Echo CS-8001(6digits)(36) Instruction Manual

PARTS CATALOG

CHAIN SAW

CS-8001(6digits)(36)

1. Cylind r, Crankcas , Piston

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

1 900162-06025 4

BOLT, H.S. 6*25

6*25 W,SW

2 101001-30832 1

CYLINDER ASSY

Sus. by 101001-

30833

2 101001-30833 1

CYLINDER W/GASKET

Sr/Nr 36001000

and before

2 P021-005410 1

CYLINDER ASY

Sr/Nr 36001001

and after

3 + 101010-30830 1

GASKET, CYL. BASE

4 100000-30831 1

PISTON KIT

Sus. by 100000-

30832

4 100000-30832 1

PISTON KIT

Sr/Nr 36001000

and before

4 P021-005420 1

PISTON KIT

Sr/Nr 36001001

and after

5 + 100011-30831 2

RING, PISTON

6 + 100013-30830 1

PIN, PISTON

8*13*34.8 Sr/Nr 36001000

and before

6 + V611-000000 1

PIN,ENG 13

8*13*38.8 Sr/Nr 36001001

and after

7 + 100015-30830 2

CIRCLIP, PISTON PIN

8 + 100012-30830 1

BEARING, NEEDLE

9 100100-30830 1

CRANKSHAFT ASSY

10 100142-30830 1

KEY, WOODRUFF

12 130516-30830 1

BAND

13 130510-30830 1

ADAPTER, INTAKE

14 433016-11031 1

SCREW, TENSIONER

- 1 -

CS-8001(6digits)(36)

1. Cylind r, Crankcas , Piston

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

15 433028-11030 1

CLIP

16 433014-02830 1

TENSIONER

17 433000-19831 1

CATCHER KIT, CHAIN

18 + 900162-05020 1

BOLT, H.S. 5*20

5*20 W,SW

19 900600-00005 1

WASHER 5

21 100204-30832 1

CRANKCASE KIT

22 + 100213-30830 1

OILSEAL

25Z-16 39.9 7

23 + 436114-13930 1

VALVE, CHECK

24 + 900345-50010 1

PIN, SPRING 5*10SUS

5*10SUS

25 + 100215-02830 2

PIN, DOWEL

26 + 900810-36203 2

BEARING, BALL 6203

6203/C3

27 + 433011-19830 2

STUD, GUIDE BAR

28 + 100242-30830 1

GASKET, CRANKCASE

30 + 100212-19830 1

OILSEAL

ISM 15*25*6

29 900162-05035 4

BOLT, H.S. 5*35

5*35 W,SW

31 100921-30830 1

CUSHION

32 900162-05014 2

BOLT, H.S. 5*14

5*14 W,SW Sr/Nr 36001185

and before

32 900162-05014 1

BOLT, H.S. 5*14

5*14 W,SW Sr/Nr 36001186

and after

33 900162-05020 5

BOLT, H.S. 5*20

5*20 W,SW

34 436001-31730 1

CAP ASSY, OIL TANK

35 + 900721-00025 1

O-RING 25

G-25

36 + 131050-19830 1

RETAINER, LINK

37 + 900246-03008 1

SCREW 3*8

3*8

- 2 -

CS-8001(6digits)(36)

1. Cylind r, Crankcas , Piston

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

38 + 131051-19830 1

LINK

60L

39 900238-05014 1

SCREW 5*14

5*14 Sr/Nr 36001186

and after

40 880210-30830 1

BUMPER, SPIKED

41 900105-06020 2

BOLT, H.S. 6*20

6*20

42 900605-00006 2

WASHER, SPRING 6

43 101501-31730 1

COVER, CYLINDER

45 + 101578-30830 1

PLUG

44 101520-33330 1

COVER

46 101541-30831 1

PLATE, GUIDE

47 890345-39230 1

LABEL,CAUTION

48 890631-38130 1

LABEL, CAUTION

- 3 -

CS-8001(6digits)(36)

2. Air Cl an r, Muffl r

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

1 130302-30830 1

COVER SET, AIR CLN

2 + 130406-30830 1

NUT, THUMB

3 + 900720-00010 1

O-RING P-10

P-10

4 + 900720-00003 1

O-RING P-3

P-3

5 890112-60830 1

LABEL, MODEL

Sus. by 890112-

60831

5 890112-60831 1

LABEL, MODEL

11 130303-30831 1

FILTER, AIR W/SEAL

12 + 130356-19830 1

GROMMET

13 + 130320-30831 1

SEAL, CLEANER

14 130306-30830 1

CASE, CARBURETOR(BS)

15 101529-30830 1

PLATE, GUIDE (A)

16 129013-30831 1

SCREW, IDLE SPEED

17 129010-19830 1

GROMMET

Sr/Nr 36001000

and before

17 129010-38830 1

GROMMET, NEEDLE

Sr/Nr 36001001

and after

18 100905-19830 1

CUSHION

19 130339-30830 1

PLUG

21 130007-30830 1

INSULATOR

20 + 130012-30830 1

SEAL, DUST

22 + 130020-19830 2

NUT

23 900162-05025 4

BOLT, H.S. 5*25

5*25 W,SW

24 130110-30830 1

PIPE, IMPULSE

25 129011-19831 1

PLATE

26 900162-05055 2

BOLT, H.S. 5*55

5*55 W,SW

- 4 -

CS-8001(6digits)(36)

2. Air Cl an r, Muffl r

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

27 900162-05014 2

BOLT, H.S. 5*14

5*14 W,SW

28 130405-30830 1

SUPPORTER, FILTER

29 123000-30832 1

CARBURETOR ASSY

HDA-63

30 178078-19830 1

SPRING

31 178114-19830 1

HOLDER, THR. LEVER

32 178510-30830 1

ROD, CHOKE

33 178810-11231 1

GROMMET

34 178307-30830 1

ROD, THROTTLE

35 163400-30830 1

SWITCH, IGNITION

36 890157-19830 1

LABEL, SWITCH

37 156114-04920 2

GROMMET

38 162021-30830 1

LEAD

39 900242-04008 1

SCREW

4*8

40 900220-04008 1

SCREW 4*8

4*8

41 145610-30830 1

MUFFLER

42 900162-04010 4

BOLT, H.S. 4*10

4*10 W,SW

43 145861-30830 1

LID, MUFFLER

46 145510-30830 1

GASKET, MUFFLER

47 900162-06020 2

BOLT, H.S. 6*20

6*20 W.SW

48 145711-30830 1

BRACKET, MUFFLER

49 145813-31730 1

COVER, MUFFLER

50 900162-05020 1

BOLT, H.S. 5*20

5*20 W,SW

- 5 -

CS-8001(6digits)(36)

3. Start r, Magn to(Sr/Nr 36001915 and b for )

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

1 101534-30830 1

PLATE, GUIDE

2 900162-05020 2

BOLT, H.S. 5*20

5*20 W,SW

3 156800-32631 1

ROTOR, MAGNETO

4 101521-30831 1

FAN, COOLING

Sus. by 101521-

30832

4 101521-30832 1

FAN, COOLING

5 100143-19830 1

WASHER

8.2*31*0.8

6 433019-12330 1

NUT, FLANGE 8

M-8

7 159012-03433 1

CAP, SPARK PLUG

8 159011-03432 1

COIL, SPARK PLUG

9 159017-31730 1

PLUG, SPARK RCJ-6Y

RCJ-6Y

10 152112-05730 1

BUSHING

11 156601-30831 1

COIL, IGNITION

12 900162-04020 2

BOLT, H.S. 4*20

4*20 W,SW

13 150611-30830 1

TUBE

7*8.6*45

20 177234-30830 2

SPRING, RETURN

21 177247-12331 2

SPACER, RATCHET

22 177218-30830 2

PAWL, STARTER

23 900603-00005 2

WASHER 5

5.5*12*0.8

24 900162-05030 2

BOLT, H.S. 5*30

5*30 W,SW Sus. by V203-

000140

24 V203-000140 2

BOLT,5

5*30

25 101535-30830 1

COVER, FAN

26 177200-30831 1

STARTER ASSY

27 + 900238-05014 1

SCREW 5*14

5*14 Sus. by 900162-

05014

- 6 -

CS-8001(6digits)(36)

3. Start r, Magn to(Sr/Nr 36001915 and b for )

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

27 + 900162-05014 1

BOLT, H.S. 5*14

5*14 W,SW

28 + 177214-02830 1

WASHER

5.2*16*1.0T

29 + 177226-07060 1

ROPE, STARTER

4.0*950

30 + 177206-14330 1

DRUM, STARTER

31 + 177216-12330 1

COLLAR

32 + 177242-30830 1

PLATE, STARTER

33 + 177220-02834 1

SPRING, REWIND

34 + 177221-02830 1

PLATE, STARTER

35 + 177228-30830 1

GRIP, STARTER

36 + 177227-07060 1

GUIDE, ROPE

37 900162-05020 4

BOLT, H.S. 5*20

5*20 W,SW

38 890118-17930 1

LABEL, ECHO

Sus. by X502-

000460

- 7 -

CS-8001(6digits)(36)

4. Start r, Magn to(Sr/Nr 36001916 and aft r)

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

1 101534-30830 1

PLATE, GUIDE

2 900162-05020 2

BOLT, H.S. 5*20

5*20 W,SW

3 156800-32631 1

ROTOR, MAGNETO

4 101521-30832 1

FAN, COOLING

5 100143-19830 1

WASHER

8.2*31*0.8

6 433019-12330 1

NUT, FLANGE 8

M-8

7 159012-03433 1

CAP, SPARK PLUG

8 159011-03432 1

COIL, SPARK PLUG

9 159017-31730 1

PLUG, SPARK RCJ-6Y

RCJ-6Y

10 152112-05730 1

BUSHING

11 156601-30831 1

COIL, IGNITION

Sus. by 156601-

30832

12 900162-04020 2

BOLT, H.S. 4*20

4*20 W,SW

13 150611-30830 1

TUBE

7*8.6*45

20 177234-30830 2

SPRING, RETURN

21 177247-12331 2

SPACER, RATCHET

22 177218-30830 2

PAWL, STARTER

23 900603-00005 2

WASHER 5

5.5*12*0.8

24 V203-000140 2

BOLT,5

5*30

25 101535-30830 1

COVER, FAN

26 177200-30831 1

STARTER ASSY

27 + 900162-05014 1

BOLT, H.S. 5*14

5*14 W,SW

28 + 177214-02830 1

WASHER

5.2*16*1.0T

29 + 177226-07060 1

ROPE, STARTER

4.0*950

30 + 177206-14330 1

DRUM, STARTER

31 + 177216-12330 1

COLLAR

- 8 -

CS-8001(6digits)(36)

4. Start r, Magn to(Sr/Nr 36001916 and aft r)

KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1

NOTE2

32 + 177242-30830 1

PLATE, STARTER

33 + 177220-02834 1

SPRING, REWIND

34 + 177221-02830 1

PLATE, STARTER

35 + 177228-30830 1

GRIP, STARTER

36 + 177227-07060 1

GUIDE, ROPE

37 900162-05020 4

BOLT, H.S. 5*20

5*20 W,SW

38 890118-17930 1

LABEL, ECHO

Sus. by X502-

000460

38 X502-000460 1

LABEL,ECHO

- 9 -
