LIVARNO LUX HG00776A Technical specifications

LED SOLAR LIGHT

LED-SOLARLEUCHTE

Montage-, Bedienungs- und Sicherheitshinweise

IAN 315252

LED-AURINKOKEN-

NOVALAISIN

Asennus-, käyttö- ja turvallisuusohjeet

LED SOLAR LIGHT

Assembly, operating and safety instructions

LED-SOLCELLSLAMPA

Monterings-, bruks- och säkerhetsanvisningar

SOLARNA LAMPKA LEDOWA

Wskazówki montażu, obsługi i

bezpieczeństwa

GB Assembly, operating and safety instructions Page 5

FI Asennus-, käyttö- ja turvallisuusohjeet Sivu 18

SE Monterings-, bruks- och

säkerhetsanvisningar Sidan 30

PL Wskazówki montażu, obsługi i

bezpieczeństwa Strona 42

DE/AT/CH Montage-, Bedienungs- und

Sicherheitshinweise Seite 56

HG00776A/HG00776C

HG00776B/HG00776D

5GB

List of pictograms used..................................... Page 6

Introduction................................................................ Page 6

Proper use......................................................................... Page 6

Description of parts and features.................................... Page 7

Scope of delivery............................................................. Page 7

Technical data.................................................................. Page 7

Safety instructions................................................ Page 8

Product-specific safety instructions .................................. Page 9

Safety instructions for batteries/rechargeable

batteries............................................................................ Page 10

Functioning.................................................................. Page 11

Preparing for use .................................................. Page 11

Installing the product........................................................ Page 12

Setting up the product...................................................... Page 12

Replacing the rechargeable battery............................... Page 13

Charging the rechargeable battery................................ Page 13

Maintenance and care...................................... Page 14

Troubleshooting ..................................................... Page 14

Disposal......................................................................... Page 15

Warranty...................................................................... Page 16

6 GB

List of pictograms used

Splash-proof (IP44)

LED solar light

Introduction

We congratulate you on the purchase of your new product. You

have chosen a high quality product. The instructions for use are

part of the product. They contain important information concern-

ing safety, use and disposal. Before using the product, please fa-

miliarise yourself with all of the safety information and instructions

for use. Only use the product as described and for the speciﬁed

applications. If you pass the product on to anyone else, please

ensure that you also pass on all the documentation with it.

Proper use

The product is intended for outdoor use. The product is intended

for private use only. The product is not intended for commercial or

for use in other applications.

Not suitable for ordinary lighting in household

room illumination.

This product is suitable for extreme temperature up to -21°C.

7GB

Descri

ption of parts and feat

ures

1Solar cell

2Solar housing

3Recess

4Rechargeable battery

compartment cover

5Rechargeable battery

6Groove

7Rechargeable battery

compartment

8ON/OFF switch

9Housing

10 Ground spike

Scope of delivery

1 LED solar light

1 Ground spike

1 Rechargeable battery Ni-MH (nickel-metal hydride), AA/

1.2V/600 mAh (pre-installed)

1 Assembly, operating and safety instructions

Technical data

Operating voltage: 1.2V (direct current)

Rechargeable battery: 1x rechargeable battery Ni-MH (nickel-

metal hydride)/AA/1.2V/600mAh

LED: 1x LED (not replaceable)

Rated power LED: approx. 0.06W per LED

Protection type: IP44 (splash proof)

Solar cell: approx. 66 x 66mm

8 GB

Safety instructions

BEFORE USING THE PRODUCT, PLEASE FAMILIARISE

YOURSELF WITH ALL OF THE SAFETY INFORMATION AND

INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT

ON TO OTHERS, PLEASE ALSO INCLUDE ALL THE DOCUMENTS!

DANGER TO LIFE AND

RISK OF ACCIDENTS FOR INFANTS AND

CHILDREN! Never leave children alone and

unsupervised with the packaging material. There is always a

risk of suﬀocation if children play with the packaging material

Children often underestimate risks. Always keep children away

from the packaging material. This product is not a toy.

This product can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

product in a safe way and understand the hazards involved.

Children shall not play with the product. Cleaning and user

maintenance shall not be made by children without supervision.

Never leave children unattended with the packaging material.

It can cause suﬀocation. Children often underestimate dangers.

Always keep children away from the product.

This product is not a toy and should be kept out of the reach

of children. Children are not aware of the dangers associated

with handling electrical products.

Do not use the product if you detect any kind of damage. The

LED cannot be replaced.

The LED is not replaceable.

9GB

If the LED fails at the end of its life, the entire product must be

replaced.

CAUTION! DANGER OF EXPLOSION! Do

not operate the product in potentially explosive en-

vironments in which there are inﬂammable vapours,

gases or dusts.

Product-speciﬁc safety instructions

Do not subject the product to strong vibrations or high

mechanical loads.

Make sure that the solar cell 1is free of dirt and free of snow

and ice in winter. Otherwise the performance of the solar cell

1will diminish.

Cold temperatures have a negative inﬂuence on the operating

life of the rechargeable battery. If the product is not going to

be used for a long time, e.g. in winter, it should be switched

oﬀ, taken up, cleaned and stored in a dry, warm room.

Never open up the solar housing 2! In the event of damage,

repairs or other problems with the product, please contact an

electrician. The LED is not replaceable.

CAUTION! DANGER OF EXPLOSION! Use

only rechargeable battery of the recommended

type. Other rechargeable or single-use batteries

could explode during charging.

RISK OF INJURY! Make sure that when the

housing 9is removed that the ground spike 10 is also removed

so they cannot pose any risk (e.g. stumbling over them).

Dispose of the product in the proper way if the product is

damaged.

10 GB

Safety instructions for batteries/

rechargeable batteries

DANGER TO LIFE! Keep batteries / rechargeable batteries

out of reach of children. If accidentally swallowed seek

immediate medical attention.

DANGER OF EXPLOSION! Never recharge

non-rechargeable batteries. Do not short-circuit bat-

teries/rechargeable batteries and/ or open them.

Overheating, ﬁre or bursting can be the result.

Never throw batteries/rechargeable batteries into ﬁre or water.

Do not exert mechanical loads to batteries / rechargeable

batteries.

Risk of leakage of batteries/rechargeable batteries

Avoid extreme environmental conditions and temperatures,

which could aﬀect batteries/rechargeable batteries, e.g.

radiators/ direct sunlight.

If batteries/rechargeable batteries have leaked, avoid contact

with skin, eyes and mucous membranes with the chemicals!

Flush immediately the aﬀected areas with fresh water and seek

medical attention!

WEAR PROTECTIVE GLOVES! Leaked or dam-

aged batteries/rechargeable batteries can cause

burns on contact with the skin. Wear suitable pro-

tective gloves at all times if such an event occurs.

In the event of a leakage of batteries/ rechargeable batteries,

immediately remove them from the product to prevent damage.

Remove batteries/rechargeable batteries if the product will

not be used for a longer period.
