MEMUP M430TR Troubleshooting guide
& Installation Guide
User
Feel Design
USER GUIDE
1. PRECAUTIONS 1
2. PRODUCT INFORMATIONS 3
3. POWER ON / OFF 5
4. PLAYER FUNCTION 6
5. TRANSCODING TOOL 11
6. TECHNICAL SPECIFICATIONS 13
- 1 -
Do not touch power supply adapter with wet hands.
Otherwise, it may cause an electric shock
Use standard power supply adapter.
Otherwise, it may cause damage to this player by using a
non-Standard power supply adapter
Make sure power supply faucet connected to correct
underground cable.
Otherwise, it may cause an electric shock
Make sure power supply adapter plugged in socket tightly.
Otherwise, it may cause fire.
Do not play too long with max volume.
Otherwise, it may cause harm to your hearing.
Do not strike the player.
Otherwise, it may damage the player
Do not wear earphones when driving.
Otherwise, it may cause accident.
If this player gives off smoke or heat, please stop using it
immediately and contact customer service centre.
Keep on using this player will be dangerous.
- 2 -
Keep this player between 0°c and 40°c.
Do not put player in dust or damp condition.
Otherwise, it may damage the player.
Do not expose player in sun shine directly.
Otherwise, it may damage the player
Do not put the player close to a credit card, etc…
Otherwise, it may damage magnetic parts of credit card,
etc …
Please clean player by cleaning and soft cloth, do not use
any detergent.
Otherwise, it may damage the player.
Do not let dust or liquid matter into the player.
Otherwise, it may damage the player.
If it happens, please contact customer service centre.
Do not take apart or fix player by yourself.
Otherwise, it may damage the player.
Do not make player fall.
Otherwise, it may damage to the player.
- 3 -
PRODUCT INFORMATIONS
Product functions
Compatible with audio format
MP3/WMA/WAV format.
Compatible with video format
AVI/ASF format.
Support function of picture browsing
JPEG/BMP/GIF/PNG format.
Support function of E-book
E-book files in TXT format (in ANSI)
Support function of FM radio
Frequency ranging from 87.5 to 108 MHZ
Support FLASH playing
With Macromedia Flash Lite 2.1.
Embedded with 4.3 inch TFT Touch screen
High definition pictures and videos with 16M colors.
Built-in rechargeable battery
Extra batteries are not necessary.
Conversion Software
Convert video file which is unable to be played into playable format with conversion software.
Package Content
1. PMP
2. Manual
3. AC adapter
4. AV in cable
5. USB line
6. Earphone
7. Carry case
- 4 -
Function display
- 5 -
Connection
External audio connection: with double jack line connection
Stereo earphone connection: plugged needed for radio reception
Connect with TV: with supplied audio/video cable, for TV input
Computer connection thanks to USB cable
Caution: Unexpected interruption may cause damage to this product!
Charge
Tips: During recharge, please don’t pull out plug, the product will be damaged.
Recharge mode
Connect AC adapter to charge. In recharging mode, indicator is red and go out when battery is full
Charge indication
POWER ON / POWER OFF
Power on
Long press “POWER” 3-5 seconds, indicator will turn green.
Power off
Long press “POWER” 3-5 seconds, indicator will go out.
- 6 -
PLAYER FUNCTION OPERATION INSTRUCTION
Main menu interface
9 icons on main menu interface.
On the bottom bar : volume, power, time (as picture)
Tips: This product is compatible with Windows 98Se, Me, Windows 2000, Windows XP,
Windows Vista, MAC OS 10 etc.
Video
Select “Video” to enter into video browser to display video files.
Press “Video” to display operation:
1. Loop Mode: “Current”, “All” or “Random”.
2. File Protect: “Lock” or “Unlock”.
3. Del File: “Current” or “All”.
4. Resume: Play last file played (previously saved as bookmark)
5. Exit: Select “Exit” to return to main interface
a. Press "ESC" button to stop playing, then choose " OK " or "Cancel" to save or cancel the
video bookmark, then get back to the video browser.
b. Click " " or " " icon to adjust the volume.
c. Click “ ” to pause, and click “ ” to resume.
d. Click “ ” or “ ” to play previous or next file.
- 7 -
e. During video play, click the center of the screen to display the tool bar. Click “ ’ or “ ” to
play backward or forward. Click “ ” to play again.
Tips: Forward or Backward function is under condition of video playing.
Audio
Select “Audio” to enter into audio browser to display audio files.
Click “audio” to display operation:
1. Loop Mode: “Current”, “All” or “Random”.
2. File Protect: “Lock” or “Unlock”.
3. Del File: “Current” or “All”.
4. EQ Mode: “Normal”, “Classic”, “Popular”, ”Bass” or “Rock”.
5. Exit: Select “Exit” to return to main interface
Press “ESC” button or click “ ” on taskbar to stop playing, then get back to the file list. Press
“ESC” button or click “ ” again to return to the main interface.
Click “+” or “-” icon to adjust volume
Click “ ” to pause, and click “ ” to resume.
Click “ ” or “ ” to play previous or next file.
- 8 -
During audio playing, click “ ” or “ ” to play Backward or Forward. Click “ ” to select the
EQ mode.
Click “ ” to switch to the cycle mode.
Lyrics synchronous display
To make lyrics and music display synchronously, make sure music and lyrics files are both copied in
same MP3 folder with same file name, lyrics file name should be: *.LRC, otherwise lyrics can not be
displayed synchronously when playing music files.
Select “Picture” in main interface to enter.
Click ”Picture” to show operation:
1. Display Mode: “List” or “Slide”.
2. File Protect: “Lock” or “Unlock”.
3. Del File: “Current” or “All”.
4. Wall Paper: Make current photo as desktop background
5. On Menu: Make current photo as start-up image
6. Off Menu: Make current photo as power-off image
7. Exit: Select “Exit” to return to the main interface.
Click the photo and Click again to play.
Click ”Esc” to stop pictures browsing and return to ”file list”
Under photo viewing click the center of the screen to display next photo; you can click the "picture"
in the list of photo file, and then select "Display Mode/ Slide" to play in slide mode
.
Wall Paper:
Click "picture "under the list of picture file, and click " Wall Paper " on
the pop-up menu, then the current picture can be set as desktop background; All the pictures stored
in the player can be set as desktop background and startup/ power-off image etc.
Radio
For FM radio, earphones must be plugged as they are radio antenna.
In main interface, select “Radio” to enter into FM interface.
Default state is preset with 20 stations for your selection (click “ ” or “ ” to select)
Click “ ” to adjust volume
During FM play, click “ ” to select “Manusch”, “Select” and “Auto Seek”:
Manual Search
Select “Manusch”, click “ ” or “ ” to switch frequency; click “ ”, it will ask to save, select “ok” to
save, and press “Esc” to exit.
