Makita 4390D Quick start guide
Parts Breakdown 4390D
Page 1 of 2 2/8/2008
Parts Breakdown 4390D
Fig # Part ID Part Name Quantity
1 629581-1 MOTOR, 6093DW, T2 1
2 152272-4 SUPPORTER, 4300DW 1
3 153202-8 GEAR,4390D,TYPE 2 1
4 253307-5 T. WASHER, 4390D 3
5 253874-0 F. WASHER 4, 4390DW 1
6 212014-9 N.R. BEARING 407, 4300DW 1
7 154401-5 SLIDER, 4390DW, T2 1
8 214020-0 P. BEARING 3, 4300DW 1
11 214020-0 P. BEARING 3, 4300DW 1
12 214020-0 P. BEARING 3, 4300DW 1
13 922107-1 H.S.H. BOLT M4X8, AF502 1
14 163157-9 SET PLATE, DA391D 1
14 342833-0 SET PLATE, 4071D 1
15 182406-5 HOUSING SET, 4390DW, T3 1
15 188196-8 N/A 1
16 855903-1 NAME PLATE, 4390D 1
17 231390-2 COMP. SPRING 3, UH3000D 1
18 414169-8 LOCK-OFF LEVER, 4390D 1
19 643909-9 BATTERY HOLDER, 6222DWE 1
20 410972-5 TRIGGER, 4390DW 1
21 651866-7 SWITCH 1
22 322099-8 ROLLER, 4390DW 1
23 256654-3 PIN 4, 4390DW 1
24 343875-7 SHOE, 4390DW, T2 1
25 188196-8 N/A 1
25 182406-5 HOUSING SET, 4390DW, T3 1
26 961017-7 STOP RING E-3, 4304 1
27 911143-2 P.H. SCREW M4X22, 6211D 8
35 191681-2 BATTERY 9000, 6012HDW 1
400 783201-290A N/A 1
401 792540-990A N/A 1
402 792541-790A N/A 1
403 414938-7 BATTERY COVER, 6222DWE 1
404 824285-2 N/A 1
Page 2 of 2 2/8/2008
