LUX LUMEN BigEye IP67 User manual
BigEye RGB LED spot
IP67 version
BigEye RGB LED spot IP67 p.2/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
CONTENT
1 PICTURE .................................................................................. 3
2 DIMEN ION ........................................................................... 4
3 PECIFICATION ..................................................................... 5
3.1
GENERAL
....................................................................................... 5
3.2
M
ECHANICAL SPECS
.......................................................................... 5
3.3
E
LECTRICAL SPECS
: .......................................................................... 5
3.4
P
HOTOMETRIC SPECS
: ....................................................................... 5
4 AFETY INFORMATION ............................................................ 6
4.1
S
YMBOLS
...................................................................................... 6
4.2
P
ROTECTION FROM ELECTRIC SHOCK
....................................................... 7
4.3
P
ROTECTIONS FROM FIRE AND BURNS
...................................................... 7
4.4
P
ROTECTION FROM INJURY
.................................................................. 8
4.5
D
ISPOSING OF THIS PRODUCT
.............................................................. 8
5 PHY ICAL IN TALLATION ....................................................... 9
5.1
U
NPACKING
.................................................................................... 9
5.2
L
OCATION AND ORIENTATION
............................................................... 9
5.3
M
OUNTING
..................................................................................... 9
6 EXTERNAL CONNECTION ...................................................... 10
7 EMC AND AFETY REQUIREMENT ......................................... 11
8 ERVICE AND MAINTENANCE ................................................ 12
8.1
S
AFETY PRECAUTIONS
...................................................................... 12
8.2
C
LEANING
.................................................................................... 12
9 WARRANTY ............................................................................ 13
9.1
A
PPLICATION OF WARRANTY
............................................................... 13
9.2
RMA
PROCEDURE
........................................................................... 15
10 U ED LI T OF ABBREVIATION .......................................... 16
BigEye RGB LED spot IP67 p.3/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
1
BigEye RGB LED spot IP67 p.4/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
2
Dimensions
230
223
73,6
247,19
70,5
183
40
BigEye RGB LED spot IP67 p.5/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
3
pecifications
3.1 general
The BigEye RGB LED spot is light fixture especi lly designed for
outdoor pplic tions where high light output is necess ry.
The LED PCB c rries 24 x 3W LED’s of which 8x Red, 8x Green
nd 8x Blue.
The housing is m de from solid luminium so it serves s cooler
s well.
An ddition l 700mA led driver nd power supply is necess ry to
use the BigEye RGB LED spot.
3.2 Mechanical specs
•Tot l weight: 590gr (20.8oz)
•Ingress Protection r ting: IP 67
•Aluminium housing, 15 µm nodized
•Aluminium mounting ring, 15 µm nodized
•24 pcs rebel 3W LED’s (8x red, 8x green, 8x blue) on PCB.
•4mm tempered, cle r gl ss.
•All f steners in st inless steel.
•Robust outdoor c ble.
3.3 Electrical specs:
•3 groups of 8 LEDs in seri l connection t 700mA const nt
current.
•Tot l power consumption 50W.
3.4 Photometric specs:
By using lenses the light output ngle c n be chosen:
- 120° without ny lens.
- 14° lenses
- 30° lenses
- 46° lenses
- Or mixture of different lenses.
BigEye RGB LED spot IP67 p.6/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
4
afety information
Before inst lling, powering up, or servicing the BigEye RGB LED
spot, it is highly recommended th t you re d this m nu l nd
ensure yourself th t you completely underst nd its content.
Observe the s fety prec utions in this m nu l. Inst ll nd
oper te the led-unit only s described in this m nu l, nd in
conformity with loc l regul tions. If you h ve ny questions how
to oper te this product s fely, ple se cont ct your point of s le.
4.1 Symbols
Following symbols re used to identify import nt s fety
inform tion on the product nd in this m nu l.
BigEye RGB LED spot IP67 p.7/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
4.2 Protection from electric shock
Although this device itself does not oper te with d ngerous
volt ges, the inst ll tion in which is intended to be used, c n
cont in d ngerous volt ges.
Shut down the power of the complete inst ll tion before c rrying
out ny inst ll tion, or m inten nce work.
Use only AC to DC power sources, suit ble for the pplic tion,
nd conform to loc l regul tions. Ple se ensure yourself th t the
AC to DC power supply is ble to deliver the r ted current
requirements of the inst ll tion.
If ny c ble, se l or housing is d m ged, cr cked or reformed,
disconnect the power of the inst ll tion immedi tely.
For ny ddition l servicing, not described in this m nu l, ple se
cont ct your point of s le.
4.3 Protections from fire and burns
Do not oper te this led-unit if mbient temper tures, is bove
45 °C (113 °F). Ple se ensure yourself th t sufficient ventil tion
round the led module is possible.
It might be necess ry to llow the led-unit to cool down for 5
minutes, before servicing.
Do not modify the led-fixture, in w y, not described in this
m nu l.
BigEye RGB LED spot IP67 p.8/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
4.4 Protection from in ury
Ensure yourself th t the led-module nd ll its ccessories re
securely f stened. Verify th t the led unit is firmly fixed to its
supporting underground.
4.5 Disposing of this product
This led-lighting device is m nuf ctured in compli nce with
directive of the Europe n community: w ste electric l nd
electronic lly equipment. Ple se help to preserve our
environment, nd ensure th t this product will be recycled
properly t the end of its life.
BigEye RGB LED spot IP67 p.9/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
5
Physical installation
Th nk you for selecting this RGB LED spot s best solution in
your setup.
W rning! Re d the s fety prec utions in this m nu l before
integr ting this led-unit into your inst ll tion.
Inst ll tion must be c rried out by qu lified profession ls only.
Assure yourself th t there is sufficient nd unrestricted ir flow
round the RGB LED spot.
5.1 Unpacking
The following items re included in your p ck ge:
•BigEye RGB LED spot, complete with focussing br cket
• Protective ntist tic p ck ging, with short form m nu l
5.2 Location and orientation
This BigEye RGB LED spot c n be used in ll directions.
5.3 Mounting
urface mounting
The BigEye RGB LED spot c n be mounted on ll kind of non
combustible m teri ls, but t ke in consider tion th t the module
c n h ve Tc of pprox 30 °C higher s mbient temper ture.
In c se of problems, or doubts, ple se cont ct your point of s le.
BigEye RGB LED spot IP67 p.10/16
LUX LUMEN - Kernenergiestr t 53A - 2610 WILRIJK – BELGIUM
T: +32 3 293 35 50 – F: +32 3 293 35 44
www.lux-lumen.com
6
External connections
afety precautions
Never connect the live power on the input termin ls of the
BigEye RGB LED spot! The BigEye RGB LED spot c n only be use
by proper 700mA led driver powered by 48 VDC power
supply.
In c se of doubts, cont ct your point of s le.
Polarity
The BigEye RGB LED spot is pol rity sensitive. So observe
pol rity nd c bling:
•Inner conductor m rked with 1 = Common +
•Inner conductor m rked with 2 = Red
•Inner conductor m rked with 3 = Green
•Inner conductor m rked with 4 = Blue
Improper connection, might d m ge the BigEye RGB LED spot
nd power supply perm nently. In c se of inversed pol rity, the
w rr nty is void.
Connectors
M ke sure to use IP66 connectors if the use of connectors is
necess ry, in n outdoor environment, to obt in IP66 for
complete system. The BigEye RGB LED spot c n be delivered
with suit ble IP66 connectors. Ple se cont ct your point of s le.
Power supply: Rated current
The r ted input current r nge of the BigEye RGB LED spot is
700mA. Use proper led driver.
We recommence the ‘LL 12ch LEDdriver 700mA’ with the proper
48VDC power supply. A highly suit ble, DMX driven LED driver.
One driver c n control up to 4 BigEye RGB LED spots.
