PART Ⅰ: Generic VersionMDW12RSS / MDW12RBS / MDW12RWHPlease read this manual carefully before using the dishwasher and Keep this manual for future reference.

SAFETY INFORMATION3CONTENTSPRODUCT OVERVIEW8USING YOUR DISHWASHERBasket Used Tips99MAINTENANCE AND CLEANINGExternal CareInternal CareCaring For The Dishwasher11111114INSTALLATION INSTRUCTION 151516171818NOTE:Reviewing the section on troubleshooting Tips will help you solve some common problems by yourself.If you cannot solve the problems by yourself, please ask for help from a professional technician.The manufacturer, following a policy of constant development and updating of the product, may make modifications without giving prior notice.If lost or out-of-date, you can receive a new user manual from the manufacturer or responsible vendor.About Power ConnectionWater Supply And DrainConnection Of Drain HosesPosition The ApplianceFree Standing InstallationBuilt-In Installation(for the integrated model)TROUBLESHOOTING TIPS2428LOADING THE BASKETS ACCORDING TO AS/NZS 2007.119

SAFETY INFORMATIONWARNINGWhen using your dishwasher , follow the precautions listed below:Installation and repair can only be carried out by a qualified technicianThis appliance is intended to be used in householdand similar applications such as:-staff kitchen areas in shops, offices and other working environments;-farm houses;-by clients in hotels, motels and other residential typeenvironments;-bed and breakfast type environments.This appliance can be used by children aged from 8years and above and persons with reduced physical,sensory or mental capabilities or lack of experienceand knowledge if they have been given supervision orinstruction concerning use of the appliance in a safeway and understand the hazards involved.Children shall not play with the appliance. Cleaning and user maintenance shall not be done by children without supervision. (For EN60335-1)This appliance is not intended for use by persons (including children ) with reduced physical, sensory or3

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. (For IEC60335-1 )Packaging material could be dangerous for children!This appliance is for indoor household use only.To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.Please unplug before cleaning and performing maintenance on the appliance.Use a soft cloth moistened with mild soap, and then use a dry cloth to wipe it again.Earthing Instructions4This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of an electric shock by providing a path of least resistance of electric current. This appliance is equipped with an earthing conductor plug.The plug must be plugged into an appropriate outlet that is installed and earthed in accordance with all local codes and ordinances.Improper connection of the equipment-earthing conductor can result in the risk of an electric shock. Check with a qualified electrician or service representative if you are in doubt whether the appliance is properly grounded.

Do not modify the plug provided with the appliance; If it does not fit the outlet. Have a proper outlet installed by a qualified electrician.Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out.Do not place any heavy objects on or stand on the door when it is open. The appliance could tip forward.When loading items to be washed:1) Locate sharp items so that they are not likely to damage the door seal; 2) Warning: Knives and other utensils with sharp points must be loaded in the basket with their points facing down or placed in a horizontal position.Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the skin and eyes and keep children away from the dishwasher when the door is open.Check that the detergent powder is empty after completion of the wash cycle.5

6Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent. For unmarked plastic items not so marked, check the manufacturer's recommendations.Use only detergent and rinse agents recommended for use in an automatic dishwasher.Never use soap, laundry detergent, or hand washing detergent in your dishwasher.The door should not be left open, since this could increase the risk of tripping. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.During installation, the power supply must not be excessively or dangerously bent or flattened.Do not tamper with controls.The appliance needs to be connected to the main water valve using new hose sets. Old sets should not be reused.To save energy, in stand by mode , the appliance will switch off automatically while there is no any operation in 30 minutes .

DisposalFor disposing of package and the appliance please go to a recycling center. Therefore cut off the power supply cable and make the door closing device unusable. Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.For more detailed information about recycling of this product, please contact your local city office and your household waste disposal service.DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. 7

PRODUCT OVERVIEWTo get the best performance from your dishwasher, read all operating instructions before using it for the first time. DispenserFilter assemblyLower spray armInner pipeIMPORTANT:8Cutlery basketupper spray armUpper basketLower basketCup rackPictures are only for reference, different models may be different. Please prevail in kind.NOTE:

USING YOUR DISHWASHER1. Loading the basket2. Fill the rinse aid dispenser (Please check the section 1 of PART Ⅱ: Special Version) 3. Fill in detergent (Please check the section 1 of PART Ⅱ: Special Version) 1. Loading the basket2. Fill the rinse aid dispenser (Please check the section 1 of PART Ⅱ: Special Version) 3. Fill in detergent (Please check the section 1 of PART Ⅱ: Special Version) 9Adjusting the upper basketThe height of the upper basket can be easily adjusted to accommodate taller dishes in either the upper or lower basket.To adjust the height of the upper rack, follow these steps:Type 1:Basket Used TipsBefore using your dishwasher :Inside Outside41Pull out the upper basket.2Remove the upper basket.3Re-attach the upper basket to upper or lower rollers.Push in the upper basket.lower positionupper position

10raise upwardsfold backwards1To raise the the upper basket at the center of each side until the basket locks into place in the upper position. It is not necessary to lift the adjuster handle.upper basket just lift ,2To lower the lift the adjust handles on each side to release the basket and lower it to the lower position.upper basket, Type 2:Folding back the cup shelvesTo make room for taller items in the upper basket, raise the cup rack upwards. You can then lean the tall glasses against it. You can also remove it when it is not required for use.Folding back the rack shelvesThe spikes of the lower basket are used for holding plates and a platter. They can be lowered to make more room for large items.
