EN

Cordless Chain Saw

INSTRUCTION MANUAL

7

FR

Tronçonneuse sans Fil

MANUEL D’INSTRUCTIONS

19

DE

Akku-Kettensäge

BETRIEBSANLEITUNG

33

IT

Motosega a batteria

ISTRUZIONI PER L’USO

47

NL

Accukettingzaag

GEBRUIKSAANWIJZING

61

ES

Electrosierra Inalámbrica

MANUAL DE

INSTRUCCIONES

75

PT

Motosserra a Bateria

MANUAL DE INSTRUÇÕES

89

DA

Akku-kædesav

BRUGSANVISNING

103

EL

Φορητό αλυσοπρίονο

ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ

115

TR

Akülü Ağaç Kesme

KULLANMA KILAVUZU

130

2

Fig.1

3

Fig.2

Fig.3

13

17

16

4

Fig.8

2

Fig.5

2

3

Fig.6

Fig.10

1

5

6

7

Fig.19

Fig.23

Fig.20

Fig.24

Fig.25

Fig.21

2

2

1

1

3

1

8

Fig.22

Fig.26

Fig.27

Fig.31

1/5

Fig.28

1

2

30

30

55

55

1

2

30

1

9

Fig.29

Fig.34

Fig.30

10 ENGLISH

ENGLISH (Original instructions)

SPECIFICATIONS

Model:

DUC256

DUC306

DUC356

DUC406

DUC256C

Overall length (without guide bar)

270 mm

Rated voltage

D.C. 36 V

Net weight

*1

4.2 kg

*2

4.6 - 4.8

kg

4.7 - 4.9

kg

4.8 - 5.0

kg

4.8 - 5.1

kg

4.6 - 4.7

kg

Standard guide bar length

250 mm

300 mm

350 mm

400 mm

250 mm

Recommended guide bar

length

with 90PX

250 - 400 mm

-

with 91PX

250 - 400 mm

-

with 25AP

-

250 mm

Applicable saw chain type (refer

to the table below)

90PX

91PX

25AP

Standard sprocket

Number of teeth

6

9

Pitch

3/8″

1/4″

Chain speed

0 - 20 m/s

(0 - 1,200 m/min)

Chain oil tank volume

200 cm3

•Due to our continuing program of research and development,

the specifications herein are subject to change without

notice.

•Specifications may differ from country to country.

*1: Weight, with largest battery cartridge and empty oil tank, and without guide bar and chain, according to EN ISO

11681-2. *2: The lightest and heaviest combination of weight, according to EPTA-Procedure 01/2014. The weight

may differ depending on the attachment(s), including the battery cartridge.

Applicable battery cartridge

BL1830 / BL1830B / BL1840 / BL1840B / BL1850 / BL1850B / BL1860B

•Someof the battery cartridges listed above may not be

available depending on your region of residence.

WARNING: Only use the battery cartridges listed above. Use of any other battery cartridges may cause

injury and/or fire.

Saw chain, guide bar, and sprocket combination
