Maytag MVWC200XW User manual

W10280548D

W10280549C - SP

TOP-LOADING

WASHER

USE AND CARE GUIDE

Table of Contents

WASHER SAFETY ............................................................2

WHAT’S NEW UNDER THE LID?....................................3

CONTROL PANEL AND FEATURES.................................4

CYCLE GUIDE.................................................................5

USING YOUR WASHER ..................................................6

WASHER MAINTENANCE...............................................9

TROUBLESHOOTING ..................................................11

WARRANTY..................................................................15

ASSISTANCE OR SERVICE...............................Back Cover

Table des matières

SÉCURITÉ DE LA LAVEUSE ...........................................16

QUOI DE NEUF SOUS LE COUVERCLE?......................17

TABLEAU DE COMMANDE ET

CARACTÉRISTIQUES ....................................................18

GUIDE DE PROGRAMMES...........................................20

UTILISATION DE LA LAVEUSE .....................................21

ENTRETIEN DE LA LAVEUSE.........................................24

DÉPANNAGE ................................................................26

GARANTIE....................................................................32

ASSISTANCE OU SERVICE...................Couverture arrière

LAVEUSE À CHARGEMENT

PAR LE DESSUS

GUIDE D’UTILISATION ET

D’ENTRETIEN

Para una versión de estas instrucciones en español, visite www.maytag.com

WASHER SAFETY

Lid Lock

To allow for higher spin speeds, the lid will lock and

the Lid Locked light will turn on. When this light is

lit, the lid is locked and cannot be opened. When this

light is blinking, the washer is paused. When this light

is off, the lid can be opened. After a cycle is started,

the lid locks, unlocks, and locks again. If you need

to open the lid to add a garment after this point, you

must press START/PAUSE/UNLOCK and wait for the

lid to unlock. The lid will only unlock after washer

movement has stopped. Depending on when in the

cycle you try to pause, it may take several seconds to

several minutes for the lid to unlock.

Sensing

This washer will perform a series of spins to check

for load balance. When a load is started, it may take

2–3 minutes before water begins to enter the basket.

During this time, a series of clicks and a whirring

noise signal that sensing technology is determining

if there is an off-balance load.

IMPORTANT:

• Washer will not operate if the lid is open.

• Washer will not begin to ll with water until the lid is closed, locked, and the sensing process is complete.

This delay in ll could take 2–3 minutes.

• Fabric Softener option must be selected to ensure fabric softener dispenses at the correct time.

Sounds

At different stages of the wash cycle, you may hear

sounds and pauses that are different from those of your

previous washer. For example, you may hear a clicking

and hum at the beginning of the cycle as the lid lock

goes through a self-test. There will be different kinds of

humming and whirring sounds as the agitator tests for

load balance or moves the load. And, sometimes, you

may hear nothing at all as the washer allows time for

clothes to soak.

Spray Rinse

Select cycles default to a spray rinse. During these

cycles, you will hear water enter the washer as the tub

spins, allowing the rinse water to penetrate clothes.

Check the “Cycle Guide” for details.

WHAT’S NEW UNDER THE LID?

Your new washer will operate differently than your past agitator-style washer.

CONTROL PANEL AND FEATURES

WATER LEVEL

Select the setting most suitable for your load. Small will add

a low amount of water for smaller loads and Super Plus will

add the most amount of water for large or bulky loads. Items

need to move freely. Tightly packing can lead to poor cleaning

performance, and may increase wrinkling and tangling.

TEMPERATURE

Temperature Control senses and maintains uniform water

temperatures by regulating incoming hot and cold water.

Select a wash temperature based on the type of fabric and soils

being washed. For best results and following the garment label

instructions, use the warmest wash water safe for your fabric.

• Warm and hot water will be cooler than what your previous

washer provided.

• Even in a cold and cool water wash, some warm water may

be added to the washer to maintain a minimum temperature.

WASH CYCLE KNOB

Use the Wash Cycle knob to select available cycles on your

washer. Turn the knob to select a cycle for your laundry load.

See “Cycle Guide” for detailed descriptions of cycles.

FABRIC SOFTENER

This option can be added to most cycles and must be set to

“YES” if using fabric softener during a cycle. It ensures that

fabric softener is added at the correct time in the rinse for

even distribution.

START/PAUSE/UNLOCK BUTTON

Press to start the selected cycle; press again to pause the cycle

and unlock the lid.

NOTE: If the washer is spinning, it may take several minutes to

unlock the lid. Press and hold for 3 seconds to cancel a cycle.

CYCLE STATUS LIGHTS

The Cycle Status Lights show the progress of a cycle. At each

stage of the process, you may notice sounds or pauses that are

different from traditional washers.

SENSING

When the START/Pause/Unlock button is pressed, the

washer will rst perform a self-test on the lid lock

mechanism. You will hear a click, and the lid will unlock

briey before locking again. The washer will use spins to

check for load balance. These spins may take several

minutes before water is added to the washer. You may

hear the hum of the spins before lling. This is normal.

WASH

You will hear the agitator moving the load. The motor

sounds may change at different stages in the cycle. The

wash time is determined by the selected soil level.

RINSE

You will hear sounds similar to the wash cycle as the washer

rinses and moves the load. You may hear the motor turning

on briey (short hum) to move the basket while lling.

Fabric softener will be added if the Fabric Softener-Yes

option was selected.

Some cycles use spray rinsing. After draining and spinning

out wash water, the washer will continue to spin and spray

in rinse water for the entire rinse time.

Not all features and options are available on all models.

Appearance may vary.

CYCLE GUIDE

Items to wash: Cycle: Temperature*: Spin

Speed: Cycle Details:

Heavily soiled

fabrics Heavy Duty

Heavy Use this cycle for heavily soiled or sturdy items.

Hot

Warm

Cool

Cold

High

For best fabric care, choose the cycle that best ts the load being washed.

Not all cycles and options are available on all models.

SPIN

The washer spins the load at increasing speeds for proper

water removal, based on the selected cycle and spin

speed.

DONE

Once the cycle is complete, this light will come on.

Remove the load promptly for best results.

LID LOCKED

To allow for higher spin speeds, the lid will lock and the

Lid Locked light will turn on. When this light is lit, the

lid is locked and cannot be opened. When this light is

blinking, the washer is paused. When this light is off,

the lid can be opened.

If you need to open the lid, press

START/Pause/Unlock. The lid will

unlock once the washer movement

has stopped. This may take several

minutes if the load was spinning at

high speed. Press START/Pause/

Unlock again to resume the cycle.

NOTE: Be sure to select Fabric Softener-Yes, if adding fabric softener to load.

*All rinses are cold.

Machine-wash silks,

lingerie, washable

wools

Delicate Low

No-iron fabrics,

cottons, perm

press, linens,

synthetics

Cottons, linens,

sheets, and mixed

garment loads

Swimsuits and

items requiring

rinsing without

detergent

Casual

Normal

Regular

Rinse &

Spin

Use this cycle to wash lightly soiled garments indicating

“Machine Washable Silks” or “Gentle” cycle on the care

label. Place small items in mesh garment bags before

washing. This cycle features a spray rinse.

Use this cycle to wash loads of no-iron fabrics such as sport

shirts, blouses, casual business clothes, permanent

press, and blends.

Use this cycle for normally soiled cottons and mixed fabric

loads. This cycle features a spray rinse.

Combines a rinse and high speed spin for loads requiring

an additional rinse cycle or to complete a load after power

interruption. Also use for loads that require rinsing only.

Hot

Warm

Cool

Cold

Hot

Warm

Cool

Cold

Cold rinse only

Low

High

Dripping wet or

hand-washed

items

Drain &

Spin

This cycle uses a spin to shorten drying times for heavy fabrics

or special-care items washed by hand. Use this cycle to drain

washer after cancelling a cycle or completing a cycle after a

power failure.

High

Hot

Warm

Cool

Cold

N/A

Sturdy fabrics,

colorfast items,

towels, jeans

Heavy Duty

Regular Use this cycle for normally soiled or sturdy items.

Hot

Warm

Cool

Cold

High

Large items such

as sheets, small

comforters, jackets

Normal

Heavy Use this cycle for heavily soiled cottons or mixed fabric

loads. This cycle features a spray rinse.

Hot

Warm

Cool

Cold

High

• Empty pockets. Loose change, buttons, or any small object

can pass under the agitator and become trapped, causing

unexpected sounds.

• Sort items by recommended cycle, water temperature,

and colorfastness.

• Separate heavily soiled items from lightly soiled.

• Separate delicate items from sturdy fabrics.

• Do not dry garments if stains remain after washing, because

heat can set stains into fabric.

• Treat stains promptly.

• Close zippers, fasten hooks, tie strings and sashes, and remove

non-washable trim and ornaments.

• Mend rips and tears to avoid further damage to items during

washing.

Helpful Tips:

• When washing water-proof or water-resistant items, load evenly.

• Use mesh garment bags to help avoid tangling when washing

delicate or small items.

• Turn knits inside out to avoid pilling. Separate lint-takers from

lint-givers. Synthetics, knits, and corduroy fabrics will pick up

lint from towels, rugs, and chenille fabrics.

NOTE: Always read and follow fabric care label instructions to

avoid damage to your garments.

1. Sort and prepare your laundry

Add a measured amount of detergent into the bottom of the

washer basket before adding clothes. If using an Oxi or

color-safe bleach laundry boost product, add to the bottom

of the washer basket, as well.

IMPORTANT: Follow the manufacturer’s instructions to determine

the amount of detergent to use.

2. Add detergent

USING YOUR WASHER

5. Add fabric softener to dispenser

(on some models)

Pour a measured amount of liquid fabric

softener into dispenser; always follow

manufacturer’s directions for correct amount

of fabric softener based on your load size.

Dilute liquid fabric softener by lling the dispenser with warm

water until liquid reaches the underside of the rim. See max ll line

arrows. Then select Fabric Softener-Yes option.

IMPORTANT: Fabric Softener option must be selected to “Yes”

to ensure proper distribution at correct time in cycle.

Adding Liquid Fabric Softener Manually to Wash Load

During the nal rinse, wait until the washer has completed lling,

press the START/Pause/Unlock button to pause the washer. Lift the

lid and add the measured recommended amount of liquid fabric

softener. Do not allow liquid fabric softener to spill, splash, drip,

or run into the basket or on load. Do not use more than the

recommended amount. Close the lid and press the START/Pause/

Unlock button again to start the washer.

IMPORTANT: Fabric Softener option must be selected to “Yes” to

ensure proper distribution of the fabric softener during the rinse

portion of the cycle.

4. Add liquid chlorine bleach

to dispenser

Liquid

Chlorine Bleach

Do not overll, dilute, or use more than 1 cup (250 mL).

Do not use color-safe bleach or Oxi products in the same

cycle with liquid chlorine bleach.

Load garments in loose heaps evenly around basket wall. For

best results, do not pack the load tightly. Do not wrap large

items such as sheets around the agitator; load them in loose

piles around the sides of the basket. Try mixing different sized

items to reduce tangling.

3. Load laundry into washer

MAX FILL

IMPORTANT: Do not tightly pack or force items into washer.

Items need to move freely for best cleaning and to reduce

wrinkling and tangling.

Turn cycle knob to choose your wash cycle. For more

information, see “Cycle Guide”.

6. Select cycle

Wash Temp

Hot

Some cold water is added to save

energy. This will be cooler than your

hot water heater setting.

Warm

Some cold water will be added, so

this will be cooler than what your

previous washer provided.

Cool

Warm water may be added to

assist in soil removal and to help

dissolve detergents.

Cold

This is the temperature from your

faucet. If your tap cold water is

very cold, warm water may be

added to assist in soil removal

and help dissolve detergent.

Suggested Fabrics

8. Select TEMPERATURE

Once you select a cycle, select the desired wash temperature by

turning the Temperature knob to the appropriate setting based on

your load. All rinses are cold.

NOTE: Always read and follow fabric care label instructions to

avoid damage to your garments.

10. Press START/Pause/Unlock

to begin wash cycle

Press the START/Pause/Unlock button to start the wash cycle.

Filling is delayed for several minutes while load balance is

sensed. When the cycle has nished, the DONE indicator will

light. Promptly remove garments after cycle has completed

to avoid odor, reduce wrinkling, and rusting of metal hooks,

zippers, and snaps.

Unlocking the lid to add garments

If you need to open the lid to add 1 or 2 missed garments:

Press START/Pause/Unlock; the lid will unlock once the washer

movement has stopped. This may take several minutes if the load

was spinning at high speed. Then close lid and press START/

Pause/Unlock again to restart the cycle.

If lid is left open for more than 10 minutes, the water will pump

out automatically.

Delay in water ll

Filling is delayed for 2 to 3 minutes to check for load unbalance.

You will hear the hum of the spin prior to lling. This is normal

operation.

If you are using fabric softener, be sure to set Fabric

Softener-Yes option.

Whites and pastels

Durable garments

Heavy soils

Bright colors

Moderate to light soils

Colors that bleed

or fade

Light soils

Dark colors that

bleed or fade

Light soils

9. Select OPTION (on some models)

Select the Water Level setting most suitable for your load. Small

will add a low amount of water for smaller loads and Super Plus

will add the most amount of water for large or bulky loads. Items

need to move freely.

7. Select WATER LEVEL

CLEANING YOUR WASHER

Keep your washer as clean and fresh as your clothes. To keep

washer interior odor-free, follow this recommended monthly

cleaning procedure:

1. Make sure the washer is empty.

2. Using recommended AFFRESH®washer cleaner, add one

tablet to washer basket

If using liquid chlorine bleach, add 1 cup (250 mL) to liquid

chlorine bleach dispenser.

IMPORTANT: Do not add detergent. Do not use more than

recommended amount of bleach to avoid damaging product

over time.

3. Close washer lid.

4. Select Heavy Duty Regular cycle, hot temperature, and large

water level.

5. Press START/Pause/Unlock.

NOTE: For best results, do not interrupt cycle. If cycle must

be interrupted, press START/Pause/Unlock twice and run a RINSE

& SPIN cycle to ensure bleach has been rinsed from washer.

Press and hold the START/Pause/Unlock for 3 seconds to cancel

the cycle.

Cleaning the liquid fabric softener dispenser

1. Remove dispenser by grasping top with both hands and

squeezing, while pushing upward with thumbs.

2. Rinse dispenser under warm water, then replace it.

NOTE: To avoid damage to the washer or clothing, do not wash

clothes with the liquid fabric softener dispenser removed.

Cleaning the bleach dispenser

Wipe the inside of the bleach dispenser with a clean,

damp cloth.

To clean exterior:

1. Use a soft, damp cloth or sponge to wipe up any spills.

2. Use all-purpose surface cleaner, if needed.

IMPORTANT: To avoid damaging the washer’s nish, do not use

abrasive products.

Operate your washer only when you are home. If moving, or not

using your washer for a period of time, follow these steps:

1. Unplug or disconnect power to washer.

2. Turn off water supply to washer, to avoid ooding due to

water pressure surge.

WINTER STORAGE CARE

IMPORTANT: To avoid damage, install and store washer

where it will not freeze. Because some water may stay in

hoses, freezing can damage washer. If storing or moving

during freezing weather, winterize your washer.

To winterize washer:

1. Shut off both water faucets; disconnect and drain water inlet

hoses.

2. Put 1 qt. (1 L) of R.V.-type antifreeze in basket and run

washer on RINSE & SPIN cycle for about 30 seconds to

mix antifreeze and remaining water.

3. Unplug washer or disconnect power.

NON-USE AND VACATION CARE

Replace inlet hoses after 5 years of use to reduce the risk of hose

failure. Periodically inspect and replace inlet hoses if bulges,

kinks, cuts, wear, or leaks are found.

When replacing your inlet hoses, mark the date of replacement

on the label with a permanent marker.

WATER INLET HOSES

WASHER MAINTENANCE

TRANSPORTING YOUR WASHER

1. Shut off both water faucets. Disconnect and drain water inlet

hoses.

2. If washer will be moved during freezing weather, follow

Winter Storage Care directions before moving.

3. Disconnect drain from drain system and drain any remaining

water into a pan or bucket. Disconnect drain hose from back

of washer.

4. Unplug power cord.

5. Place inlet hoses and drain hose inside washer basket.

6. Drape power cord over edge and into washer basket.

7. Place packing tray from original shipping materials back

inside washer. If you do not have packing tray, place heavy

blankets or towels into basket opening. Close lid and place

tape over lid and down front of washer. Keep lid taped until

washer is placed in new location.

REINSTALLING/USING WASHER AGAIN

To reinstall washer after non-use, vacation, winter storage,

or moving:

1. Refer to “Installation Instructions” to locate, level, and

connect washer.

2. Before using again, run washer through the following

recommended procedure:

To use washer again:

1. Flush water pipes and hoses. Reconnect water inlet hoses.

Turn on both water faucets.

2. Plug in washer or reconnect power.

3. Run washer through Casual cycle to clean washer and

remove antifreeze, if used. Use half the manufacturer’s

recommended amount of detergent for a medium-size load.

Other manuals for MVWC200XW

This manual suits for next models

Table of contents

Languages:

Other Maytag Washer manuals

Maytag

Maytag FRONT-LOADINGAUTOMATICWASHER User manual

Maytag

Maytag Neptune MAH3000 User manual

Maytag

Maytag MVWB850WQ - Bravos 5.0 cu. Ft. IEC Capacity... User manual

Maytag

Maytag MVW18PDAXW User manual

Maytag

Maytag MHW5630HW0 Operating and installation instructions

Maytag

Maytag SAV2555 User manual

Maytag

Maytag MAT14PD User manual

Maytag

Maytag MHWE950W Series Parts list manual

Maytag

Maytag LAT8804 User manual

Maytag

Maytag MAV2755AWW User manual

Maytag

Maytag MAT20CSTGW User manual

Maytag

Maytag W-3 User manual

Maytag

Maytag Top Loading Washing Machine User manual

Maytag

Maytag MAH22PDAXW1 User manual

Maytag

Maytag MDE22PRBY User manual

Maytag

Maytag BRAVOS XL MVWB750YW User manual

Maytag

Maytag 2000 Series User manual

Maytag

Maytag MHN30PNA User manual

Maytag

Maytag mav9750 aww Operating instructions

Maytag

Maytag Washer User manual

Maytag

Maytag MHW4200BW0 User manual

Maytag

Maytag MTW5707TQ0 User manual

Maytag

Maytag MVWX5SPAW User manual

Maytag

Maytag MVWC350AW0 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
