Lite Blox LB Series User manual
INSTRUCTION
MANUAL
ENGLISH
V1.1
54
1. Safety guidelines
1.1. General
1. Advices
1.3. Disposal
1.4. Safety symbols
1.5. Product labelling
. Introduction
.1. Product description
. . Intended use
.3. Glossary of terminology
.4. Used symbols
3. Product specifications
3.1. Technical specifications
3.1.1. Electrical specifications
3.1. . Mechanical specifications
3.1.3. Charge and discharge specifications
3.1.4. Temperature specifications
3.1.5. Compliance specifications
3.1.6. General product specifications
3. . Environmental conditions
3.3. Required tools
3.4. Scope of delivery
3.5. Connections
3.6. Optional components
3.7. Protection thresholds
4. Installation
4.1. General information
4. . Unpacking
4.3. First use
4.3.1. Placement
4.3. . Connecting wires
4.3.3. Connecting charger
4.4. Disconnecting
5. Battery use
5.1. General information
5. . Charging
5. .1. Charging rates
5.3. Intelligent BMS
5.3.1. I.K.O.S
5.3. . A.V.A.T.
5.3.3. Self protection
5.4. Sitting time
5.4.1. Without load
5.4. . In vehicle
5.5. Vehicle integration process
5.6. LITE BLOX remote APP
5.6.1. Status display
5.6. . Cut o switches
5.6.3. Reactivation
76
5.6.4. Charts
5.6.5. Telemetry data
6. Inspection and cleaning.
6.1. General information
6. . Inspection
6.3. Cleaning
7. Storage
8. Transportation
9. Disposal & recycling
10. Troubleshooting
11. Warranty and liability
SAFETY
GUIDELINE
1110
1|SAFETY GUIDELINES
1.1
GENERAL
ATTENTION! Please read the following instructions carefully.
This manual is an extension to the printed DIN A6 flyer for „startup &
maintenance“ that comes with your LITE BLOX battery. It is part of the
product and contains important notes for correct handling &
maintenance. Therefore please make sure to store this document at a
safe place in order to have it at hand at all times in cases of uncertainties
and when the product is passed on.
1.
ADVICES
Please pay close attention to the following advices in order to ensure an immaculate operation at any time for
maximum product life:
• Refer to this manual for appropriate installation, maintenace & charging.
• Do not remove the LITE BLOX battery from its original packaging until required for use.
• Always keep your LITE BLOX clean and dry.
• Only use as starter battery on common automotive alternators
• Pay attention to the plus (+) & minus (–) marks on the LITE BLOX battery as well as on the
peripherals to ensure correct use at any time.
• Do not short circuit your LITE BLOX & treat as described in this manual.
• Only use appropriate chargers, validated for use with Lithium Iron Phosphate batteries (LiFePO4).
• Do not mix batteries of dierent manu facture, capacity, size or type in one application.
• Never leave your LITE BLOX plugged to a battery charger without attendance.
• Never charge your LITE BLOX at an environment temperature below - 0°C.
• Disconnect from the vehicles peripherals when not in use for longer sitting periods.
• Recharge on extended storage periods (>150days when fully charged)
• Do not dismantle, crush, puncture, open or shred your LITE BLOX.
• Do not expose your LITE BLOX to heat or fire. Avoid exposure to direct sunlight.
• In the event of a chemical reaction of the battery cells, avoid contact with skin or eyes.
1110
1.3
DISPOSAL
Dispose the LITE BLOX battery in accordance with local, state and federal
laws and regulations. Batteries may be returned to the manufacturer.
Do not mix with other industrial waste.
1.4
SAFETY SYMBOLS
The following markings can be found on the product:
Battery can
be recycled
Do not dispose in
household waste
1|SAFETY GUIDELINES
1.5
PRODUCT LABELING
Please note that Li-ion batteries have to be treated differently from
conventional lead-acid batteries. Therefore, make sure to pay close
attention to the specifications & thresholds on the label attached to your
LITE BLOX LBXXXX (LB14XX / LB 0XX / LB 8XX) battery model - do not
remove and get in touch if missing!
INTRO-
DUCTION
1716
.
INTENDED USE
Our LBXXXX(MS) series Li-ion battery is only to be used as a power source
for starting combustion engines, whit a 1 V board net, backed by common
automotive alternators.
Therefore, it is not advised to use the battery in vehicles or systems where
the battery voltage, current or temperature exceeds the specified working
range (see 1.5).
The LBXXXX(MS) series battery has an integrated BMS, monitoring whether
the LITE BLOX is being misused or used outside of the intended working
space and may disconnect from the vehicles peripherals in order to protect
the Li-ion cells from permanent harm or damage (see 3.7).
|INTRODUCTION
.1
PRODUCT DESCRIPTION
Our LBXXXX(MS) high performance battery series has been developed extensively over the past 6
years for maximum performance, reliability and safety. Thanks to premium LITHIUMWERKS (R)
lithium iron phosphate battery cells in combination with our industry leading intelligent Battery
Management System (BMS), all LITE BLOX batteries are extremely reliable and oer an outstanding
cyle life according to our company maxim: quality before quantity
18
.3
GLOSSARY OF TERMINOLOGY
IBS --> Intelligent Batterymanagement System
SOC --> State Of Charge
CCCV --> Constant Current-Constant Voltage
ECU --> Engine Control Unit
OEM --> Original Equipment Manufacturer
LFP --> Lithium Iron Phosphate (LiFePO4)
BMS --> Battery Management System
.4
SYMBOLS
Following icons will be used throughout the manual:
! W A R N I N G ! ! C A U T I O N !
|INTRODUCTION
1
PRODUCT
SPECI-
FICATIONS
This manual suits for next models
3
