Maytag MFR60PN User manual

MFR60PN

CLP766

MICROPROCESSOR CONTROLS

Maytag®controls provide simple

one-touch cycle selection.

Multilingual readouts make them

easy for everyone to operate.

FOR YOUR OPERATION:

• Inverter Drive Technology For

Longer Life

• Big-Load Design With Oversized

Door Opening

• Easy-To-Operate Microprocessor

Controls

• Adjustable Water Temperatures

And Levels

• TurboWash™System Cuts Water Usage

By Up To 44%*

• Standard Manual Dispenser System

• Liquid Chemical Supply Hookup

• 8 Chemical Supply Signals

• Extra-Large Drain Valve

• Extra-Large Door And Handle

• Easy Service Access

• Programmable LCD Digital Display

Shows English, Spanish, French Or

13 Additional Languages

BUILT-TO-LAST™FEATURES:

• Commercial-Duty Door Handles,

Belts And Frame

• Extra-Large Drain Valve

• Durable Sealed Bearings

• Stainless Steel Top, Front And Sides

* Compared to previous Maytag®MFR washers.

Total savings may vary by model.

MORE ENERGY-SAVING SOLUTIONS

THAN ANY OTHER BRAND

Maytag built the first appliance ever to

receive the ENERGY STAR®label. Today

we offer more high-efficiency laundry

appliances than any other brand — from

energy-efficient dryers to highly efficient

ENERGY STAR®-qualified washers — to

help you save money and build profits.

CLEANS BETTER WITH

LESS WATER

TO CUT UTILITY COSTS.

MAYTAG®COMMERCIAL

ENERGY ADVANTAGE™

RIGID-MOUNT FRONT-LOAD

WASHER

www.maytagcommerciallaundry.com

10/05

Maytag®Energy Advantage™Rigid-Mount Washer Extractor

MICROPROCESSOR NON-COIN

Energy Advantage™

Rigid-Mount Washer Extractor

WASHER SPECIFICATIONS

MODEL MFR60PN

MOTOR

Inverter drive

•

Variable speed

•

HP (kw)

3 (2.2)

Voltage 208 – 240V

Single-Phase/Three-Phase

BREAKER SIZE — amps

SPEED

Wash speed — maximum rpm

Extract speed — maximum rpm

490

Extract speed — maximum g-force

100

WATER INLET/HOSE

Water inlet — in. (cm)

.75 (1.9)

Operating pressure — psi (bar)

14.5 – 116 (1 – 8)

Drain size — in. (cm)

3.0 (7.5) O.D.

CAPACITY

Lbs. (kg)

60 (27)

Cylinder volume — cu. ft. (liters)

9.5 (270)

Cylinder diameter — in. (cm)

29.5 (75)

Cylinder depth — in. (cm)

24.0 (61)

COLOR

Stainless Steel

•

APPROXIMATE WEIGHT

Crated — lbs. (kg)

1,047 (475)

Uncrated — lbs. (kg)

915 (415)

DIMENSIONS

A) Height — in. (cm)

54.33 (138.0)

B) Width — in. (cm)

34.25 (87.0)

C) Depth — in. (cm)

40.95 (104.0)

D) Floor to bottom of door — in. (cm)

15.3 (38.9)

E) Depth including handle and vent

on back — in. (cm)

44.84 (113.9)

F) Floor to drain outlet center — in. (cm)

3.47 (88)

G) Side to drain outlet center — in. (cm)

17.13 (43.5)

Door Opening — in. (cm)

19.84 (50.4)

See specific instructions for proper installation. Because of continuous product improvement, Maytag reserves the right

to change specifications without notice.

MAYTAG®LIMITED

WARRANTY

2 YEARS — ALL PARTS

5 YEARS — SHELL,

WELDED FRAME ASSEMBLY,

BASKET, SHAFT ASSEMBLY,

BEARINGS AND SEALS.

For a period from the date of original purchase

through the time listed above, the designated

parts that fail in normal commercial use will be

repaired or replaced free of charge for the part

itself, with the owner paying all other costs,

including labor, transportation and customs duty.

Chemical damage is excluded from all warranty

coverage. See complete warranty for details.

WITH

HANDLE

AND VENT

IN BACK

AIR VENT ELECTRICAL

POWER

CONNECTION

WATER

CONNECTIONS

DRAIN

OUTLET

FRONT VIEW

BACK VIEW
