Martin Tripix 300 User manual

User Manual

Tripix™ Range

Tripix™300

Tripix™1200

Tripix™Wash

Tripix Power™

Tripix Power™IP66

Dimensions

Unit: mm

Tripix™ 300 / Tripix™ 1200

Tripix™Wash

Tripix Power™

Tripix Power™ IP66

A/S and all affiliated companies disclaim liability for any injury, damage, direct or indirect loss,

consequential or economic loss or any other loss occasioned by the use of, inability to use or reliance on

the information contained in this manual. The Martin logo, the Martin name and all other trademarks in this

document pertaining to services or products by Martin Professional A/S or its affiliates and subsidiaries are

trademarks owned or licensed by Martin Professional A/S or its affiliates or subsidiaries.

P/N 35000232, Rev. H

Safety Information

Warning! Read the safety precautions in this section before

installing, powering, operating or servicing this product.

The following symbols are used to identify important safety

information on the product and in this manual:

DANGER!

Safety

hazard. Risk

of severe

injury or

death.

Warning!

Hazardous

voltage. Risk

of lethal or

severe

electric

shock.

Warning!

LED light

emission.

Risk of eye

injury.

Warning!

Burn hazard.

Hot surface.

Do not touch

Warning!

Refer to user

manual.

Warning! Do not view the light output with optical instruments

or any device that may concentrate the beam.

This product is for professional use only. It is not for household use.

This product presents risks of severe injury or death due to fire

hazards, electric shock and falls.

Read this manual before installing, powering or servicing the

product. Follow the safety precautions listed below and observe all

warnings in this manual and printed on the fixture. Install and

operate the fixture only as described in this manual and in

accordance with local laws and regulations. Refer any operation not

described in this manual to a qualified technician.

If you have questions about how to operate the fixture safely, please

contact your Martin dealer or call the Martin 24-hour service hotline

at +45 70 200 201, or in the USA on 1-888-tech-180.

PROTECTION FROM ELECTRIC SHOCK

•The Tripix Power IP66 does not have a power on/off switch.

Make sure that a means of isolating this device from power

(an on/off switch or a power plug that can be removed from a

power outlet) is easily accessible.

•Shut down power to the entire installation at the main power

distribution board and lock out power (by removing the fuse at

the distribution board for example) before carrying out any

installation or maintenance work.

•Isolate devices from AC power before removing or installing

any cover or part and when not in use.

•Connect the Tripix Power and Tripix Power IP66 electrically to

ground (earth).

•Use only a source of AC power that complies with local

building and electrical codes and has both overload and

ground-fault (earth-fault) protection.

•Before using the devices, check that all power distribution

equipment and cables are in perfect condition and are rated

for the current requirements of all connected devices.

•Isolate all devices from power immediately if any cable, seal,

cover or other component is damaged, cracked or deformed.

Do not reapply power until repairs have been completed.

•The Tripix Power is for indoor use only. The Tripix Power IP66

can be installed outdoors.

•Refer any service operation not described in this manual to an

authorized Martin Service partner.

PROTECTION FROM FIRE AND BURNS

•Do not operate fixtures or the Tripix Power IP66 if the ambient

temperature (Ta) exceeds 45° C (113° F). Do not operate the

Tripix Power if the Ta exceeds 40° C (104° F).

•The exterior surfaces of the Tripix fixtures, Tripix Power and

Tripix Power IP66 can become hot, up to 65° C (149° F),

during normal operation. Ensure that accidental physical

contact with the devices is impossible.

•Allow all Tripix devices to cool for 5 minutes before servicing.

•Install Tripix devices at least 20 cm (8 in.) away from

combustible materials (for example textiles, wood, paper).

•Keep flammable materials well away from Tripix devices.

•Do not modify any Tripix device in any way not described in

this manual. Only install genuine Martin parts.

•Use only Martin approved accessories to mask or modify the

light beam.

•Do not attempt to bypass fuses. Replace defective fuses with

ones of the specified type and rating only.

•Install the Tripix Power indoors in a well-ventilated area only.

The Tripix Power IP66 can be installed outdoors. Provide a

minimum clearance of 5 cm (2 in.) and ensure unrestricted

airflow around all Tripix devices.

PROTECTION FROM INJURY

•Do not look at LEDs with a magnifying glass or any other

optical instrument that may concentrate the light output.

•Ensure that all external covers, components and installation

fittings are securely fastened.

•Block access below the work area and work from a stable

platform whenever installing, servicing or moving the devices.

•Ensure that all supporting structures, surfaces, fasteners and

lifting equipment can bear the weight of all the devices they

are intended to support plus an adequate safety margin, and

that they conform to local building and safety regulations.

•Use a sufficient number of fasteners with sufficient corrosion

resistance, dimensions and strength to mount the DIN rail

safely. Any nuts used must be self-locking.

•If there is a danger of injury or damage if a Tripix device falls,

secure it with an approved secondary attachment such as a

safety cable looped around the device or passed through a

mounting hole and anchored securely in the mounting surface.

Disposing of this product

Martin™ products are supplied in compliance with Directive

2002/96/EC of the European Parliament and of the Council of

the European Union on WEEE (Waste Electrical and

Electronic Equipment), as amended by Directive

2003/108/EC, where applicable.

Help preserve the environment! Ensure that this product is

recycled at the end of its life. Your supplier can give details of

local arrangements for the disposal of Martin products.

Contents

Dimensions....................................................................................................... 2

Safety Information............................................................................................. 3

Contents ........................................................................................................... 6

Introduction....................................................................................................... 7

Unpacking ................................................................................................. 8

Using for the first time................................................................................ 8

Physical installation .......................................................................................... 9

Location and orientation ............................................................................ 9

Mounting.................................................................................................. 10

AC power........................................................................................................ 16

Installation setup............................................................................................. 19

Tripix system overview ............................................................................ 19

Connecting the Tripix System.................................................................. 23

Fixture configuration ....................................................................................... 30

Configuring with MUM ............................................................................. 30

Operation........................................................................................................ 39

Service and maintenance ............................................................................... 41

Cleaning .................................................................................................. 41

Fixture information and monitoring .......................................................... 42

Testing..................................................................................................... 43

Fuse replacement.................................................................................... 47

Software installation ................................................................................ 48

Troubleshooting .............................................................................................. 50

Specifications ................................................................................................. 51

TripixTM Series User Manual 7

Introduction

Thank you for selecting Tripix™, a compact LED-based color-changing

lighting product from Martin™. The Tripix is available in Short 300 mm

(11.8 inch), Long 1200 mm (47.2 inch) and Wash models. All fixtures

are powered by the Tripix Power™ or Tripix Power™ IP66.

The Tripix range features:

•RGB (Red, Green, and Blue) color mixing, with RGB, HSI (hue,

saturation, intensity) and HSIC (hue, saturation, intensity, color

temperature control) options

•Calibrated and raw (uncalibrated) RGB, calibrated HSI and HSIC

•82 W LED power from Tripix 1200

•24 W LED power from Tripix 300

•72 W LED power from Tripix Wash

•Narrow, medium and wide diffuser filters (narrow fitted as

standard)

•Possibility of controlling all fixtures attached to one Tripix Power

device as one single pixel

•Possibility of controlling Tripix 1200 and Tripix Wash fixtures as

one, two or four separate pixels

•DMX512 control

•RDM (Remote Device Management) implemented in Tripix Wash

•64 pre-programmed stand-alone shows available. Master/slave

functionality allows synchronized stand-alone operation

•Possibility of combining a mixture of Tripix 300, 1200 and Wash

fixtures on same power and data links

•Clamp mounting system for mounting Tripix 300 and 1200 fixtures

on standard 35 mm top-hat DIN rail

•Mounting bracket for Tripix Wash

For the latest firmware updates, documentation, product specifications

and other information about this and all Martin Professional™ products,

please visit the Martin website at http://www.martin.com.

8 TripixTM Series user manual

Unpacking

The following items are included with the Tripix fixture:

•Tripix fixture (Tripix 1200 or Tripix 300 or Tripix Wash) with narrow

beam angle diffuser installed

•Warning note

The following items are included with the Tripix Power:

•Tripix Power external power supply unit

•Power inserter Y-cable

•DMX termination plug

•Two power cables

•This user manual

The following items are included with the Tripix Power IP66:

•Tripix Power IP66 external power supply unit

•Power inserter Y-cable

•DMX termination plug

•This user manual

Using for the first time

Before applying power to a Tripix installation:

•Carefully review “Safety Information” on page 3.

•Check that the local AC power voltage is within the range listed on

the Tripix Power or Tripix Power IP66 serial number label.

•Install the Tripix system as described in this manual.

TripixTM Series User Manual 9

Physical installation

Warning! Read “Safety Information” on page 3 before installing

devices.

The safety and suitability of lifting equipment, installation location,

anchoring method, mounting hardware and electrical installation

is the responsibility of the installer. All local safety regulations

and legal requirements must be observed when installing and

connecting the devices. Installation must be carried out by

qualified professionals only.

Tripix 300 and 1200 fixtures must be clamped onto a 35 mm DIN

top-hat rail that is securely anchored to a suitable flat surface.

Tripix Wash fixtures have an integral mounting bracket that must

be bolted or screwed to a flat surface. Ensure that the supporting

structure can bear the weight of all installed devices plus an

adequate safety margin.

Make sure that there will be at least 5 cm (2 in.) of free space and

unrestricted airflow around all Tripix devices.

Important! We recommend that you set DMX addresses and

configure fixtures before physical installation. See “Fixture

Configuration” later in this manual.

Contact your Martin supplier for assistance if you have any questions

about how to install this product safely.

Location and orientation

Tripix fixtures have an IP rating of 66 and are suitable for outdoor

installation. The Tripix Power has an IP rating of 20 and is for indoor

installation only, while the Tripix Power IP66 is suitable for outdoor

installation.

Allow 5 cm (2 in.) space and free airflow around the Tripix Power, Tripix

Power IP66 and Tripix fixtures. Do not bury or cover any Tripix device.

Install the Tripix Power, Tripix Power IP66 and all Tripix fixtures at least

20 cm (8 in.) away from any combustible materials (wood, paper, etc.)

and well away from any flammable materials.

The housings of the Tripix fixtures can reach 65° C (149° F), the Tripix

Power housing can reach 55° C (131° F) and the Tripix Power IP66

housing can reach 80° C (176° F). Restrict public access or locate the

devices so that they cannot accidentally be touched.

10 TripixTM Series user manual

All Tripix devices can be installed in any orientation.

Mounting

Mounting the Tripix 300 and 1200

Warning! Tripix 300/1200 fixtures must be mounted on 35 mm (1.4

inch) top-hat profile DIN rail that is securely anchored to a surface.

The installation must conform to local electrical, building, safety

and fire regulations. If there is a danger that a device may cause

injury or damage if it falls, use a means of secondary attachment

such as a safety cable looped around the device and securely

anchored to the mounting surface.

Tripix 300 and 1200 fixtures are designed for mounting on standard 35

mm top-hat DIN rail. You can use standard lengths of 35 mm DIN Rail

or use Martin Short 35 mm DIN rail supplied in 72 mm (2.8 in.) lengths

(P/N 23819560).

Figure 1: Martin Short 35 mm DIN rail

The special Martin DIN Rail can be ordered from Martin (see

“Accessories” in the Specifications section at the back of this manual).

Dimensions for the Martin Short DIN rail are given in Figure 1.

Note that you cannot fasten the Tripix fixture mounting clamps directly

over screws used to fasten DIN rail to the mounting surface. If a DIN

rail mounting screw is in the way of a mounting clamp, move the screw

to another slot in the DIN rail.

This manual suits for next models

Table of contents

Other Martin Lighting Equipment manuals

Martin

Martin EFX500 User manual

Martin

Martin PAL 1200 FX User manual

Martin

Martin MAC 2000 Profile II User manual

Martin

Martin Mania SCX500 User manual

Martin

Martin MAC Viper AirFX Setup guide

Martin

Martin Alien 05 User manual

Martin

Martin MAC 550 Profile User manual

Martin

Martin Exterior Projection 500 User manual

Martin

Martin MAC Viper Profile User manual

Martin

Martin MAC TW1 User manual

Martin

Martin MAC Aura User manual

Martin

Martin MAC 2000 Wash XB User manual

Martin

Martin MAC Viper Profile User manual

Martin

Martin MAC 500E User manual

Martin

Martin Atomic Colors User manual

Martin

Martin MAC 350 Entour User manual

Martin

Martin Acrobat User manual

Martin

Martin RoboScan 812 User manual

Martin

Martin MAC Viper Profile Setup guide

Martin

Martin MAC Viper Profile User manual

Martin

Martin MAC 250 Wash User manual

Martin

Martin MAC 301 Wash User manual

Martin

Martin ELP CL User manual

Martin

Martin RoboColor III User manual

Popular Lighting Equipment manuals by other brands

Brizo

Brizo 8SP-MU-4 manual

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 installation instructions

IKEA

IKEA BJÖRKSPIREA manual

Laserworld

Laserworld Evolution Series ES-400RGB manual

Alien

Alien RG STAR user manual

EuroLite

EuroLite LED B-40 user manual

Qazqa

Qazqa Suplux SL 3 Black 103062 instruction manual

Commercial Electric

Commercial Electric 54568141 Use and care guide

CREE LIGHTING

CREE LIGHTING 304 Series installation instructions

Goobay

Goobay 49867 user manual

ECOMAN ITALIA

ECOMAN ITALIA LED T8 instruction manual

Alkalite

Alkalite Krypton KT-81 user manual

Clas Ohlson

Clas Ohlson GU10 manual

DTS

DTS DELTA 10 F user manual

ring

ring Solar Steplight manual

One Stop Gardens

One Stop Gardens 57696 Owner's manual & safety instructions

Chauvet DJ

Chauvet DJ COREpar UV120 ILS user manual

SIREM

SIREM Swimeo A2 instructions
