Lightolier ProSpec 37113 User manual

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

ProSpec™120V/277V Track Lighting 37113

Page 1 of 2 Mini HID, Step Spot, 70W PAR30 CMH

Features

1. Track Attachment Fitting: Molded polycarbonate, rotates into track.

2. Locking Lever: Steel pin. Locks and detaches unit.

3. Track Adaptor Housing: Die-cast aluminum.

4. Ballast Housing: Extruded aluminum housing with die-cast aluminum

end caps.

5. Ballast: Electronic HID.

6. Tension Pivot Mounts: Allows for 350° horizontal and 180° vertical

rotation with tensioned mounts for controlled aim.

7. Lamp Housing: Die-cast aluminum.

8. Lampholder: Medium base 5kV pulse rated glazed porcelain body socket

with plated nickel screw shell and lamp contacts; 18AWG SEW-2 leads

encased in fiberglass sleeving.

Accessories

Holder: 8473, holds one accessory

Diffusion/ Special Filters: AF3 series

Color Filters: ADF3 series

Louver (Hex Cell): AL3HC

Electrical

Electronic Ballast (Thermally Protected)

Input Voltage: 120V/277V Total Harmonic Distortion: <10%

Power Factor: >0.99 ANSI Code: M (C) 85, M (C) 98,

M (C) 139, M (C) 143Input Power: 77W

Max Input Current: Do not use on dimming circuit

0.65A@120V/0.28A@277V

Finish

All painted finishes are baked powder or enamel.

Markings

UL, cUL

7 7/32

[184 mm]"

7 7/8

[200 mm]"

1 15/16

[50 mm]"

5 13/16

[148 mm]"

7 5/32

[182 mm]"

4 9/16

[115 mm]"

1 5/8

[41 mm]"

2 1/2

[64 mm]"

6 7/32

[158 mm]"

4 9/16

[ 116 mm]"

Catalog No. Finish Mounting Lamp

37113WH

37113BK

White

Black

ProSpec®120V/277V track systems only. 70W PAR30 CMH (M98) E26 medium base

Not included

Job Information Type:

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

ProSpec™120V/277V Track Lighting 37113

Page 2 of 2 Mini HID, Step Spot, 70W PAR30 CMH

Aiming Angle: 0° 30° Horizontal 30° Vertical 45° Vertical

L Beam length DDistance

W Beam Width AAiming Angle

CDistance to center beam FC Footcandles

Land W are the outer points where the candle

power drops to 50% of the maximum. FC are the

initial footcandles at the center of the beam.

Lamp data shown is typical. Consult lamp manu-

facturers for availability and performance.

CBCP = Center Beam Candle Power.

10000 11000

Philips

CMH70PAR30L/FL 40°

68000 11000

Philips

CMH70PAR30L/SP 10°

43000 11000

GE CMH70PAR30L/SP

15°

10000 11000

GE CMH70PAR30L/FL

40°

42000 12000

Sylvania

CMH70PAR30L/SP 12°

D FC L W D C FC L W D C FC L W D C FC L W

Lamp

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

12' 6.9' 194 4.2' 3.6'

14' 8.1' 142 4.9' 4.3'

16' 9.2' 109 5.6' 4.9'

18' 10.4' 86 6.4' 5.5'

5' 8.7' 215 5.6' 2.6'

6' 10.4' 149 6.7' 3.2'

7' 12.1' 110 7.8' 3.7'

8' 13.9' 84 8.9' 4.2'

7' 7.0' 310 3.8' 2.6'

8' 8.0' 238 4.3' 3.0'

9 9.0' 188 4.8' 3.4'

10' 10.0' 152 5.4' 3.7'

12' 299 3.2' 3.2'

14' 219 3.7' 3.7'

16' 168 4.2' 4.2'

18' 133 4.7' 4.7'

8' 4.6' 101 8.1' 6.7'

10' 5.8' 65 10.2' 8.4'

12' 6.9' 45 12.2' 10.1'

14' 8.1' 33 14.2' 11.8'

3' 5.2' 139 14.5' 4.4'

4' 6.9' 78 19.3' 5.8'

5' 8.7' 50 24.2' 7.3'

6' 10.4' 35 29.0' 8.7'

5' 5.0' 141 8.4' 5.1'

6' 6.0' 98 10.1' 6.2'

7' 7.0' 72 11.7' 7.2'

8' 8.0' 55 13.4' 8.2'

8' 156 5.8' 5.8'

10' 100 7.3' 7.3'

12' 69 8.7' 8.7'

14' 51 10.2' 10.2'

12' 6.9' 189 3.4' 2.9'

14' 8.1' 139 3.9' 3.4'

16' 9.2' 107 4.5' 3.9'

18' 10.4' 84 5.1' 4.4'

5' 8.7' 210 4.3' 2.1'

6' 10.4' 146 5.2' 2.5'

7' 12.1' 107 6.1' 2.9'

8' 13.9' 82 7.0' 3.4'

7' 7.0' 303 3.0' 2.1'

8' 8.0' 232 3.4' 2.4'

9 9.0' 183 3.8' 2.7'

10' 10.0' 148 4.3' 3.0'

12' 292 2.5' 2.5'

14' 214 2.9' 2.9'

16' 164 3.4' 3.4'

18' 130 3.8' 3.8'

12000 12000

Sylvania

CMH70PAR30L/FL 30°

8' 4.6' 122 5.9' 5.0'

10' 5.8' 78 7.3' 6.2'

12' 6.9' 54 8.8' 7.4'

14' 8.1' 40 10.2' 8.7'

3' 5.2' 167 8.2' 3.2'

4' 6.9' 94 10.9' 4.3'

5' 8.7' 60 13.7' 5.4'

6' 10.4' 42 16.4' 6.4'

5' 5.0' 170 5.8' 3.8'

6' 6.0' 118 6.9' 4.5'

7' 7.0' 87 8.1' 5.3'

8' 8.0' 66 9.2' 6.1'

8' 188 4.3' 4.3'

10' 120 5.4' 5.4'

12' 83 6.4' 6.4'

14' 61 7.5' 7.5'

12' 6.9' 307 2.8' 2.4'

14' 8.1' 225 3.3' 2.8'

16' 9.2' 173 3.7' 3.2'

18' 10.4' 136 4.2' 3.6'

5' 8.7' 340 3.6' 1.7'

6' 10.4' 236 4.3' 2.1'

7' 12.1' 173 5.0' 2.4'

8' 13.9' 133 5.7' 2.8'

7' 7.0' 491 2.5' 1.7'

8' 8.0' 376 2.8' 2.0'

9 9.0' 297 3.2' 2.2'

10' 10.0' 240 3.5' 2.5'

12' 472 2.1' 2.1'

14' 347 2.4' 2.4'

16' 266 2.8' 2.8'

18' 210 3.1' 3.1'

8' 4.6' 101 8.1' 6.7'

10' 5.8' 65 10.2' 8.4'

12' 6.9' 45 12.2' 10.1'

14' 8.1' 33 14.2' 11.8'

3' 5.2' 139 14.5' 4.4'

4' 6.9' 78 19.3' 5.8'

5' 8.7' 50 24.2' 7.3'

6' 10.4' 35 29.0' 8.7'

5' 5.0' 141 8.4' 5.1'

6' 6.0' 98 10.1' 6.2'

7' 7.0' 72 11.7' 7.2'

8' 8.0' 55 13.4' 8.2'

8' 156 5.8' 5.8'

10' 100 7.3' 7.3'

12' 69 8.7' 8.7'

14' 51 10.2' 10.2'
