Medify Air MA-112 User manual
MA-112
AIRPURIFIER
MA-112US
READ AND FOLLOW THESE INSTRUCTIONS
USE UNIT ACCORDING TO INSTRUCTIONS PROVIDED IN THIS MANUAL
KEEP MANUAL FOR FUTURE REFERENCE
V2.0
IMPORTANT SAFETY INSTRUCTIONS:
IN ORDER TO AVOID ANY DAMAGE TO YOU, OTHERS OR PROPERTY, FOLLOW THE FOLLOWING SAFETY PRECAUTIONS:
IF THE POWER CORD OR UNIT DOES NOT WORK, CONTACT MEDIFY CUSTOMER SERVICE IMMEDIATELY.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING – TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
• DO NOT touch the power plug with wet hands.
• Turn off the power before cleaning machine.
• DO NOT use the air purifier in rooms where fumigation or pesticide is being used.
• Keep machine dry.
• Only a soft clean cloth is to be used. DO NOT use solvents like Benzene, Alcohol or any flammable
cleaners to clean the air purifier.
• This is a 110V unit. It is NOT made for 220V use. Plugging into a 220V outlet will burn out the motor
and circuits and the unit will no longer work. Only use with a 110V outlet.
• Do not use air purifier in a room
while
cooking with oil and grease that may clog the filters
•BEFORE USING THIS PRODUCT, PLEASE MAKE SURE TO REMOVE THE PLASTIC COVERING FROM ALL
FILTERS.
• Turn off the power immediately in case of any of the following:
-Malfunction of any switch
-Circuit failure
-Abnormal heating of wires or plugs
-Any other malfunction
SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY REFERENCE.
3
•
•
CLEAN AIR INLET
POLLUTED AIR INLET
POLLUTED AIR INLET
UNIQUE FEATURES & SPECIFICATIONS
3-STEP FILTER PURIFICATION SYSTEM
1. FIRST STEP: PRE FILTER
Removes larger particles including hair, fibers, dander, and others.
2. SECOND STEP: TRUE HEPA H13 FILTER
HEPA H13 is a higher grade of TRUE HEPA that can remove 99.9% of particles down to 0.1 microns
as well as PM2.5 particles such as smoke, pollen, dust mites and others.
3. THIRD STEP: ACTIVATED CARBON FILTER
Absorbs odors, harmful VOCs, and other toxic substances such as formaldehyde.
4
TECHNICAL DATA
• Voltage: 110V AC 60Hz
• Power Rating: 95W
• Noise level: < 70 dB(A)
• Unit dimensions: 28.3”H x 15.7”W x 15.4”D
• Unit weight: 33.5 lbs.
CONTROL PANEL
HANDLE
AIR OUTLET COVER
BACK COVER
FRONT PANEL
AIR INLET
LEFT COVER
PRE-FILTER PRE-FILTER
RIGHT COVER
TRUE HEPA H13 FILTER
+ ACTIVATED CARBON FILTER NET
TRUE HEPA H13 FILTER
+ ACTIVATED CARBON FILTER NET
5
BEFORE USE
DISASSEMBLY AND INSTALLATION METHODS OF SIDE COVERS
PLACEMENT OF THE AIR PURIFIER
1. Press down on the handles on the sides to remove the
side covers. After they open, lift the cover out from the
bottom fixed grooves.
2. To reinstall side covers, align at fixed grooves and
insert covers into grooves. Covers will snap back
automatically.
50cm
50cm
50cm
50cm
50cm
50cm
Do not obstruct air intake or clean air outlet.
To ensure enough ventilation, make sure there is a 20 inch
or 50 cm distance between the air inlet and wall or nearby
furniture.
50cm
50cm
50cm
6
INSTALLING THE FILTER SET
All filters must be used together. Please disassemble filters according to the following instructions. Reinstall
the filters accordingly.
1. Place the machine in a dry location and on a smooth
and flat surface.
2. Press down on the handles on the sides to remove the
side covers. After they open, lift the cover out from the
bottom fixed grooves.
3. Do not disassemble the filters. Filters sets come in one
piece for maximum efficiency.
7
4. Remove any exterior packaging of the filter sets. Place
filters back in the air purifiers after the packaging is
removed.
5. To reinstall the side covers, align at the fixed grooves
and insert the cover into the grooves. The side covers
will snap back in automatically.
8
HOW TO USE
PLUG IN
• After plugging it in, the air purifier will beep. Indicator lights will flash 1 time. Then, they will turn off.
TURNING ON THE AIR PURIFIER
• Press the ON/OFF button. The unit will start on speed 1 with indicator light on.
• Press the ON/OFF button again to turn off the unit.
MANUAL ADJUSTMENT OF FAN
• Press the SPEED button to choose air speed: 1, 2, 3 or 4.
SLEEP MODE
• Press the sleep button to enter into sleep mode, all other indicator lights will turn off. The fan speed and
noise level will change to the lowest setting.
• After 10 seconds, the sleep indicator light goes out as well.
• Press any key to exit sleep mode.
TIMER
Press the timer button and choose hour options: 1, 2, 4, 8 or no timer.
1. Ionizer button/ Filter
Replacement Reset
2. SLEEP Button
3. TIMER Button (1, 2, 4, 8 hours)
4. Child-lock
5. Fan Speed Button (1, 2, 3, 4)
6. ON/OFF Button
DESCRIPTION OF CONTROL PANEL FUNCTIONS
9
IONIZER MODE
Press the Ionizer button. The unit will sound and the indicator light of the Ionizer will be on. Press the Ionizer
button again and the unit will go out of Ionizer mode. The indicator light for the Ionizer will be off. When the
filter replacement indicator is on, user needs to replace the filter and press the Ionizer button for 3 seconds
to reset. Then, fan speed indicator light will stop flashing.
CHILD-LOCK BUTTON
In this mode, none of the function keys can be used or changed (except the child lock function). To turn on
the child lock, hold the button down for 3 to 5 seconds. To turn off the child lock function, hold the button
down for 30 to 45 seconds.
CLEANING AND MAINTENANCE
Please make sure to pull out the power plug before cleaning the unit. Do not immerse machine in water or
any other liquid. Do not use abrasive, corrosive or flammable products to clean any parts of the unit. The unit
uses composite filters, so filters cannot be washed.
CLEANING THE AIR PURIFIER
Clean the air purifier regularly to prevent dust accumulation. Use soft and dry clothes to remove dust from
the air purifier.
10
FILTER REPLACEMENT
LIGHT INDICATOR TO REPLACE THE FILTER*
The indicator light will remind users when it is time to change your filter.
1. Remove all existing filters from the unit. Remove all
packaging from new filter sets. Then, install the new
filters into the unit in the same order as existing filters.
Turn off and pull out power plug before replacing the filters. If replacement filter indicator light
flashes again after replacement, press the reset button at the side (as shown) until indicator
light resets itself.
ATTENTION
2. Install new filter sets in the unit. Reinstall side covers,
as outlined earlier. Side covers will snap back in
automatically.
3. When filter replacement is complete, plug in unit and
turn on. Press the Ionizer button for 3 seconds to reset
the unit.
*You can order genuine Medify replacement filters at: www.medifyair.com
