Lilliput 569-O/P User manual

COLOUR TFT

LCD

MONIT

Use

Manu

MPOR

SAFETY

ONS

Please read manual before using this product.

Please keep manual for future reference.

Please read the cautions to prevent possible danger and loss of property

Please enjoy the benefits of convenience, safety, and space-saving from this

TFT LCD monitor in different ways.

ROD

TS:

This product employs integrate circuits, lower power consumption, and lower

radiation emission. It has fashion designed appearance and good portability.

With peaking, false color, exposure and histogram functions

HDMI & YPbPr Input, to connect with Full HD Video Camera.

LED backlight display, supports 1920×1080 HD resolution.

With sun shade to see clearly under sunshine.

Center Marker, Screen Marker, RGB, mono and color display, 16:9、4:3and

full screen aspect ratio switch, underscan/overscan switch, HDMI & Video

signal loop output.

CAUTION

S：

1. Please do not place the display screen toward the ground.

2. Please avoid heavy impact or drop onto the ground.

3. Please do NOT use chemical solutions to clean this product. Please wipe with

a clean soft cloth to maintain the brightness of the surface.

4. Please do not block any vent hole.

5. Please follow the instructions and trouble-shootings to adjust the product.

Other improper adjustment may result in damage. Any further adjustment

must be performed or conducted by a qualified technician.

6. Please unplug the power and remove the battery if long-term no-use, or

thunder weather.

PRODUCT

DESC

RIP

TION

1. EAR: Earphone jack

2. POWER: ON/OFF (light turns red when standby, turns green when

working)

3. VIDEO: Indicator lights up when signal switch to video state.

4. YPbPr: Indicator lights up when signal switch to YPbPr state.

5. HDMI: Indicator lights up when signal switch to HDMI state.

6. F1、F2、F3、F4：user-definable function buttons: mark, underscan, color

mode, ratio, camera, peaking, false color, exposure and histogram.

Def

F1: PEAKING

F2: FALSE COLOR

F3: EXPOSURE

F4: HISTOGRAM

7. Knob BRI/M/SEL: Press the knob to access the menu function, pressing

the knob in the menu to return to the previous page or exit the

menu.Rotate knob to select an option. (Default: Brightness function,

rotate the knob to adjust the brightness directly.)

8. Knob VOL/ADJ: Rotate knob to confirm the selection and adjust the

parameter values. (Default: Sound function, turn the knob to adjust the

volume)

9. Sun shade cover

10. Mounting socket (left side)

11. Video signal output

12. Video signal input

13. Audio signal input

14. Y signal input

15. Pb signal input

16. Pr signal input

17. HDMI (High Definition Multimedia Interface) signal output

18. HDMI (High Definition Multimedia Interface) signal input

19. Mounting socket (bottom)

20. Battery slot

21. DC power input

22. Battery power on/off switch

23. Speaker

24. Mounting socket (right side)

There

are 3

bracket

jacks in the

Lift

、

right

and bottom of the device,

shown“

”

。

BATTERY MOUNT

Standard

mounts

process

：

Following three types of battery plates are suitable for this device, user can

choose two of the three (See the pictures below).

DV Battery Mount

ate:

Model DU21 for

battery

of Panasonic

DV:

NV-GS/PV-GS/DZ-MV/GS/H28/H258/H288GK series, comply with Panasonic

battery DU06/VBD140/SANYO DZhs301sw/Hitachi

DZ-HS303SW/BZ-BP14S/DZ3200/BP07W.

Model QM91D for

battery

of SONY

DV:

DSCR1/F/S/MVCCD/E/HC15E/HC1E/AE1u/DCRTRV828/E/CCD-TRV116/D

CR-DVD/PS105K/300K/10P/1E series.

Model F970 for

battery

of SONY

DV:

DCR-TRV series, DCR-TRV E series, VX2100E PD P series, GV-A700,

GV-D800 FD/CCD-SC/TR3/FX1E/HVR-AIC, HDR-FX1000E, HVR-Z1C,

HVR-V1C, FX7E F330.

a –

ill

iput.co

m.ru

NAM

UNCTION

Brightness Adjust the level of brightness

Contrast Adjust the level of contrast

Saturation Adjust the level of saturation

Sharpness Adjust the sharpness of picture

Tint Adjust the tint of image

Volume Adjust the volume

Color mode Choose the color temperature. Options:

User, 6500ºK, 7500 ºK, or 9300 ºK.

Red

Green

Blue

Note: Only available under “User” mode to

meet the color value you need.

SETTING

MEN

Before setting the functions, please make

sure

the device is connected

corr

ect

ly.

When power on, press BRI/M/SEL knob on the device, function menus will pop-

up on the screen.

Rotate BRI/M/SEL knob to select the options displayed on the screen, than rotate

SAT/ADJ knob to confirm and adjust option value.

After confirm the option value, then press BRI/M/SEL knob to return to

the previous, and press the BRI/M/SEL knob again to exit the menu settings.

MAIN

ENU:


ENU

EY CON

IGUR

4 user-definable function buttons: F1

F2, F3 and F4 functions can be customized as:

mark, underscan, color mode, ratio, camera, peaking, false color, exposure and

histogram.

Knobs 1-2 can be set to alter the brightness, contrast, saturation, sharpness, tint,

volume, red, green, and blue for the shortcut keys.

Knob 1 defaults as Brightness function.

Knob 2 defaults as Volume function. .

SOURCE

ENU

Disable or Enable the following input sources:

VIDEO

、

YPbPr

、

HDMI.

MISC

ENU

Blue mode:

blue mode can be set on/off.

Reset:

confirm the recovery into factory mode.

Language:

English/Chinese switch.

Peaking:

Mono/Color

SSORIES

Standard

acc

esso

ries

1. Sun shade cover 1 piece

2. Battery plate (DC21/QM91D/F970/LP-E6) 2 piece (choose 2 out of 4)

3. Manual 1 copy

4. Shoe mount (for camera only) 1 piece

5. DC adapter 1 piece

Optional

acc

esso

ries

1. HDMI to mini HDMI cable 1 piece

2. Li-ion battery 1 piece
