Logitech MX800 User manual

Logitech® Wireless Performance Combo MX800

Setup Guide

Logitech Wireless Performance Combo MX800

OFF ON

Important information

Safety, compliance, and warranty

Logitech® Wireless Performance Combo MX800

Setup Guide

Logitech Wireless Performance Combo MX800

English. . . . . . . . . Setup 4. . . . . . . . . . . . . . . . Product information 5

Français . . . . . . . . Installation 4. . . . . Informations relatives au produit 10

Nederlands . . . . . . Installatie 4. . . . . . . . . . . . . . .Productinformatie 15

Ελληνικά. . . . . . . . . Ρύθμιση 4. . . . . . . . . . . . . . Πληροφορίες για το προϊόν 20

По-русски . . . . . . . .Настройка 4. . . . . . . . . . . . . . . Сведения о продукте 25

Magyar . . . . . . . . Üzembe helyezés 4. . . . . . . . . . Termékinformáció 30

Česká verze . . . . . . Instalace 4. . . . . . . . . . . . Informace o produktech 35

Po polsku . . . . . . . Konﬁguracja 4. . . . . . . . . Informacje o produkcie 40

Eesti . . . . . . . . . . Seadistamine 4. . . . . . . . . . . . . . . . Tooteteave 45

Latviski . . . . . . . . Uzstādīšana 4. . . . . . . . . . . . Informācija par ierīci 50

Lietuvių . . . . . . . .Nustatymas 4. . . . . . . . . . . .Produkto informacija 55

Hrvatski . . . . . . . .Postavljanje 4. . . . . . . . . . Informacije o proizvodu 60

Srpski . . . . . . . . . Podešavanje 4. . . . . . . . . Informacije o proizvodu 65

Slovenščina . . . . . .Nastavitev 4. . . . . . . . . . . . . Informacije o izdelku 70

Slovenčina. . . . . . . Nastavenie 4. . . . . . . . . . . Informácie o výrobku 75

Română . . . . . . . . Instalare 4. . . . . . . . . . . Informaţii despre produs 80

Български . . . . . . . .Настройка 4. . . . . . . . . . . . . Информация за продукта 85

Українська . . . . . . .Настроювання 4. . . . . . . . . . . . .Відомості про продукт 90

Türkçe . . . . . . . . . Kurulum 4. . . . . . . . . . . . . . . . . . . Ürün bilgisi 95

101  . . . . . . . . . . . . . . . 4 . . . . . . . . . . . . . 

www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Logitech Wireless Performance Combo MX800

OFFON

OFF ON

Performance MX™

OFF ON

PULLPULL

OFF ON

www.logitech.com/download/mx800

USB

Logitech Wireless Performance Combo MX800

English 5

4. Multimedia volume zone

Mute

Volume down

Volume up

Calculator

5. FN key

6. Automatic light sensor (ALS)

7. Battery status indicator

8. Keyboard power switch

Keyboard features

OFFON

1. Application zone

FN + F1 Launch Internet browser

FN + F2 Launch e-mail application

FN + F3 Launch Windows Search*

FN + F4 Flip†

2. Convenience zone

FN + F5 Backlight down by 25%

FN + F6 Backlight up by 25%

FN + F7 Battery check

FN + F8 Sleep mode

* One Touch Search if the SetPoint® software is installed.

† Application Switcher if the SetPoint® software is installed.

3. Multimedia navigation zone

FN + F9 Launch media

FN + F10 Previous track

FN + F11 Play/Pause

FN + F12 Next track

Logitech Wireless Performance Combo MX800

6 English

Mouse features

Performance MX™

OFF ON

1. Left and right buttons

2. Scroll wheel

• Press wheel down for middle click

• Press wheel left to scroll left

• Press wheel right to scroll right

3. Scroll wheel mode shift button

• Press to shift between hyper-fast (free spinning)

and precision (click-to-click) scrolling

4. Battery indicator

5. Back and forward button

6. Zoom button

7. Application button

8. 0n/o switch

9. Battery door release

Logitech Wireless Performance Combo MX800

English 7

Recharging the mouse

To charge your mouse, plug the charging

cable into a powered USB port.

Recharge your mouse when the battery

indicator blinks red.

Do not use the receiver extender cable

for recharging. Use only AA NiMH

replacement batteries

(1800 mAh minimum).

Recharging the keyboard

Typically, you can expect about 10 days

of battery life before you will need

to recharge the keyboard battery.*

If the backlighting level is set to 100%,

you have about 15 hours of battery life.

To recharge the keyboard, connect it to

your computer using the USB recharging

cable. A full battery recharge takes about

5 hours and only 3 hours if the keyboard

has been switched o.

OFFON

* Battery life varies with usage, backlighting level, and computing conditions.

Heavy usage usually results in shorter battery life.

Recharging

Logitech Wireless Performance Combo MX800

8 English

Unifying

Logitech® Unifying technology connects up to six compatible Logitech mice and keyboards

to the same receiver, using only one USB port for multiple devices.

To learn more, visit:

www.logitech.com/support/unifying

What do you think?

Please take a minute to tell us.

Thank you for purchasing our product.

www.logitech.com/ithink

Logitech Wireless Performance Combo MX800

English 9

Troubleshooting

Mouse

No pointer movement?

1. Slide the mouse’s O/On switch to O and then On.

The mouse’s battery status indicator LEDs should light up.

2. Conﬁrm that the mouse is charged and battery polarity

is correct. The battery status indicator is red when the battery

is low.

3. Try plugging the Unifying receiver into another USB port.

4. Try reconnecting the mouse and Unifying receiver using

the Logitech Unifying software (see the Unifying section).

Erratic pointer movement or missed button clicks?

1. Remove metallic objects between the mouse and Unifying receiver.

2. If the Unifying receiver is plugged into a USB hub, try plugging it directly into your computer.

3. Move the Unifying receiver closer to the mouse by using the included receiver extender cable.

Keyboard

Keyboard not working?

1. Slide the keyboard’s O/On switch to O and then On.

The keyboard’s battery status indicator LEDs should light up.

2. Conﬁrm that the keyboard is charged. The battery status indicator

is red when the battery is low.

3. Try plugging the Unifying receiver into another USB port.

4. Move the Unifying receiver closer to the keyboard by using

the included receiver extender cable.

5. Try reconnecting the keyboard and Unifying receiver using

the Logitech Unifying software (see the Unifying section).

6. Restart the computer.

OFFON

OFF ON

Logitech Wireless Performance Combo MX800

10 Français

4. Zone de volume multimédia

Sourdine

Volume -

Volume +

Calculatrice

5. Touche FN

6. Capteur de luminosité

automatique

7. Témoin de charge des piles

8. Bouton d'alimentation

du clavier

Fonctionnalités du clavier

OFFON

1. Zone d'applications

FN + F1 Lance le navigateur Internet

FN + F2 Lance l'application

de courrier électronique

FN + F3 Lance le service

de recherche Windows*

FN + F4 Basculer**

2. Zone de fonctions pratiques

FN + F5 Réduit le rétroéclairage de 25%

FN + F6 Augmente le rétroéclairage

de 25%

* Fonction One Touch Search disponible si le logiciel SetSpoint® est installé.

** Fonction de changement d'application disponible si le logiciel SetSpoint® est installé.

FN + F7 Vériﬁe le niveau

de charge des piles

FN + F8 Mode de veille

3. Zone de navigation multimédia

FN + F9 Lance un dispositif

multimédia

FN + F10 Piste précédente

FN + F11 Lecture/Pause

FN + F12 Piste suivante
