes

ensuring not to infringe with any gas/water pipes or electrical cables

•Feed the mains cable through the rubber grommet to retain IP rating and secure the luminaire housing

into the hole using the plugs and screws provided. Rubber washers or sealant should be applied

around the screw heads to prevent water ingress. Mortar around the luminaire housing if necessary

and allow to set before continuing

•Connect the luminaire to the mains supply ensuring the correct polarity is observed: L –Live (brown),

E –Earth (green/yellow), N –Neutral (blue). Oversleeving is provided to help protect the incoming

mains cable. The cable and terminal block should be kept away from the lamp to prevent heat damage

•Insert a suitable E27 lamp (not included), max. 40W

•Refasten the glass (frosted side in) and chosen fascia ensuring the gasket is in place and a tight seal

is made

•Switch on and check for correct operation

•Should the protective glass be cracked or damaged it should be replaced immediately

•This fitting must not be used without the protective glass installed

WARNING

This product must be disconnected from the circuit if subjected to any high voltage or insulation resistance

testing. Irreparable damage will occur if this instruction is not followed.

This product is not suitable for direct installation in the ground, nor in a retaining wall where the ground behind

may become saturated.

This product is not suitable for installation in or near a coastal or marine environment.

INSTALLATION

• Provide power to the required point of installation (refer to BS7671 for correct cabling

methods). Suitable IP rated junction boxes should be used where required

• Round cable should be used for the mains supply. The use of ﬂat cable will cause water

ingress to the ﬁtting

• Carefully remove the fascia and glass from the luminaire housing by unfastening the two

screws on the front (see Fig. 1)

• Cut a suitable recess in the mounting surface, mark the location of the ﬁxing holes, and

drill the holes ensuring not to infringe with any gas/water pipes or electrical cables

• Feed the mains cable through the rubber grommet to retain IP rating and secure the

luminaire housing into the hole using the plugs and screws provided. Rubber washers or

sealant should be applied around the screw heads to prevent water ingress. Mortar

around the luminaire housing if necessary and allow to set before continuing

Fig. 1

WARNING

This product must be disconnected from the circuit if subjected to any high voltage or

insulation resistance testing. Irreparable damage will occur if this instruction is not followed.

This product is not suitable for direct installation in the ground, nor in a retaining wall where

the ground behind may become saturated.

This product is not suitable for installation in or near a coastal or marine environment.

• Connect the luminaire to the mains supply ensuring the correct polarity is observed:

L – Live (brown), E – Earth (green/yellow), N – Neutral (blue). Oversleeving is provided to

help protect the incoming mains cable. The cable and terminal block should be kept away

from the lamp to prevent heat damage

• Insert a suitable E27 lamp (not included), max. 40W

• Refasten the glass (frosted side in) and chosen fascia ensuring the gasket is in place and

a tight seal is made

• Switch on and check for correct operation

• Should the protective glass be cracked or damaged it should be replaced immediately

• This ﬁtting must not be used without the protective glass installed

GENERAL

Clean the external surfaces with a damp cloth using a mild solution of detergent and warm

water only, do not use aggressive cleaning products or solvents which may damage the

product.

Do not use any source of high-pressure washers to maintain or clean this luminaire.

This product is dimmable dependent on lamp type

This product should be recycled in the correct manner when it reaches the end of its life.

Check local authorities for where facilities exist.

WARRANTY

This product has a warranty of 1 year from date of purchase. Failure to install this product

in accordance with the current edition of the IEE Wiring Regulations (BS7671), improper

use, or removal of the batch code will invalidate the warranty. If this product should fail

within its warranty period, it should be returned to the place of purchase for a free of

charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML

Accessories reserve the right to alter product speciﬁcation without prior notice.

DCOCT21_V1

ML Accessories Limited LU5 4LT

www.mlaccessories.co.uk
