LIVARNO LUX Lux Instruction sheet
User manual and service
information
Instruc
ţ
iuni de deservire
ş
i
informa
ţ
ii cu privire la
service-are
Εγχειρίδιο χρήσης και
πληροφορίες για την τεχνική
εξυπηρέτηση
Bedienungsanleitung &
Serviceinformationen
GB
GR
CY
Korisni
č
ki priru
č
nik i
informacije o servisu
HR
Ръководство за потребителя и
информация за сервиза
A T
CH
CY
Mat-No: 1584345, 1584342
TARGA GmbH
Lange Wende 41
D-59494 Soest
www.service.targa.de
www.service.targa.co.uk
Mod.-Nr. BL3710 7
HALOGEN DESK LAMP
Halogen desktop lamp BL3710
Operating and Safety Instructions ..................................2
Halogena stolna svjetiljka BL3710
Upute za uporabu i sigurnost........................................ 13
Lampăde birou cu halogen BL3710
Instrucţiuni de siguranţă şi de utilizare..........................25
Халогенна настолна лампа BL3710
Инструкции за ползване ибезопасност2 ..................37
Επιτραπέζιο φωτιστικό αλογόνου BL3710
Οδηγίες ασφάλειας και λειτουργίας ..............................49
Halogen-Schreibtischleuchte BL3710
Bedienungs- und Sicherheitshinweise..........................61
IAN 53032 Version / Verzija / Versiunea / Версия / Έκδοση v1.9
Halogen Desktop Lamp LivarnoLux BL3710
2 - English
Table of Contents
Package Contents ................................................................ 3
Safety Instructions ................................................................ 4
Power Cable ..................................................................... 6
Intended Use..................................................................... 6
Technical Specifications ....................................................... 7
Conformity......................................................................... 7
Getting Started ..................................................................... 8
Unpacking and Assembling the Device............................. 8
Switching the Device On/Off ............................................. 9
Orientating the Lamp ........................................................ 9
Appendix............................................................................. 10
Replacing the Bulb.......................................................... 10
Cleaning.......................................................................... 10
Disposal of Old Devices.................................................. 11
Warranty Information ...................................................... 12
Halogen Desktop Lamp LivarnoLux BL3710
English - 3
Package Contents
Halogen desktop lamp BL3710
User manual with Safety Instructions
(not illustrated)
Halogen Desktop Lamp LivarnoLux BL3710
4 - English
Safety Instructions
Before you use this device for the first time, please read the
following notes in this manual and heed all warnings, even if
you are familiar with handling electronic devices. Keep this
manual safe for future reference. If you sell the device or
pass it on, it is essential that you also hand over this manual.
This icon denotes important information for
the safe operation of the product and for the
user’s safety.
The minimum distance to any lighted surfaces
must be 20 cm (7.9 inches).
Every broken protective cover must be replaced.
This lamp has been designed for “self-shielded”
halogen bulbs.
Halogen Desktop Lamp LivarnoLux BL3710
English - 5
Never use any optical devices such as a lens to look
directly into the light beam. This can cause eye damage.
Electrical devices do not belong in the hands of children.
Do not allow children to use electrical devices when not
under supervision. Children may not understand that they
can be dangerous. Keep the packaging away from
children too as there is danger of suffocation.
If you notice any smoke, unusual noises or strange
smells, switch off the device immediately and remove the
plug from the wall outlet. Do not inhale any smoke
originating from a device fire. In these cases the device
should no longer be used and should be inspected by
authorized service personnel. If you have nonetheless
inhaled smoke, consult a physician.
The lamp housing and the power cable may not be
damaged in any way. The outer flexible cable of the lamp
cannot be replaced. If the cable becomes damaged, the
lamp must be disposed of.
Never open the device housing. It does not contain any
parts that require user maintenance. High-voltage
components may cause electric shocks.
Halogen Desktop Lamp LivarnoLux BL3710
6 - English
Power Cable
Unplug the power cable by holding the plug and never pull
on the cable itself. Never place the device, items of furniture
or other heavy objects on the power cable and take care that
the cable does not become trapped. Never tie knots in the
cable and do not tie it together with other cables. All cables
should be positioned so that nobody can trip over them or be
obstructed by them. Never use adapter plugs or extension
cables that do not comply with the safety regulations
applicable in your country, and do not modify any of the
cables yourself.
Intended Use
The halogen desktop table lamp BL3710 can be used as a
lamp for your desk. The flexible arm allows you to adjust the
light to suit your needs. Always make sure the lamp is on a
stable surface.
This lamp is not intended for commercial use. This lamp has
been explicitly designed for indoor use in dry rooms. The
device fulfils all relevant norms and standards associated
with CE Conformity. Any modifications to the device other
than recommended changes by the manufacturer may result
in these directives no longer being met.
Halogen Desktop Lamp LivarnoLux BL3710
English - 7
Technical Specifications
Manufacturer: LivarnoLux
Model name: BL3710
Operating voltage: 220 - 240 VAC, 50 - 60 Hz
Bulb: Osram G9 33W
Halopin Eco bulb
(Energy Saver)
Cable length: approx. 2 m (6 ft)
(with cable On/Off switch)
Safety Class: II
Nominal power: max. 33 W
Base diameter: approx. 20.5 cm
Shade diameter: approx. 11 cm
Length of both arms: approx. 40 cm each
(measured from the pivot point)
Weight: approx. 2850 g
Conformity
This device fully complies with the basic
and other relevant requirements of EMC
Directive 2004/108/EC.
Halogen Desktop Lamp LivarnoLux BL3710
8 - English
Getting Started
Unpacking and Assembling the Device
Unpack the halogen desktop lamp and the base.
Loosen the screw (4) on the base.
Place the tenon joint of the lamp into the hole in the
base and tighten the screw.
Be sure that the tenon joint is fully inserted into the
base (see the figure below). Otherwise it will not be
possible to tighten the screw.
