Mitsubishi 2014 OUTLANDER User guide

Owner’s Handbook

ACAD-P08000 (4/13)

www.mitsubishicars.com

2014 OUTLANDER

Dieline -DO NOT PRINT!

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE POCKET BELOW:

1. Pre-Delivery Inspection Form (Customer Copy)

2. Triple Diamond Delivery Checklist (Customer Copy)

3. Salesperson or Key Dealership Contact’s Business Card

Owner’s Handbook

ACAD-P08000 (4/13)

www.mitsubishicars.com

2014 OUTLANDER

Dieline -DO NOT PRINT!

Thank you for buying a Mitsubishi Outlander. There’s no doubt you’ve already realized how

well your car drives on the open road. What you may not know is all the great features that

help your car perform the way it does. In the pages ahead we’re going to run through the

basics and prepare you for the road.

We’d also love to hear from you about your overall Mitsubishi experience. If you haven’t

already, please log on to www.MitsubishiSSIsurvey.com and tell us how we did. This will help

us make sure your next visit is that much better.

We hope you will visit the Mitsubishi Owner’s site where we store the latest Mitsubishi news

and special offers. Here you can also keep track of your car’s warranty and servicing needs,

get Roadside Assistance Information and tap into other owner-centric details. Just log on to

www.Mitsubishicars.com/ownersonly.

Driver’s View ..................... Page 2-3

Controls ............................ Page 4

Own the Road................... Page 5

Switches ........................... Page 6

ECO Driving ...................... Page 7

Folding and Stowing

the Second and Third

Row Seat (if equipped)...... Page 8

Technology ...................... Page 9

Audio System.................... Page 10

Display Audio System

(if equipped)..................... Page 11-12

HD Weather and Fuel

(if equipped)..................... Page 12

Bluetooth®(if equipped).... Page 13

Navigation System

(if equipped)..................... Page 14-15

FAQ’s................................ Page 16-17

Table of Contents

Driver’s View

1Side

Mirror Adjustment

......................... Page 4

2 Climate Controls................................... Page 4

3 Headlights ........................................... Page 4

4Windshield Wiper Lever........................ Page 4

5 Adaptive Cruise Control (if equipped) ... Page 5

6 Paddle Shifters (GT only) ..................... Page 5

7 Seat Heater Switch .............................. Page 5

8 Lane Departure Warning (LDW) and

Forward Collision Mitigation (FCM)

(if equipped)........................................ Page 6

9 Power Liftgate Main Switch

(if equipped)........................................ Page 6

10 ECO Mode Switch ................................ Page 7

11 Multi Information Display (MID)............ Page 9

12 Start/Stop Engine Switch

(if equipped with F.A.S.T.-key).............. Page 9

13 Audio Remote Control Buttons

(if equipped)........................................ Page 10

14 Display Audio and Navigation System

(if equipped)........................................ Page 11-12, 14

15 Bluetooth®Controls (if equipped) ......... Page 13

D- Push to select the blower speed

E- Push to select the position and

amount of air ﬂowing from the

vents

F- Push to defog windshield.

G- When the AUTO switch is

pressed, the settings are

automatically controlled.

Passenger’s side temperature

will be changed to the same

temperature set as the driver’s

side

H- Push to defog the rear windows.

A- Push to select the desired temperature

B- Push to select outside air (Indicator light off) or recirculated

air (Indicator light on)

C- Push for air conditioning ON/OFF

The outside rearview

mirrors can be adjusted

when the ignition switch

is in the “ON” or “ACC”

position or the operation

mode is put in ON or ACC.

Move the lever (A) to the

same side as the mirror

you wish to adjust.

4CONTROLS

Regular Headlights Windshield Wipers

The wipers will operate once.

INT: Intermittent intervals can be

adjusted by turning the knob A

AUTO: The wipers will be operated

automatically by rain sensor

(if equipped).

Slow

Fast

Rear Window Wiper and Washer

Adjust switch

Turn the knob Bto operate the rear

window wiper.

The wiper operates continuously

for several seconds then operates

intermittently at intervals of about 8

seconds.

Washer ﬂuid is sprayed, the wiper will

automatically operate 2 or 3 times.

Automatic Headlights (if equipped)

Headlights and other lights on.

Parking, tail, front and rear sidemarker lights, license plate

and instrument panel lights on.

Headlights and other lights turn on and off automatically

in accordance with outside light level.

All lights off

Pull lever toward driver to activate high beams.

AUTO

OFF

Dual-Zone Automatic Climate Controls (if equipped)

Side Mirror Adjustment

B GF H

D EC

A - CANCEL: To deactivate the ACC or

cruise control

B - RES +: To increase the set speed or

resume control after cancelling the

ACC or cruise control function.

C-SET-: To set the desired speed and

to reduce the set speed.

D-ON / OFF: To turn cruise control ON or OFF

E - ACC Distance Switch - Used to set or change the following distance between your vehicle and the vehicle in

front of you.

To set a cruising speed

1. Press Dand the “ACC” (if equipped) or “CRUISE” indicators will appear in the multi information display.

2. Accelerate or decelerate to your desired speed (above 25 mph). Press Cand remove your

foot from the accelerator pedal.

To accelerate or decelerate speed

Push up Bto increase set cruising speed.

Push down Cto decrease set cruising speed.

To cancel the cruising speed Press Aor press brake pedal, or press D .

OWN THE ROAD

– :SHIFT DOWN + :SHIFTUP

Paddle Shifters (GT only)

Seat Heater Switch

Position - Action

(HI) - For quick heating

(NEUTRAL) - Heater off

(LO) - To keep the seat warm

Drive Mode Selector (if equipped)

The drive mode can be switched

by pressing the drive mode button

while the ignition switch is in the ON

position.

Pressing the button will change the

drive mode in order to:

AWC ECO, NORMAL, SNOW, LOCK

Adaptive Cruise Control (if equipped)

Simply upshift or

downshift with a tap of

your ﬁngers – without

moving your hands from

the steering wheel.

You can return to the “D”

operation by pulling the +

(SHIFT UP) side paddle

shifter rearwards (toward

the driver) and holding for

over 2 seconds.

6SWITCHES

Active Stability Control (ASC) Off Switch Lane Departure Warning (LDW) Switch (if equipped)

Power Liftgate Switch (if equipped)

Power Liftgate Main Switch (if equipped)

Forward Collision Mitigation (FCM) Switch (if equipped)

You can deactivate the system by

pressing down the “ASC OFF” switch for

3 seconds or longer.

When the ASC is deactivated, the

display/indicator will turn on. To

reactivate the ASC, momentarily press

the “ASC OFF” switch; the display/

indicator is turned off.

When you press the LDW switch, the “LDW” indicator on the

information screen of the multi information display turns OFF

and the LDW system is inactive.

Press the switch again, the system will activate.

The power liftgate can be opened by

pressing the Power Liftgate Switch.

When the power liftgate main switch is ACTIVE, the

power liftgate can be operated using either the power

liftgate switch on the F.A.S.T.-key, the driver’s side

power liftgate switch or the open/close switches on

the power liftgate.

Every time the operation mode is turned to “ON”, the FCM

will automatically be turned on.

To turn off the FCM, press and hold the FCM switch. A buzzer

will sound and the “FCM OFF” message and indicator will

appear in the multi information display.

To change the warning distance mode, brieﬂy press the FCM

switch.

ECO DRIVING

ECO Drive Assist

ECO drive level

Low High

Multi information

display switch

ECO indicator

ECO mode switch

ECO Score

ECO drive level

Low High

Momentary fuel consumption display

This indicator will be displayed when fuel

efﬁcient driving is achieved.

ECO mode is an eco-driving support

system which automatically controls

the engine, air conditioning system,

4WD system (if equipped) and

S-AWC (if equipped) to improve

fuel efﬁciency.

To activate, press the ECO mode

switch.

While driving, the momentary fuel

consumption is shown with a bar

graph.

The “



” mark in the momentary

fuel gauge shows the average fuel

consumption.

When the momentary fuel consumption surpasses the average fuel

consumption, the momentary fuel consumption is displayed with a green

bar graph.

Maintaining your fuel consumption above the average fuel consumption

point will help increase your mileage per gallon.

To show, press the multi information display switch.

This function displays how fuel-

efﬁciently you are driving under

different driving conditions.

To show, press the multi

information display switch.

ECO score indicates the points

you have scored on fuel-efﬁcient

driving by the number of leaves.

To show, press the multi

information display switch.

Tire Pressure Monitoring System (TPMS)

The Tire Pressure Monitoring System light illuminates

when one or more of your tires is signiﬁcantly under

inﬂated. Please note that changes in the outside

temperature may decrease tire pressure causing the

TPMS light to turn on. If the TPMS

light remains illuminated, check your

tire pressure.

If the warning light illuminates, take the necessary

measures referring to the owner’s manual.

1. Slide the seat all the way to the rear by pulling up on the sliding

lever located under the bottom of the seat and pushing to the back.

2. Pull up on the front edge of the bottom seat cushion and raise it up.

Then lift the back side of the bottom seat cushion up and ﬂip it over

toward the front side as you rotate the bottom seat cushion into the

foot well area.

3. Once the seat cushion is ﬂipped forward, slide the lever (A) which

is now visible, forward into the “seat ﬂat” position to lock the seats

down.

1. Remove Headrests from storage hook on folded seat cushion.

2. Raise the seatback until it locks into place.

3. Make sure the seat belt buckles are up (D) (Figure 3) and gently

lift the seat cushion and fold it back into position making sure the

hook (E) slides below the seatback bottom. Press down on the seat

cushion to lock into place.

4. Replace headrests.

1. Remove the head restraints.

2. Pull up the strap (A), then fold the seatback forward.

3. To return, pull the strap (B), then raise the seatback until it locks

securely into place.

FOLDING AND STOWING THE SECOND AND THIRD ROW SEAT (if equipped)

Folding the second row seats Unfolding the second row seats

Folding the third row seat

4. Remove the headrests by pushing the button on the headrest post

and then lifting up on the headrest simultaneously. Place the

headrest out of the way. (The middle headrest can remain in the

lowest position).

5. Now pull the lever on the top of the backrest (B) and lower the seat

forward so it lays ﬂat.

6. Grab the headrest and face it forward. Find the slit on the bottom

rear of the headrest and place it on the metal hook located on the

middle part of the folded seat cushion (C). Place your other hand on

the back of the headrest and gently push it down until you hear and

or feel it lock into place.

Figure 3

Table of contents

Other Mitsubishi Automobile manuals

Mitsubishi

Mitsubishi LANCER EVOLUTION 2003 Operating instructions

Mitsubishi

Mitsubishi COLT User manual

Mitsubishi

Mitsubishi 3000GT Instruction manual

Mitsubishi

Mitsubishi Outlander Phev 2020 User manual

Mitsubishi

Mitsubishi COLT User manual

Mitsubishi

Mitsubishi ECLIPSE User manual

Mitsubishi

Mitsubishi Pajero Sport 2013 Instruction Manual

Mitsubishi

Mitsubishi Starion Turbo User manual

Mitsubishi

Mitsubishi Mirage 2017 User manual

Mitsubishi

Mitsubishi Lancer Evolution-VII Instruction manual

Mitsubishi

Mitsubishi LANCER EVOLUTION 2003 Technical document

Mitsubishi

Mitsubishi i-MiEV 2017 User manual

Mitsubishi

Mitsubishi ECLIPSE CROSS 2017 User manual

Mitsubishi

Mitsubishi Pick-Up 1987 User manual

Mitsubishi

Mitsubishi Pajero User manual

Mitsubishi

Mitsubishi FTO Series User manual

Mitsubishi

Mitsubishi FTO Series User guide

Mitsubishi

Mitsubishi Eclipse Cross 2019 User guide

Mitsubishi

Mitsubishi LANCER 2017 User guide

Mitsubishi

Mitsubishi 3000GT Instruction manual

Mitsubishi

Mitsubishi 2013 Outlander User manual

Mitsubishi

Mitsubishi i-MiEV User manual

Mitsubishi

Mitsubishi 2015 OUTLANDER User guide

Mitsubishi

Mitsubishi TDJS Series User manual

Popular Automobile manuals by other brands

Toyota

Toyota 2000 Tundra owner's manual

CITROËN

CITROËN DS4 DSign Handbook

Lexus

Lexus 2015 CT 200h owner's manual

Cadillac

Cadillac CTS 2008 owner's manual

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Operator's manual

Porsche

Porsche Boxster S Technical manual

GMC

GMC 2010 Savana 1500 Cargo owner's manual

KIAM

KIAM SPORTAGE 2014 Features & functions guide

GMC

GMC 2013 Terrain Getting to know

GMC

GMC T-Series 1999 owner's manual

Mercury

Mercury 1998 Mystique owner's manual

Mercury

Mercury 2007 Mariner Quick reference guide

Mazda

Mazda 2007 Mazdaspeed 3 Smart start guide

Mazda

Mazda 2014 CX-5 owner's manual

GMC

GMC Chevrolet Express 2022 owner's manual

GMC

GMC 1997 Jimmy owner's manual

Chevrolet

Chevrolet 2012 Malibu owner's manual

Cadillac

Cadillac 2010 Escalade manual
