Makita BO5031 User manual

Parts Breakdown BO5031

Page 1 of 2 2/13

Parts Breakdown BO5031

Fig # Part ID Part Name Quantity

Products with multiple versions are listed in subsiding order with the newest version on top not indented

1 265995-6 TAPPING SCREW 4X18, BO4556K 3

2 450810-9 TOP COVER, B05031K 1

3 265995-6 TAPPING SCREW 4X18, BO4556K 2

5 687063-9 STRAIN RELIEF, 4323K 1

6 682502-4 CORD GUARD 8-85, HP2010N 1

7 664064-4 CORD (2X18X8 SJ), BO4556 1

660002-4 POWER SUPPLY CORD, JN1601

8 CB407 CARBON BRUSH SET, 195007-0 1

195007-0 CARBON BRUSH SET, 195007-0

191927-6 CARBON BRUSH SET CB-407, BO5030K

9 643995-0 BRUSH HOLDER, BO4556K 2

10 654532-5 TERMINAL BLOCK, BO4556 1

11 651527-9 SWITCH, BO4556K 1

12 424039-3 SWITCH COVER, BO4556K 1

13 450809-4 MOTOR HOUSING, B05031K 1

14 866159-1 NAME PLATE, B05031K 1

15 633671-4 FIELD 115V, B05030K 1

16 266147-2 TAPPING SCREW 4X55, 6824 2

17 210017-7 BALL BEARING 607DDW, LXPK01 1

18 681652-2 INSULATION WASHER, BO4556 1

19 515731-3 ARMATURE ASS'Y 115V, B05030K 1

20 267806-1 WASHER 9, BO4556K 1

21 211092-6 B. BEARING 629DDW, BO4556 1

22 450672-5 BRACKET, B05030K 1

23 265995-6 TAPPING SCREW 4X18, BO4556K 4

24 241673-2 FAN 88, B05030K 1

25 267164-5 FLAT WASHER 15, BO5030 1

26 188579-2 SKIRT L/R SET, B05030K 1

27 265995-6 TAPPING SCREW 4X18, BO4556K 2

28 188579-2 SKIRT L/R SET, B05030K 1

29 318304-9 BEARING BOX, B5030K 1

30 211228-7 BALL BEARING 6202DDW, HM1303B 1

31 424131-5 BRAKE RING, B05030K 1

32 318303-1 BEARING BOX COVER, B05030K 1

33 253739-6 FLAT WASHER 4, BO5010 1

34 911128-8 P.H. SCREW M4X16, LXPK01 1

35 743081-8 BASE/PAD , BO5030 1

36 911128-8 P.H. SCREW M4X16, LXPK01 3

37 631831-2 CONTROLLER, B05031K 1

166078-4 DUST BAG, BO4556K 1

257202-1 RING 25, BO4556 1

416063-0 DUST BAG NOZZLE, BO4556 1

416064-8 DUST NOZZLE, BO4556 1

794520-1 5" ABR. D.#120 (5/PKG), BO5001 1

794544-7 ABRASIVE DISC 125#120, BO5001

183782-0 PLASTIC TOOL CASE, BO5030K

824562-2 PLASTIC TOOL CASE, BO5021K 1

Page 2 of 2 2/13
